Process analytical technology for lyophilization

Ensure product integrity by detecting trace contaminants and optimizing lyophilization cycles with a high-sensitivity solution designed for contamination prevention in biopharmaceutical freeze-drying processes.

Monitors Contamination and Moisture in Freeze Drying

The LYOPLUS® Mass Spectrometer from GEA is an essential tool for pharmaceutical and biotech manufacturers focused on ensuring the integrity and quality of their freeze-drying processes. Specially designed to detect trace contamination and moisture within freeze dryers, the system provides a crucial safeguard against silicone oil leaks and helps optimize drying cycles. Its quadrupole mass spectrometer design integrates seamlessly with existing automation environments or operates as a standalone unit, offering high sensitivity down to 1 ppm. With applications ranging from the production of monoclonal antibodies to lyophilized tablets, LYOPLUS® supports both pilot and production-scale operations, providing compliance with GMP requirements. Equipped with SCADA applications and multilingual interfaces, the system enhances process control while minimizing downtime and ensuring product purity.

Benefits

  • Enhances product safety by detecting silicone oil leaks early, preventing contamination.
  • Optimizes drying cycles, reducing unnecessary process time and energy consumption.
  • Integrates smoothly with existing control systems, ensuring swift adoption and minimal disruption.
  • Complies with GMP standards, supporting stringent regulatory requirements.
  • Increases operational efficiency with real-time monitoring and data analysis.

General


Applications
Parenterals,Biopharmaceuticals,Liquid formulations,Pharmaceutical products
End products
Gene therapy medications,Hormone therapies,Cell therapy products,Vaccines,Lyophilized tablets,Chemotherapeutic drugs,Insulin,Monoclonal antibodies,Biological drug substances,Enzymes,Injectable drugs,Eye drops,Protein therapeutics
Steps before
Formulation,Loading of Vials,Evacuation of Dryer,Cooling Shelves and Ice Condenser
Steps after
Quality Control Testing,Product Removal,Post-Production Cleaning,Shelf Heating
Input ingredients
water vapor,solvents,nitrogen,oxygen,helium,silicone oil
Output ingredients
lyophilized product,reduced moisture content
Market info
GEA is known for its expertise in engineering innovative and sustainable equipment and solutions, focusing on sectors such as food, beverages, pharmaceuticals, and energy, with a reputation for quality, efficiency, and advanced technological applications in industrial processing.

Technical Specifications


Detection limit
Down to 1 ppm
Automation
SCADA application compliant to 21 CFR Part 11
Interfaces
Industrial standard interfaces
Inlet system
High-conductance
Measurement
Quadrupole mass spectrometer
Sensitivity
1 ppm of non-interfering species
Software
Advanced data collection and control

Operating Characteristics


Automation level
Manual / PLC / SCADA
Batch vs. continuous operation
Batch
CIP/SIP
CIP 121°C / SIP 135°C
Cleaning method
CIP / Manual
Energy efficiency
0.5–2 kWh/kg moisture
Leak detection
Silicone oil and helium leak tests
Moisture content monitoring
Recipe-dependent moisture profiles
Process monitoring
Mass spectrometry
System integration
Standalone or full integration

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Product type Characteristics


Contamination risk
Silicone oil,process fluids

Physical Characteristics


Machine footprint
Customizable
Control panel type
Multilingual graphical user interface
Compact footprint
Fits existing automation environments
Discharge method
Integrated with freeze drying process
System's connection type
Tri-clamp connection

Custom Options


Integration with existing systems
Compatible with legacy and modern systems
Control system
Standalone or integrated with automation
Interface type
Standard industrial interfaces
Installation options
Retrofit into existing setups
Data representation
Comprehensible,real-time monitoring
System adaptability
Adaptable to different freeze dryer models
User interface
Multilingual graphical user interface
