Pharmaceutical Drying Equipment
Find innovative pharmaceutical drying equipment and connect directly with world-leading technology suppliers.
In the pharmaceutical industry, the drying process is used to reduce or remove water or other types of solvents, which could cause chemical and microbiological deterioration of the final drug, by using pharmaceutical drying equipment. But that’s not the only reason. The drying process is used everywhere in the pharmaceutical field to serve various applications: preparing granules for tablets or capsules, reducing the bulk density or weight, assisting the grinding process, or obtaining plant-derived medicines, to name a few.
Which pharmaceutical drying technology do you need?
Sorption dehumidifier for deep drying
Humid ambient conditions such as those in tropical climates make dehumidification more…
Laboratory-scale vacuum tray drying oven
Vacuum drying is used to remove moisture from sensitive materials. Drying small bat…
Flash drying system
Flash drying refers to the removal of moisture by a stream of hot gas that goes through a stream of small …
Flash drying grinder for powders
Drying and grinding can be an important feature when trying to process products such as raw …
Fluidized bed system for the granulation and drying of pharmaceuticals
Pharmaceutical industries employ several processe…
Entry-level conditioning system for drying nutraceutical gummies
The drying process demands specific environmental condit…
Pilot freeze dryer for scale up
Designed for biological, pharmaceutical and food products formulation and “scale up” work.
Custom engineered freeze dryer
For either bulk format or liquid in vials, ampoules or syringes, the Lyomega units are designe…
There is currently no equipment listed with your specified properties, but we are sure we can help you. Try us!Contact us
What are you making?
Active pharmaceutical ingredients (API) Agar-agar Ampoules Antibiotics CBD gummies CBD oil Cell cultures Chamomile oil Chewable tablets Collagen powder Cough syrup Dental implants Dry inhaler powder Eardrops Echinacea extract Effervescent tablets Elderberry extract Emulsions Enteric Coated Tablets Eucalyptus oil Eyedrops Flower extract Gels Ginkgo extract Ginseng extract Hard gelatin capsules HPMC capsules Hyaluronic acid Infusions Insulin Lavender oil Lotion Medical gummies Microtablets Multi-layer tablets Nasal spray Ointment Omega 3 oil Parenterals Pharmaceutical cartridges Pharmaceutical granules Pre-filled Syringes Probiotics Protein powder Reaction flavors Rose oil Sea buckthorn oil Single-use bags Softgel capsules Suppositories Surgical instruments Tea tree oil THC Uncoated tablets Vaccines Veterinary tablets Vials Vitamin C Water for injection
It is important to note that the choice of which pharmaceutical drying equipment to use stems from whether a wet solid, a solution, or a suspension needs to be dried.
Using fluid bed dryers for drying wet solids in the pharma industry
When it comes to drying granules that will then be pressed to form tablets, the fluidized bed dryer is one of the pharmaceutical drying equipment manufacturers use. Fluid bed dryers use a stream of hot air to reduce the moisture content of powders and granules, making them a great example of direct dryers. What does this mean? Direct dryers directly apply heated air to the product, while indirect dryers conductively heat the product by circulating heated fluid through a surface that is in contact with the product.
The fluidized-bed dryer is based on the fluidization principle. When hot air is blown into the machine to dry the product, the air velocity lifts it, converting the product from a solid to a fluid state. The suspended product seems to be a bed of fluid at this point. This is where the machine’s name comes from.
Freeze drying used to prolong the shelf life of pharmaceutical products
The freeze drying process was developed during the 1940s and pharmaceutical manufacturers use it to dry heat-sensitive materials to prevent damage to substances such as proteins and microorganisms.
Freeze-dryers are based on the sublimation principle, where solid crystals turn to vapor without passing through a liquid phase. Lyophilization occurs when the material is placed under a deep vacuum and subjected to heat energy, transforming the ice into gas.
In pharmaceutical applications, freeze-drying improves the stability and long-term storage life of labile drugs, especially protein drugs. In the pharmaceutical industry, freeze-drying is used for preserving and storing high-value products such as vaccines, cytostatics, antibiotics, biologicals, hormones, and active ingredients. It is also used for collagens, APIs, and electrolytes.
What about spray dryers and vacuum dryers?
Spray dryers are widely used pharmaceutical drying equipment to produce pharmaceutical powders with particle sizes from the nanometer to the micrometer scale. Spray drying is a continuous process by nature since it can convert a liquid feed into a powder in a single step.
A viable option for heat- or oxygen-sensitive pharmaceutical products is the vacuum drying process that reduces the risk of dust explosions. Vacuum dryers fall in the category of conductive dryers used for drying wet solids.
Pharmaceutical drying and its different applications
Drying active pharmaceutical ingredients (API)
From R&D to large-scale industry, pharmaceutical drying plays an essential role because it dramatically affects the quality of the final product both in primary pharmaceutical manufacturing, i.e., production of API or excipients, and in secondary pharmaceutical manufacture, i.e. when converting the active drugs into the final dosage form such as tablets or capsules. The drying of crystalline active pharmaceutical ingredients (API) is often needed to produce free-flowing powders for formulation, packaging, storage, and transport. The sensitive nature of API requires gentle drying in contained good manufacturing practice (GMP) environments.
Pharmaceutical drying for making plant-derived medicine
When making plant-derived medicine using plant extracts, the plant must be dried before the extraction to preserve it from enzymatic degradation. In the case of delicate plants, freeze-drying protects the thermolabile compounds. The drying temperatures range between -60°C and -80°C.
Send us a message if you are looking for a drying solution to process pharma products
We will connect you directly with a technology partner we believe can help you.
Let's talk about your project!
Tell us about your production challenge and connect directly with leading manufacturers worldwide
All your data is kept confidential
