Pilot plant filter dryer for small scale production

Optimize filtration and drying processes in your pilot plant with a versatile solution designed for seamless integration into small-scale production lines, enhancing efficiency and precision in handling sensitive slurries and cakes.

Filters, Dries, and Mixes Pilot-Scale Products

The COMBER Pressofiltro® / Turbodry® Series PF/TD units by Heinkel are versatile pilot plant filter and vacuum dryers designed for industries such as pharmaceutical, chemical, and food processing. Specially engineered to perform processes like filtration, drying, and mixing, they cater to operations that require small-scale production or pilot testing. This equipment is ideal for end-products like active pharmaceutical ingredients, epoxy resin powder coatings, and synthetic pigments.

Constructed in accordance with the Pressure Equipment Directive 97/23/EG and ASME U-stamp, these units are compliant with GMP and FDA guidelines, ensuring certification for pharmaceutical applications. They operate safely in ATEX danger zones (group II 2G 2D, zones 1/21) thanks to their explosion-protected control system (EEx-d). Built on a skid with a secure shaft seal via a gland nut, they support easy integration within existing production lines.

Customization is available, featuring a multilayer PLC system to enhance automation and process control. This series caters to Research & Development, laboratory, and processing departments seeking efficient filtration and drying of slurry and cake types. The equipment is also engineered for ease of maintenance with its robust design and materials suitable for a range of industrial environments.

Benefits

  • Enhances process flexibility by integrating filtration, drying, and mixing in one unit.
  • Reduces labor costs with automated PLC-controlled operation.
  • Ensures safety and compliance in hazardous environments with ATEX-certified design.
  • Meets stringent pharmaceutical and food industry standards with GMP and FDA compliance.
  • Supports diverse material handling due to robust construction and material versatility.

General


Applications
Surface coating,Fine chemicals,Chemical,Food products,Metal / recycling,Pharmaceutical
End products
Polymer powders,Active pharmaceutical ingredients (api),Lithium-ion battery electrode material,Nano-precipitated calcium carbonate,Catalyst carriers,Synthetic pigments,Vitamin powders,Protein isolates,Epoxy resin powder coatings
Steps before
Filtration,Precipitation,Mixing
Steps after
Crystallization,Packaging,Storage
Input ingredients
raw chemicals,pharmaceutical ingredients,fine chemicals,food materials,metal components
Output ingredients
dried chemical products,filtered pharmaceutical compounds,purified fine chemicals,dehydrated food products,processed metal components
Market info
Heinkel (Comber) is renowned for manufacturing industrial engineered-to-order equipment, specializing in filtration, centrifugal, and mixing solutions. They are recognized for their precision engineering, quality, and ability to tailor solutions for pharmaceutical and chemical industries.

Technical Specifications


Internal Diameter
200 – 500 mm
Filter Area
0.03 – 0.2 m²
Cake Volume
0.2 – 25 l
Speed
150 – 700 1/min
Drive Power
1.1 – 2.2 kw
Automation
PLC-controlled
Pressure Equipment Directive Compliance
97/23/EG
ASME U-stamp Compliance
Yes
ATEX Certification
Group II 2G 2D (zones 1/ 21)
Gland Nut Shaft Seal
Yes
Explosion Protection
EEx-d

Operating Characteristics


Batch vs. continuous operation
Batch
Automation level
PLC-controlled
Cleaning method
CIP / Manual

Material Compatibility


Density/particle size
0.5–2.5 g/cm³

Product type Characteristics


Operation mode
Pilot Plant / Small Scale Production


Pressure Equipment Directive
97/23/EG
ATEX certification
Group II 2G 2D (zones 1/21)

Physical Characteristics


Machine footprint
Device built on skid
Discharge method
Shaft seal through gland nut
Internal Diameter
200–5000 mm
Filter area
0.03–0.20 m²
Cake volume max
0.2–7 liters

Custom Options


Control system
Protected against explosion (EEx-d)
Device build
Built on skid
