Vacuum cold trap for efficient purging and drying
Optimize your laboratory’s efficiency by integrating high-performance vacuum cold traps designed for precise control over purging and drying processes, ensuring thorough removal of unwanted solvents and gases.
Preserves and Protects Vacuum Pumps in Production
The MAXTRAP Vacuum Cold Trap from Cascade Sciences is engineered to extend the life of your vacuum pump by efficiently collecting condensates before they reach the pump. Uniquely designed with a COLDWELL stainless steel trap and a patent-pending baffle system, it prevents flow restriction and maximizes surface area for effective condensate capture. It operates using a mechanically refrigerated system built by Labconco and integrates seamlessly into laboratory and chemical processing lines, handling biopharmaceuticals, fine chemicals, and nutraceuticals, amongst other applications. With configurable refrigeration settings at -50°C and -105°C, it suits a variety of purging and drying tasks. Its robust construction includes a KF-25 inlet and outlet to ensure uninterrupted flow and minimal maintenance. The trap’s compliance with CFC and HFC-free standards underlines its commitment to operational safety and environmental responsibility.
Benefits
- Enhances vacuum pump lifespan by preventing condensate ingress.
- Supports high-throughput operations with full KF-25 connections to avoid flow restrictions.
- Promotes energy efficiency with a refrigeration system free from CFC and HFC refrigerants.
- Flexible application with configurable temperature settings for diverse processing needs.
- Reduces maintenance intervals with robust construction and a large surface area for effective trapping.
- Applications
- Chemical processing,Fine chemicals,Nutraceuticals,Biopharmaceuticals,Essential oils,Laboratory applications,Pharmaceuticals
- End products
- Botanical extracts,Chemical reagents,Active pharmaceutical ingredients (apis),Cbd oil,Essential oil concentrates,Dietary supplements,Peptides,Laboratory specimens,Flavor compounds,Vaccine components
- Steps before
- Purification,Grinding,Pre-cooling,Material Loading
- Steps after
- Vacuum Purging,Drying,Material Transfer,Cleaning
- Input ingredients
- vacuum pump suction,high moisture with outgassing,solvents,oxygen
- Output ingredients
- condensed matter in trap,liquid oxygen,purged gases
- Market info
- Precision Extraction Solutions is known for providing innovative, high-quality extraction equipment and solutions for the cannabis industry, specializing in systems that enhance efficiency and safety in extracting cannabinoids and essential oils.
- Trap Type
- Vacuum Cold Trap
- Trap Capacity
- 3 Quart (2839 ml)
- Surface Area
- Patent pending series of filter baffles
- Temperature
- -50°C / -105°C
- Material
- 304 Stainless Steel
- Refrigerant
- CFC / HFC Free
- Connection Type
- KF-25 flanges
- Power Requirement
- 115V / 1ph / 3 AMP (60Hz)
- Dimensions (MAXTRAP50)
- 13.5" W x 23.5" D x 12.0" H
- Dimensions (MAXTRAP105)
- 24.1" W x 23.9" D x 12.6" H
- Weight (COLDWELL Stainless Trap)
- 14 lbs
- Mechanical Base Weight (MAXTRAP50)
- 60 lbs
- Mechanical Base Weight (MAXTRAP105)
- 139 lbs
- Working mechanism
- Refrigerated vacuum cold trap
- Batch vs. continuous operation
- Batch
- Automation level
- Manual
- Cleaning method
- Manual
- Corrosion resistance
- Stainless steel (304)
- Temperature resistance
- -105°C to -50°C
- Chemical compatibility
- Ethanol,glycol,cryo-cool fluids
- Seal Material
- Viton Gasket
- ETL Mark
- UL61010-1
- Machine footprint
- 13.5″ W x 23.5″ D x 12.0″ H (MAXTRAP 50) / 24.1″ W x 23.9″ D x 12.6″ H (MAXTRAP 105)
- Weight
- 14 lbs (Stainless Trap) / 60 lbs (Thermo Mechanical Base) / 139 lbs (Mechanical Base)
- Capacity
- 3 Quart (2839 mliters)
- Material
- 304 Stainless Steel
- Inlet/Outlet connections
- KF-25 flanges
- Cooling System
- -50°C / -105°C Refrigerated Base
- Refrigerant
- Green CFC / HFC Free
- Gasket Material
- Viton
- Insulation
- 3mm Neoprene Insulator Cap
- Capacity
- 3 Quart (2839 ml)
- Temperature Options
- -50°C / -105°C
- Cooling System
- Refrigerated by Labconco
- Inlet/Outlet Connections
- KF-25 Flanges
