Continuous chocolate line with vertical ball mills

Milling machines are used to reduce the size of material by cutting, crushing, or grinding it. The choice of industrial milling equipment depends on the industry and the materials to work with. Besides, there is a significant difference between those aimed to remove layers from metal or other materials workpieces and those designed to reduce particle size for materials that come in bulk.

Milling

Feed ingredients

With the increase in the world population and rising concerns for environmental sustainability, the market for suitable new protein sources is expanding rapidly. Traditional agricultural methods alone can’t deliver sufficient protein to meet the projected food demand over the next decades. Insects provide an alternative source of nutrients. But insect protein does not mean direct insect consumption. Extracting protein and amino acids from farmed insects is more sustainable and efficient. Specialized insect protein processing technology is driving the transformation toward new protein sources.

Insect protein

Do you have a sweet tooth, or are you more into a warm loaf of bread for a savory lunch? The bakery shop window displays something for everyone, from baguettes over croissants to muffins. Bakery products are a wide range of baked goods prepared from flour or meal derived from grains. These undergo mixing, fermentation, and baking processes with the help of bakery processing equipment such as a series of low- and high-speed mixers, fermentation tanks, and baking chambers.

Bakery

With over one-third of the population consuming it daily in different forms, coffee is one of the most popular processed beverages worldwide. Not only serving as drinks, but coffee is also often regarded as a culture. Coffee manufacturing is a knowledge-intensive industry. Coffee beans from different regions will reveal different tastes, while the level of caffeine could also be different. When it comes to coffee bean processing, the range of roasts varies from light golden brown all the way to dark. The method of tasting coffee differs between countries, habits, and tools.

Coffee

<span style="font-weight: 400">Cocoa production and the cocoa industry uses industrial processing technology to process and manufacture high quality cocoa products in many different forms. Did you know that cacao cultivation goes back centuries - to be specific, about 5300 years? </span><span style="font-weight: 400">This plant, with its long history, is also known for its versatile usage. From </span><span style="font-weight: 400">cocoa nips to cocoa butter, cocoa becomes a base to produce multiple products, ranging from food products to cosmetics. As you may already know, chocolate products are all made from cocoa as well. Hence, depending on what you intend to produce as the end product, as well as your recipe, your cocoa processing equipment line may change.</span>

Cocoa

There is a pasta type for every mood. Curly, straight, ridged, or smooth, pasta has quickly grown into a staple food. The simple combination of milled wheat and water is transformed by pasta making equipment into a rainbow of shapes, colors, and sizes. But producing pasta with the right firmness, elasticity, and color profile is as intricate a process as preparing an authentic lasagna.

Pasta

Organic fertilizer production has ancient roots, tracing its origins to ancient farmers who used natural materials like animal manure, compost, and crop residues to improve soil fertility. This sustainable tradition of repurposing organic waste for agricultural benefits has endured through the ages, handed down from one generation of farmers to the next. Producing organic fertilizer industrially involves a series of steps such as extraction, granulation, drying, and employs a combination of organic fertilizer production equipment.

Organic fertilizer

Continuous milling is a flow production method used to grind materials without interruption. It is often used in the production of foods, cosmetics, pharmaceuticals, chemicals, and minerals. The material to be processed flows in at one end and the milled output flows out at the other in a continuous process. By choosing the right combination of milling technology and processing power you can obtain the desired particle size distribution in an uninterrupted stream.

Continuous

Industrial

In industries like chemicals, food, and pharmaceuticals, achieving homogeneous mixtures of fine and cohesive powders in short timeframes is essential. Traditional batch mixing systems often struggle with residue and temperature increases, leading to inefficiencies in production lines.
<h2>Efficient and adaptable powder mixing</h2>
The Modulomix is a continuous mixer from Hosokawa Micron designed for processing fine and cohesive powders. It operates with high tip speeds, which makes it effective at dispersing materials quickly and precisely. Whether for low, medium, or high shear applications, the Modulomix offers a compact solution that minimizes residue and ensures rapid start-up and shutdown. The system's modularity allows for cascading multiple mixing units to adapt to complex mixing regimes. Key features include limited temperature increase, excellent heat transfer efficiency, and adjustable rotor speed to accommodate varying mixing conditions. The system is suitable for a range of applications including dry powder mixing, hydrating difficult powders, coating, sterilization, crystallization, and more.

Continuous mixing for fine and cohesive powders

Blending

To coat your consumer products with color or taste-enhancing substances, specialized technologies are available that ensure all the contents are individually and evenly covered. The process starts with loading your goods onto rotating drums, exposing the products to spray nozzles that treat them with your prescribed coating formula.

Coating

Crystallization

Industrial mixing equipment is used to combine two or more solid, liquid or gaseous segregated ingredients into a homogenous single product. The choice of mixing technology depends largely on the physical state of the ingredients and the desired final product. But the sensitivity of the ingredients, the process temperature, and pressure requirements are also critical factors. All these parameters result in a wide range of industrial mixers.

Mixing

Industrial sterilization processes are employed in different industries to completely eliminate all living microorganisms from the final product. For instance, in food processing, sterilization equipment is used to produce a stable product with a long shelf-life by eradicating harmful bio-contaminants. Instead, in the medical field, sterilization technologies aim to prevent the transmission of microbes to patients by sterilizing all the tools and medical devices that come in contact with the patient. Most sterilization equipment, such as autoclaves, employs high-temperature pressurized steam to destroy bacteria and disinfect surfaces from spores. Other methods include radiation sterilization or using chemicals such as hydrogen peroxide for disinfection.

Sterilization

Powder

solid

Batch

Entry level

Pilot

When developing new products with unpredictable grinding properties, the need for flexible systems is paramount. Traditional setups may involve multiple mills and classifiers, taking up significant space and often reducing efficiency during production and research phases.
<h2>Integrate multiple grinding processes seamlessly</h2>
The Multiprocessing System by Hosokawa Alpine offers a versatile solution for flexible production and research requirements. This system integrates multiple mill types into a single compact unit, ideal for rapid changeovers and efficient space utilization. By allowing quick switching between various grinding and classifying modules, it supports small-batch R&D while maintaining compliance with GMP standards. The system is available in sizes ranging from small laboratory setups to large-scale production units. Key features include modular design, optimized dismantling for easy cleaning, and minimal documentation requirements. Ideal for industries such as food, chemicals, pharmaceuticals, and minerals, the Multiprocessing System ensures high flexibility, reduced investment costs, and ease of validation.

Multiprocessing system for flexible research and production

Classifying

Grinders use a spinning blade or rotating abrasive elements to reduce the size of various materials. The specifications, RPM and grit of the engineered grinder, will result in various particle sizes. As a result, what you want to make will determine the type of grinder you need. Grinding is used for improving the texture and flow properties of various products and to enhance the flavor of food products such as coffee, spices, sugar, nuts, sesame, poppy seeds, lentils, wheat, and rice. Choosing the right rotational speed, grinding elements, and processing power allow the grinding and shredding of a wide range of materials into coarse or fine powders. Popular types of heavy duty grinders in food processing include angle grinders, bench grinders and meat grinders.

Grinding

Industrial separation equipment encapsulates the separation process which is to separate components of a liquid mixture, for recovering dissolved solids from liquids. The choice of a suitable technology depends on the identification of the key physical or chemical property, such as size, mass, density, or boiling point, which sets the product of interest apart from the rest of the components. Separation technology is widely used in the pharmaceutical and chemical industries for the isolation of active ingredients and high-purity chemicals. As well as in waste management and recycling industries.

Separation

In high-volume tortilla and corn chip production, traditional masa preparation methods often lead to extended processing times and excessive water usage. These inefficiencies can increase costs and impact production schedules, making it critical to find a more streamlined approach to masa production.
<h2>Produce fresh masa in minutes</h2>
The Masa Maker from Heat and Control is a recipe-driven, continuous system designed for rapid corn masa preparation. Instead of relying on traditional simmering and soaking techniques, this system converts dry, clean corn into fresh masa in just minutes. This eliminates the need for masa flour and allows on-demand production, ensuring consistent quality and flavor profile as per your brand requirements. By substantially reducing water usage to just what is required for the recipe and sanitation, the Masa Maker contributes to significant water savings. Additionally, it eliminates the necessity for steam generators, simmer kettles, and soak tanks, saving on energy and freeing up floor space for other operations. The Masa Maker is ideal for producing tortilla chips, taco shells, and other corn-based products.

Corn masa preparation system

Whether it is marmalade or pizza, sauce or hummus, chocolate or fruit puree, most food products undergo a cooking step during their production process. Cooking is nothing more than applying heat to food, but there are different methods to do it. For instance, baking, frying, and roasting involve cooking food without using water, unlike boiling or steaming. Industrial cookers such as vacuum and pressure cookers, industrial fryers, industrial ovens, and industrial roasters focus on specialized applications that meet the different needs of the food industry by helping producers achieve a homogeneous cooking process.

Cooking

High-volume production lines often struggle with efficient and quick drying processes, especially when dealing with delicate materials. Conventional systems may lead to high energy consumption and longer drying times which are not ideal for industries demanding fast throughput and minimal downtime.
<h2>Rapid, consistent drying with minimal air loss</h2>
The continuous dryer from HARTER Drying Solutions is designed for high-volume, time-sensitive production environments. Using a closed-loop system, it ensures efficient drying with minimal energy loss. The system utilizes extremely dry air and precise air guidance, and can optionally employ airless blow-off technology to achieve complete drying within minutes or seconds. The Airgenex® condensation drying technology ensures minimal air loss through small openings at the inlets and outlets of the drying chamber. Specific parameters like belt length, speed, and air flow are customized through drying tests, ensuring optimal performance. Suitable for applications including surface drying, food processing, pharmaceutical/medical technology drying, and more, it is tailored to meet various industrial requirements.

Continuous dryer for large production volumes

Industrial drying machines are designed to remove moisture from your product. But the drying process must cater to variations in the state of matter and molecular structure of the input material. Industrial dryer technology exploits the modes of heat transfer (convection, conduction, radiation, evaporative cooling) to control the moisture content.

Drying

Lyophilization

When drying large volumes of food products, achieving consistent results can be challenging. Unstable drying conditions can lead to uneven moisture levels and product degradation. Efficient temperature control, adaptable drying times, and seamless product handling are essential to maintain quality.
<h2>Ensures consistent and gentle drying.</h2>
The Tunneltrockner for continuous operation by HARTER Drying Solutions offers a reliable drying process for food products. Products are placed in baskets or on trays within movable racks that are transported through the drying tunnel either manually or automatically. The tunnel is equipped with a conveyance system that enables continuous or intermittent movement of the racks, with speed adjusted based on product requirements. This method ensures that your products are dried gently at low temperatures within the desired time frame. The system's flexibility allows you to dry different products by adjusting temperatures and drying times specific to each product. Standard racks fit the dimensions of Euro pallets, but customizations are available to accommodate specific needs. HARTER can also provide a complete drying system including specially designed racks.

Continuous tunnel dryer for food products

Conveyor systems are used for moving materials from one location to another. Considerations for choosing a suitable industrial conveying system include the nature of the product, its physical state, the desired conveying rate, and sensitivity of the product to heat and mechanical shock. Conveying equipment is used in the food, pharmaceutical, chemical, biomass, and mineral industries to move materials around a warehouse as well as to transport bulk powders, granules, and grains for processing and filling. These types of systems are usually automated and there is a wide variety of solutions to choose when it comes to the type of conveyor. Types include screw, gravity, chain, roller and belt conveyors.

Conveying

In industrial bread production, removing the crusts from loaves evenly and efficiently is crucial. Manual decrusting is time-consuming and inconsistent, leading to waste and lower-quality products. For bakeries seeking to automate and enhance precision in bread decrusting, a dedicated solution is essential.
<h2>Effortlessly decrust loaves on all sides</h2>
The Mod. 110-TRA by Gasparin is a continuous band blade decrusting slicer designed for the effective removal of bread crusts on all four sides. Utilizing a continuous band blade cutting head mounted on balanced pulleys, it offers excellent adherence and stability during operation. This slicer features two distinct stations: one for horizontal crust slicing and the other for vertical crust slicing. It includes adjustable inlet and outlet loading conveyor belts, with the upper belt designed to hold and guide the loaf securely towards the blades and the lower belt equipped with lateral guides. Each blade's cutting height and depth are independently adjustable, allowing for precise customization. The conveyor belt's speed can be adjusted via an inverter, ensuring flexibility in production. An electric panel with centralized controls and stainless steel protection screens offers ease of use and safety. Optional features include pneumatic blade tensioning, a stainless steel version, and a design ready for a crumb suction system.

Continuous band blade decrusting slicer for bread

Cutting

Handling

In the production of butter toffee, ensuring a consistent texture and flavor is crucial, especially when dealing with ingredients like nuts and high-fat content mixes. Poor processing can lead to inconsistent product quality and inefficient production times.
<h2>Continuous processing of butter toffee</h2>
The ROTORSTAR from CHOCOTECH is designed for the continuous processing of butter toffee containing sugar, butter, and glucose. This system allows up to 15% of volume in chopped or ground nuts to be incorporated into the toffee mixture before cooking, where nuts achieve a roasted flavor. The mixture can handle nut pieces up to 5 mm in size, and larger nuts can be integrated post-cooking using the SOLLICH SMC mixer. This ensures a fine, snappy texture with the traditional taste of roasted nuts.

Continuous butter toffee processing system

Processing

Roasting involves extended exposure to heat in an oven or over a fire. Depending on your end product, roasting equipment makes sure that the raw materials you put in undergo even roast intensity before they are transferred for further processing. Some roasting technologies may also be used for other cooking requirements, including toasting and drying. When thinking about roasting, the idea of roasted coffee comes to mind. However, there are a wide array of food products that go through a roasting process. For example, nuts such as almonds and cashews go through a roasting machine

Roasting

In large-scale confectionery and bakery production, achieving consistent aeration in sugar masses, chocolates, and baked goods is crucial. Uniform texture and structural integrity are often challenged by varying ingredient properties and batch sizes.
<h2>Ensures homogenous aeration with precise control</h2>
The TORNADO® by CHOCOTECH is designed to offer continuous aeration of sugar masses, chocolate, and bakery products. The system features an aerating head with a rotor and stator that can be tempered for both heating and cooling, facilitating intensive blending through meshing shearing pins. The process starts with a small pre-rotor and pre-stator combination that meters the whipping agent and starts the aeration process. This pre-foam is then introduced into the pressurized main aerating head along with the base mass, resulting in a fine-pored and stable foam. The system's rotor and stator are EDM finished for precision and can be easily disassembled for maintenance. This aeration technology ensures consistent and homogeneous blends across various confectionery and bakery applications. The TORNADO® series offers different models to handle light and heavy foam, with capacities ranging from 500 kg/h to 2000 kg/h depending on specific weight and foam texture.

Continuous aeration system for confectionary and bakery products

Aerators are devices used for mixing air (oxygen transfer) with a liquid such as water or oil to form a homogeneous product. Selecting an industrial aeration system involves choosing a suitable mixing head and considering the desired input and output flows, temperature, level of aeration, properties of the liquid phase, and the degree of automation and pressure control. Aerators are used in the food industry for the production of fat-based center masses and crèmes and in the chemical industry for wastewater treatment. When it comes to water treatment, surface aerators are most commonly used.

Aeration

Industrial cooling equipment varies according to the consistency and temperature conversion demands the material you are handling, but the process typically involves heat exchange treatment as your products are conveyed through a cooling chamber equipped with extraction fans or circulating water. Temperature control is a crucial aspect of your commercial production and cooling systems are applied to a range of industries.

Cooling

In large-scale bakery operations, achieving consistent dough quality for various products like croissants and biscuits can be challenging. Maintaining optimal texture and volume, while also ensuring efficient production, often requires multiple steps and various pieces of equipment.
<h2>Unify mixing, kneading, and pressure treatment</h2>
The ContiMix Continuous Dough Extruder from Bühler is designed to seamlessly combine mixing, kneading, and pressure/vacuum treatment into one streamlined process. This system excels in producing doughs that have improved volume and crumb structure, essential for high-quality end products. With precise temperature control, it enhances the taste of baked goods that use butter or margarine. The system also offers the potential to reduce or eliminate downstream process steps, saving both time and investment costs. The closed processing zone ensures a continuous product flow and higher food safety standards. Ideal for bakeries aiming for consistent quality and shorter production times, the ContiMix significantly optimizes the dough preparation process.

Continuous dough extruder for baked goods

The extruder was first developed to make lead pipes in the late 18th century. But the extrusion process technique quickly spread to other manufacturing sectors, including food, feed, and biomass products. An extruder machine presses a fluid or solid material through a die. Depending on your use case, extruders adopt single- or twin-screw systems to push the premixed feed material through a barrel. Thermal pressure applied in this step can chemically modify the mixture, so the screw system must be precisely calibrated to achieve the desired result. Finally, a knife head cuts the extruded material into your designed dimensions. Extrusion machinery produces items of a uniform size, shape, and consistency.

Extrusion

The process of forming allows you to shape your products homogeneously. Forming machines are fed the manufactured material in bulk and cut it down to specification, so the process takes place between formulation of the mass and the packaging of the final item.

A special class of this equipment – Form, Fill, and Seal Machines (FFS) – creates bags and pouches from flat material such as plastic sheets, fills them with your designated product, and seals them.

Forming

Kneading

In industries where precise mixing of powders is critical, challenges often arise related to achieving homogeneous mixtures without product loss or contamination. Ensuring consistent quality and abiding by stringent hygiene standards are additional hurdles that must be overcome.
<h2>Achieves consistent mixing for various material states</h2>
The AMK Continuous Mixer from Amixon is designed to handle dry, moist, and suspended goods with an emphasis on precise and controlled mixing. One of its notable features is the adjustable mixing intensity, which ranges from gentle homogenization to intensive deagglomeration. The mixer operates with minimal product loss at both the start and end of production, maintaining efficiency. Capable of micro-fine admixture of liquid materials, it ensures no contamination and meets high regulatory and hygiene standards (GMP, FDA, 3-A Sanitary Standards, and EHEDG). The AMK Continuous Mixer also excels in extended processes such as moistening, tempering, drying, and reaction processing. An innovative continuous boiler flow aids in maintaining a consistent filling level, thereby optimizing mixing efficiency. The top-mounted mixing device ensures safe and thorough cleaning, either dry or wet.

Continuous powder mixer for dry, moist and suspended goods

Homogenization is the process of reducing particle size in mixtures to improve the consistency, uniformity, and stability of the product. The choice of a homogenizer depends on the nature of the product, desired particle size, the physical state of the ingredients, and pressure requirements during the process. Homogenization is widely used in the biotech industry for cell lysis and in the pharmaceutical industry for the emulsification of creams and ointments; it also finds applications in the cosmetics and food industries for improving the consistency and uniformity of various products.

Homogenization

Tempering equipment is most commonly used in manufacturing chocolate products as well as bakery products. However, tempering can also be found in the metals industry for processing alloys. The idea behind the tempering process is to heat two or more items to a certain temperature so that they can be blended together easier. Chocolatiers pass the chocolate through a heating cycle and then a cooling tunnel to give their final products a smooth and glossy finish. Tempering machines automate this process, evenly distributing the crystal structure in melted chocolate across the entire production line. Besides enhancing the look and texture of coatings, denser and consistent crystallization also has the benefit of slowing down fat migration in your chocolate-filled products. A vibrating table is an important component for tempering chocolate. First the chocolate mixture goes through a dispenser into the chocolate mould. After which the vibrating table is used to evenly distribute the mixture in the mould so that there are no air bubbles. Thus, creating a smooth and consistent final product.

Tempering

liquid

During the early stages of synthesis, generating only limited product quantities can pose a challenge, making realistic milling tests more difficult.


<h2>Formulates chemical reactions for tests in R&amp;D labs and universities</h2>
DYNO<sup>®</sup>-MILL RESEARCH LAB from WAB-GROUP<sup>® </sup>is a bead mill suitable for small batches starting from 100 ml. It enables processing in two modes: continuous passage and circulation mode. The mill can grind media from ø 0.05 - 1.0 mm to a particle size under 100 nanometers.

DYNO<sup>®</sup>-MILL RESEARCH LAB is designed for easy handling: you can detach the entire grinding section from the drive by loosening just three screws. Afterward, disassembling the grinding section requires only a few simple steps. This makes cleaning quick and convenient. Plus, the separate grinding cylinder can undergo sterilization as a whole.

Agitator bead mill for flow chemistry

To optimize qualities like particle size, distribution, solubility, and miscibility of active ingredients in agricultural chemicals, you need to be able to grind them ultra-fine.


<h2>Finely grinds particles that provide better protection of the plant against pests, fungi, and weeds</h2>
DYNO<sup>®</sup>-MILL Universal Bead Mill (UBM) from WAB-GROUP<sup>® </sup>offers dispersion and ultra-fine grinding solutions for fertilizers, fungicides, herbicides, and insecticides. The mill accommodates a grinding chamber volume spanning from 0.5 to 100 liters and employs grinding media with diameters ranging between Ø 0.2 and 2.5 mm. It efficiently grinds and disperses active ingredients to very fine particle sizes.

Featuring the DYNO<sup>®</sup>-DISC BC agitator discs with integrated grinding media channels, the DYNO<sup>®</sup>-MILL UBM ensures an acceleration of the grinding beads along a defined trajectory. In the operational phase, each channel for the beads establishes dual grinding circuits between the agitator discs, operating in opposing directions. The enclosed outer configuration secures the beads between the discs, ensuring their uniform distribution within the active grinding chamber, thereby facilitating efficient dispersion and fine grinding of active ingredients.

Bead mill for crop protection

Ensuring the quality, efficiency, and reproducibility of nanosuspensions throughout the wet grinding process is a continuous challenge, demanding strict control over various parameters like the use of high-grade materials, uniform energy input, and ideal cooling properties.
<h2>Grinds viscous products continuously in the micron and nanometer range</h2>
The DYNO<span data-contrast="auto"><sup>®</sup></span>-MILL NPM from WAB-GROUP<span data-contrast="auto"><sup>® </sup></span>is specially designed for continuous dispersion and wet grinding of nanosuspensions. The patented DYNO<span data-contrast="auto"><sup>®</sup></span> ACCELERATORs provide powerful hydraulic movement of the grinding beads and guarantee consistent energy input for grinding thin to viscous products, in the micron and nanometer ranges. The rotating grinding media separation system facilitates the use of very small grinding media ranging from 0.05 to 0.2 mm.

The peripheral speed of the separation system ensures the safe separation of grinding media from the product. The use of high-quality ceramics like SiC, and ZrO<sub>2</sub> provides metal-free grinding and guarantees a long service life. It is ideal for both passage and circuit operation, maintaining consistent efficiency, while achieving extremely narrow particle size distributions. It is best suited for producing construction materials like paints, toners, and cement.

&nbsp;

Ultra fine bead mill for nanosuspensions

To prevent blockages, clogging, and cross-contamination coming from highly viscous materials your grinding equipment needs to be cleaned frequently.
<h2>Grinds low fluidity products with high throughputs in the nanometer range</h2>
DYNO<span data-contrast="auto"><sup>®</sup></span>-MILL ECM-AP from WAB-GROUP<sup>® </sup>is a high-efficiency agitator bead mill that features a patented grinding bead separation system. It is designed to grind the most challenging products with higher throughputs and production capacities. The self-cleaning effect of the separation system improves the driveability of highly viscous products, preventing screen clogging and reducing production downtimes for screen cleaning. It is designed to use the finest grinding beads down to 0.1mm. The uniform distribution of grinding media in the grinding chamber produces the finest and narrowest particle sizes in the nanometer range, ensuring a high grinding efficiency. It is applicable for both, pass and circulation modes. It is great for making coated and uncoated tablets.

Self-cleaning bead mill for highly viscous materials

To achieve precisely defined API properties and safe and reproducible production, rigorous implementation of hygienic and sterile automated processes is a must.
<h2>Refines wet milling with clean and sterile technology</h2>
The DYNO<span data-contrast="auto"><sup>®</sup></span>-MILL MULTI LAB CIP/SIP from WAB-GROUP<span data-contrast="auto"><sup>®</sup></span> is a specially designed agitator wet mill for sterile research and development, pilot, and production operations in the pharma industry. It can process low to high-viscous products with batch sizes starting from 500 ml. What is more, it comes with easily interchangeable grinding chambers from 0.3 l to 1.4 l. It can accommodate both, WAB KD agitator discs as well as the DYNO<span data-contrast="auto"><sup>®</sup></span>-ACCELERATOR. The use of agitating small beads in wet milling efficiently grinds suspended particles to the low micrometer or even nanometer range, maintaining a narrow particle size distribution.

Cleaning in Place (CIP) ensures there is no direct contact between the plant operator and active pharmaceutical ingredients. Steam sterilization up to 135°C ensures plant sterility, guaranteeing a germ-free production of tablets, capsules, injectables, and vaccines.

Agitator bead mill for API

For precise, efficient, and reproducible cell disruption, optimization of process parameters such as material selection, grinding media, and temperature control are important.


<h2>Employs ultra-fine grinding for cell disruption and extraction of ingredients</h2>
DYNO<sup>®</sup>-MILL MULTI LAB (ML) from WAB-GROUP<sup>®</sup> is an adaptable laboratory agitator bead mill, well-suited for small-scale productions and R&amp;D in biotechnology. Suitable in continuous and discontinuous operations, the bead mill specifically designed for smaller applications can utilize ultra-fine grinding beads as small as 0.1mm. It has adjustable grinding chamber sizes, material selection, and adaptable grinding technology. It incorporates two grinding principles in one mill: the DYNO<sup>®</sup> agitator disc and the patented DYNO<sup>®</sup>-ACCELERATOR.

Discontinuous operation utilizes grinding vessels of 0.15 l and 0.3 l to handle low-viscosity suspensions. The batches range from 85 ml to 170 ml. Continuous operation is suitable for processing highly fluid to viscous, pumpable products.  It employs grinding containers of 0.15, 0.3, 0.6, and 1.4 l to process batch sizes exceeding 500 ml. Using superior ceramic components such as SiC and ZrO<sub>2</sub> ensures no metal contamination and an extended service life.

Flexible laboratory bead mill for vaccines

Using nanoparticles in cosmetics requires precise control over material breakdown and distribution. You also have to keep material compatibility, temperature control, and high hygiene standards in mind.


<h2>Versatilely disperses particles in nano-cosmetic applications</h2>
DYNO<sup>®</sup>-MILL MULTI LAB (ML) from WAB-GROUP<sup>®</sup> is a flexible laboratory agitator bead mill, ideal for research and development and small-scale productions of cosmetics. It can accommodate varying grinding chamber sizes, material selection, and grinding technology. That in both, continuous and discontinuous operation. For the smallest applications, it is designed to use the finest grinding beads down to 0.1mm.

Discontinuous operation employs specially designed 0.15 l and 0.3 l grinding vessels to process low-viscosity suspensions in batch sizes of 85 ml and 170 ml, respectively. Continuous operation is suited to handle highly fluid to viscous, pumpable products. There, grinding containers of 0.15, 0.3, 0.6, and 1.4 l volumes are available to process batch sizes exceeding 500 ml. The use of high-quality ceramic components like SiC, and ZrO<sub>2</sub> assures no metal contamination and thereby, a long service life. It offers variability with two grinding principles in one mill: the DYNO<sup>®</sup> agitator disc and the patented DYNO<sup>®</sup>-ACCELERATOR.

Flexible R&D wet agitator mill for cosmetics

Processing toxic chemicals requires high compliance with safety standards and a continuous overview of the protection of your operators.


<h2>Reliably disperses and finely wet grinds paints, toners, and pigments</h2>
DYNO<span data-contrast="auto"><sup>®</sup></span>-MILL KD from WAB-GROUP<span data-contrast="auto"><sup>®</sup></span> was the first horizontal agitator bead mill for dispersion and ultra-fine wet grinding technology. The mill offers grinding chamber volumes ranging from 0.15 to 600 liters and utilizes grinding media ranging from Ø 0.5 to 2.5 mm. It employs a wide choice of grinding media including hardened and stainless steel, hard chrome-plated stainless steel, polyurethane, and ceramic.

In the horizontal grinding chamber, the DYNO<span data-contrast="auto"><sup>®</sup></span> agitator discs are symmetrically arranged on the agitator shaft and transfer kinetic energy to the grinding media. Especially in the passage mode, with optimal process parameters, these disc mills consistently achieve narrow particle size distribution in the micrometer range. It employs a cooling process by forcing the cooling water through the outer jacket, thereby enabling the processing of temperature-sensitive products like pigments and paints.

Also available as the DYNO<sup>®</sup>-MILL ECO 5 for more simple applications and smaller batch sizes.

Horizontal disc bead mill for liquid chemicals

<span data-contrast="auto">Fine-grinding</span><span data-contrast="auto"> s</span><span data-contrast="auto">olid flavors to improve</span><span data-contrast="auto"> taste properties and</span><span data-contrast="auto"> integration into your food product, you need a </span><span data-contrast="auto">clean </span><span data-contrast="auto">flexible </span><span data-contrast="auto">milling solution </span><span data-contrast="auto">that </span><span data-contrast="auto">can </span><span data-contrast="auto">handl</span><span data-contrast="auto">e</span><span data-contrast="auto"> a la</span><span data-contrast="auto">rge variety of materials</span><span data-contrast="auto">.</span>
<h2>Super-fine grinding and dispersion for technology refines food and enhances flavors</h2>
<span data-contrast="auto">DYNO<sup>®</sup>-MILL Universal Bead Mill (UBM) from WAB-GROUP<sup>® </sup>provides ultra-fine grinding and efficient dispersion solutions for a wide range of food and beverages, from laboratory-scale (DYNO<sup>®</sup>-MILL UNI LAB) to large-scale production. The mill accommodates a grinding chamber volume ranging from 0.5 to 100 l</span><span data-contrast="auto"> while utilizing grinding media ranging between Ø 0.2 and 2.5 mm. It serves dispersion and grinding for food refinement of chocolates, natural colorants, alternative foods, food supplements</span><span data-contrast="auto">,</span><span data-contrast="auto"> and pet foods. </span><span data-ccp-props="{&quot;201341983&quot;:0,&quot;335551550&quot;:6,&quot;335551620&quot;:6,&quot;335559739&quot;:160,&quot;335559740&quot;:259}"> </span>

<span data-contrast="auto">DYNO<sup>®</sup>-MILL UBM features the DYNO<sup>®</sup>-DISC BC agitator discs, designed with grinding media channels, which ensure effective acceleration of the grinding beads along a precisely defined path. During operation, each bead channel forms two grinding circuits between agitator discs, operating in opposite directions. The closed outer contour securely retains the beads between the discs and uniformly distributes them within the active grinding chamber,</span> <span data-contrast="auto">giving efficient dispersion and fine grinding of food and beverage products. </span><span data-ccp-props="{&quot;201341983&quot;:0,&quot;335551550&quot;:6,&quot;335551620&quot;:6,&quot;335559739&quot;:160,&quot;335559740&quot;:259}"> </span>

Agitator bead mill for functional foods and flavors

To facilitate the attainment of ultrafine particles and enhance electrode properties, reactivity, and surface structure proper grinding technology and high-quality raw materials should be applied.
<h2>Offers grinding and dispersion for NMC, Li-NMC, LNMC, and NCM materials</h2>
DYNO<sup>®</sup>-MILL Universal Bead Mill (UBM) from WAB-GROUP<sup>® </sup>provides dispersion and ultra-fine grinding solutions for a wide range of battery materials from laboratory-scale to large-scale production.  The mill is scalable with a grinding chamber volume from 0.5 to 100 l while using grinding media between Ø 0.2 and 2.5 mm. It is suitable for dispersion and grinding of battery materials like anode and cathode materials, fuel cells, carbon nanotubes, multi-layer ceramic capacitors, and photovoltaic and separator materials.

It comprises the DYNO<sup>®</sup>-DISC BC agitator discs, featuring grinding media channels, which ensure efficient acceleration of the media along a precisely defined path. While in operation, each of the bead channels establishes two grinding circuits between the agitator discs, functioning in opposing directions. The closed outer contour secures the grinding beads between the agitator discs and uniformly distributes them within the active grinding chamber, for dispersion and fine grinding of battery materials.

Ultrafine bead mill for battery materials

Products like granules, tablets and capsules require inspection at numerous steps in the production and packaging process. Since all pharmaceutical and chemical manufacturers have to follow standard quality specifications, automatic visual inspection, measurements, real time reports, statistical data and control are crucial at various stages of production and packaging.
<h2>Visual inspection and measurement of pellets, granules and mini tablets</h2>
Patvis APA by Sensum visualizes, measures and diagnoses quality of various particles, such as pellets, granules, and mini tablets in real-time when mounted on the process equipment. It consists of a high-resolution camera which performs non-destructive acquisition of live images. These images can be saved for later analysis and research purposes or are analysed in real-time, where the image analysis software programs ensure accurate measurements of particles. Furthermore, it is programmed to monitor and control the quality of particles in accordance with FDA and GAMP. It can detect variations in size, shape and extent of agglomeration during pellet coating, granulation and pelletisation processes. With its graphical user interface various statistical reports can be obtained during and after the process.

Particle analysation monitor

Formulation technologies are an integral process in many industries such as pharma and food. Chemical mixtures require strict handling to combine the separate ingredients into the homogenized recipe that makes your final product. Formulation technology stores, mixes and subjects the elements to a range processing parameters according to your specifications to develop the base material. The resulting formulas are then weighed, formed, packaged, or sent for further formulation.

Formulation

Granulation

Industrial inspection equipment is used for checking compliance with health, safety, and quality control standards. For that reason, inspection systems are most commonly utilized in the food and pharmaceutical industry but, they are also used in other industries too. Inspection solutions are often integrated into a production process or production line. Visual inspection systems perform checks to detect variation in size, shape, and color and ensure the presence of labels and closures. Check-weigh systems help ensure that product packages are not under or over-filled. Metal detection systems can help guard against the presence of foreign objects in product containers and X-ray inspection equipment is used to detect physical defects and to ensure high quality package seal integrity.

Inspection

Industrial measurement equipment is used as a crucial step before products leave the production line. These measuring instruments check for correct dosage and standards. Equipment for measurement and control employs a wide range of technologies to detect inconsistencies in volumes, sizes, weights, and fill levels as well as to inspect goods for quality against a set of criteria. Specialized measuring tools allow you to minimize the probability for error to its lowest possible, ensuring that both products and packaging meet your benchmarks.

Measurement &amp; Control

Complex processes call for continuous tracking and monitoring systems that help you to keep the manufacturing operation under control. The technology analyzes the components in the production phase for divergence in behavior or changes in conditions. Based on advanced software applications, monitoring platforms make sure that your products satisfy the quality criteria while they are being developed.

Monitoring

Pelleting equipment transforms powdered, mashed, or grounded material into a denser cylindrical shape. Pellet processing compresses the fine material against a perforated die, where it will be shaped and cut. Although granulating and extrusion also produce pellet-like products, manufacturing pellets is a distinct process.

Pelleting

Widely used in the construction industry as filling materials, calcium carbonate is usually made from pulverized limestones. As a result, vibration and noise are typical issues during CaCO3 powder production processes, especially during grinding. Therefore, it is essential to have a classifier milling system to ensure low noise and low vibration while achieving the maximum particle fineness required in CaCO3 powder production.


<h2>Mill for fine grinding and drying of soft to medium-hard minerals</h2>
The Pendulum Mill PM by NEUMAN &amp; ESSER is a roller mill used for fine grinding and drying soft to medium-hard materials such as clay, bentonite, limestone, and many other minerals. It is a robust and durable design of combined grinding, de-agglomeration, drying, and classifying system.

The mill consists of a sturdy cast, mill housing, and a rotor with a crosshead. The grinding roller travels on the rings, whose centrifugal action against the grinding ring reduces the minerals into finer sizes. Rotating shovels guide the particles from the mill bottom to the grinding zone. The air system then transports the ground particles to the classifier, where it rejects coarse particles and sends them back to the mill for further grinding. The speed of the classifier can be adjusted to meet the required particle size and distribution. Finally, a downstream collector receives the particles with the necessary final degree of fineness.

The Pendulum Mill PM can achieve narrow particle size distribution with an upper particle size ranging from 10 μm to 1,000 μm (1,250 to 18 mesh). The mill capacity ranges from 0.5 t/h to 150 t/h and can process up to 35% humidity material.

Grinding and drying of CaCO3

Recovered Carbon Black (rCB) can be recycled back to the tire production chain and serves as a usable material in the manufacturing of rubber products such as conveyor belts. The main challenge in recycling tires for recovered carbon black of versatile use is refining the pyrolyzed tire materials from various feedstocks to achieve consistent fineness. Typically, an efficient grinding, milling, and classifying system are required to ensure the desired fineness of rCB and increase its value.


<h2>Classifier mill for superfine grinding and classifying process</h2>
The Impact Classifier Mill ICX by NEUMAN &amp; ESSER is suited for dry grinding by combining extra-fine grinding with high-precision classification in a single assembly. During grinding, rapidly moving grinding tools convey feed materials into the liner at variable speeds and crush them. The integrated classifier separates coarse particles carried via airflow. Coarse materials rejected from the classifier re-enters the grinding zone for further reduction. The ICX can achieve particle size top cut from 5 µm to 50 µm. It also enables high throughput rates with high energy efficiency and the capability to process mill capacities ranging from 10 kg/hr to 20,000 kg/hr.

The direct drive uses a VFD-controlled motor; this avoids using a gearbox and oil supply in the rotor. As a result, the ICX can provide easy operation, low maintenance, and low energy consumption by using this design.

When grinding potentially explosive dust such as carbon black, a pressure shock-resistant classifier mill is pressure-resistant up to 11 bar. The NEA ICX is also compatible, and other ATEX-compliant systems can be attached to it.

Classifier mill for recovered carbon black

When producing customized flakes, pressed cakes, or other oilseed products, the oilseed preparation value chain differs from one seed to the other. For example, soybean treatment asks for different processing compared to a sunflower seed or rapeseed.


<h2>Cleaning and dehulling seed for further processing in extraction plants</h2>
An oilseed preparation plant by Andreotti Impianti has a specific sequence of activities that meets the specific business needs of the following process plants of, for example, biofuel production. First, depending on the type of seed processed, the preparation plant handles the weighing of the seeds to stabilize the flow at the plant's inlet. The process then continues with removing any coarse particles from the raw material, and further cleaning consists of destoning where stones and other impurities are removed. After this, the material is then conditioned to reduce the viscosity and adjust the moisture content to desired levels. The oilseeds now need to be further reduced in size, which happens by cracking them. Finally, the seeds are dehulled to modify the final meal protein content, leaving a material with a higher protein density.

Take, for example, sunflower seed processing. The dehulling directly impacts the protein levels of the end product for this type of seed. Therefore, there is the option for one-stage or two-stage dehulling, meaning that for the one-stage dehulling, the product contains less than 16 percent residual hulling fragments. The dehulling process can reduce this percentage to 11 percent with a second round, which will lead to an even higher protein level in the dehulled product.

The main goal of the preparation plant is to have the raw material, the seeds ready and modified for further processing by solvent extraction or mechanical pressing. After dehulling, as mentioned above, seeds can be flaked to improve extraction performance for solvent extraction in an extraction plant. In addition, sunflower seed and rapeseed need to be pressed to improve extraction performance. Other process steps in the preparation plant might include milling to homogenize the size of the meal and pelleting for the logistics of the final product.

Oilseeds preparation plant

Industrial cleaning equipment is used to wash or disinfect machinery and the production/warehouse area. It may also be used to sterilize the product, equipment, tools, floor or work surfaces and to purify or clean the product by removing impurities. Choosing a suitable cleaning system depends on the type of product or equipment to be cleaned, the sensitivity of the product to heat, pressure, and chemicals, and the level of sterility desired.

Cleaning

Almost all manufacturers will require industrial storage systems and solutions at some point during their production process. The raw materials that go into your products need dedicated storage solutions to protect them from spoilage and contamination before they enter the manufacturing cycle. Storage usually refers to particular storage space. For example, having enough warehouse storage. Or clearing out a production facility for more floor space.  However, in this case, we are referring to the equipment and solutions that make storage manageable and easier. Such equipment includes solutions such as storage racks, pallet racks and shelving systems. These are just some of many storage options available to manufacturers. Advanced technology facilitates the management of heavy duty and high density tank and silo systems by automating the delivery system and linking it with the rest of the production line.

Storage

High-quality powder coatings are often required to manufacture equipment, appliances, and vehicles to ensure product durability and longevity. A combined dry grinding and classifying system can significantly help to improve the quality of powder coatings production by providing steep particle size distribution. To achieve the finest uniform powder coatings, the mixture of pigment, polymer resin, and other additives must be finely pulverized.


<h2>Classifier mill to grind brittle material dry, free-flowing, and fine powders</h2>
The Impact Classifier Mill ICM by NEUMAN &amp; ESSER is designed for grinding brittle material to superfine particles such as materials for powder coatings. It combines efficient impact grinding and precise classification technology. During impact grinding, grinding tools throw feed materials into the liner and crush it. The classifier separates coarse particles and sends them back to the mill’s grinding zone for further grinding. It effectively achieves grinding cuts and narrow particle size distribution of 20 μm to 1,000 μm. The throughput of the various mill sizes and designs can range from 10 kg/hr to 20,000 kg/hr. In addition, the large grinding chamber has cooler temperatures that result in lower fines generation.

The ICM employs direct drive technology, a type of permanent-magnet synchronous motor. It removes using a gearbox and oil supply in its rotor, making the mill easy to operate and clean. In addition, the mill is pressure shock resistant up to 11 bar, a must when grinding for powder coatings.

Classifier mill for powder coating

After crushing and drying mined bentonite, this clay mineral is usually processed through a grinding mill into powder form. To maximize the capability of bentonite powder in hydration and water absorption, a combined milling and drying system with a higher lifetime of wearing parts is required to achieve desired fineness and product quality.


<h2>Mill for grinding and drying soft to medium minerals</h2>
The Pendulum Mill PM by NEUMAN &amp; ESSER is a roller mill used for fine grinding and drying minerals such as bentonite, clay, limestone, and others. It combines grinding, de-agglomeration, drying and classifying, making it an extremely robust and durable design.

The mill consists of a sturdy cast, mill housing, and a rotor with a crosshead and pendulums whose rollers run against a grinding ring crushing the bentonite material into fine sizes. Air transports the materials to the grinding zone through channels and rotating shovels. Both fine and coarse particles enter the classifier, where it separates coarse particles and sends them back to the mill for further grinding. The classifier speed can be adjusted to meet the requirements that come with the desired particle size distribution. Finally, the downstream collector receives the particles with the required final degree of fineness.

The Pendulum Mill PM can achieve upper particle sizes ranging from 10 μm to 1,000 μm (1,250 to 18 mesh). The various mill capacities can receive input quantities ranging from 0.5 t/h to 150 t/h and process feed material moisture of up to 35%.

Grinding and drying of bentonite

<span style="font-weight: 400;">The first step of producing almost any kind of chocolate starts with grinding cocoa beans to get fine liquor. In order to achieve the highest quality end product, you need to use a system that is capable of grinding down cocoa beans into smooth liquor while preserving the aroma, flavour, and quality of paste.</span>


<h2>Grind cocoa beans into fine cocoa paste</h2>
<span style="font-weight: 400;">The Vulva Cacao Grinder 40 KG MC-I by Nemisto has been specifically designed for the efficient grinding of cacao beans with the goal to extract the highest quality liquid cacao paste.</span>

<span style="font-weight: 400;">Engineered for small-scale production, with size of just 60cm x 90cm x 140cm, this 80KG stainless steel cocoa grinder has the capacity of processing anything from a single bean to 40-kilogram batches at a time.</span>

<span style="font-weight: 400;">With motors independently installed for each of the three stages, the unit provides for exceptionally uniform processing of cacao beans, ensuring the highest quality of output.</span>

<span style="font-weight: 400;">The safety of the operator is ensured through the sophisticated and safety-driven design of the unit which leaves all dangerous parts of the system out of the immediate reach of the operator. Furthermore, the control unit has a run control system that can shut the entire process down with the single click of a button.</span>

Small capacity cocoa grinder

Drying and grinding can be an important feature when trying to process products such as raw and refined minerals, organic and inorganic chemicals, food ingredients and waste streams. It is crucial to maintain particle size and consistent quality of the finished product during such processes. You will need an efficient and abrasion resistant attrition solution to pulverise and dry your product into your required particle size.


<h2>A simplified process while drying and grinding ensuring high product quality</h2>
Atritor’s Dryer-Pulveriser is able to grind and dry the product simultaneously. It is an air-swept mill that uses an air stream to efficiently process the product and controls the final particle size. It is able to process feedstocks of up to 50+mm and production capacities from 100kg/h up to 30t/h with evaporation rates up to 6,000 kilograms per hour.

The mill acts as an efficient dryer when the process air is heated using a hot air generator or waste heat from another process. It can reach an inlet temperature of up to 550ºC. Heat energy from the process can be recovered from the heated air stream. After flash drying, the product is kept cool due to evaporative cooling. The output temperature of the product is maintained accordingly to control the moisture content of the product.

The Flash drying grinder for powders is configured with a combination of variable speed rotor, hammer arrangement and fixed pins. Turbulence inside the grinding area creates attrition to reduce the particle size, which can be controlled for simple deagglomeration of the product. An internal classifier configuration can also be used to further control particle size.

The ‘A’-series is constructed with internals that are resistant to abrasion for applications that can cause high amounts of wearing to the equipment. Where the desired amount of evaporation required far exceeds the grinding duty, the ‘B’-series machine of a lighter weight, fully fabricated configuration permitting higher airflows can be used for non-wearing product or duties, as well as for for applications in which stainless steel contact parts may be necessary.

Flash drying grinder for powders

When you need to produce ultra-fine powders, the milling and drying process employed is what ensures the consistency of your product. To process minerals and chemicals, you need a machine which is powerful, flexible, simple to maintain.


<h2>Versatile and highly efficient milling and drying</h2>
Atritor’s cell mill has been constructed to produce ultra-fine powders. It is able to grind, flash dry, classify and surface coat powders at the same time. Its capacity ranges from 50 kilograms per hour to 15 tonnes per hour, with evaporation rates up to 3,000 kilograms per hour.

The feed can be dosed directly into the machine via a screw feeder or via the inlet air duct. It is then ground in a vertically mounted, multi-stage rotating rotor. Each of the rotor sections is constructed with up to 200 quick-change blades. There is also the possibility for a classifier which is mounted at the discharge section to ensure that oversized feed particles are either discarded or recirculated.

The mill acts as an efficient dryer when the process air is heated using a hot air generator or even waste heat from another process. It can reach an inlet temperature of up to 450ºC. Heat energy from the process can be recovered from the heated air stream and utilized to preheat the intake air. After flash drying, the product is kept cool due to evaporative cooling via the constant exposure of new surface areas of the product created during attrition.

In the case of minerals that require surface treatment, the cell mill provides a range of coatings and surface modifiers that can be added on the side of the machine during the milling process. It has a wide range of applications, from minerals like GCC, clay and limestone to chemicals, dyes, pigments and a wide range of food ingredients and by-products.

Milling and drying machine for fine powders

Manure fertilizer needs to be made marketable by making them visually attractive, with high level of hygiene frequently required for export. A full processing line can provide a cost-efficient, start-to-end solution to form pellets, which are uniform with smooth surface and high stability of the granulate, ready for transporting.


<h2>Reliable, standardised system focused on processing poultry manure</h2>
Dorset’s Pelleting line is a fully equipped standardised pelleting line, dedicated for volumes of 400 Kg/H or 800 Kg/H. It is a full processing line, mounted on a steel platform. It includes all the parts required for pelleting dry poultry manure: a crusher, dosing system, pellet press, dust sieve, cyclone, sanitation and a cooling system.

Most wastewater treatment plants processing slurry use techniques that result in waste streams which by itself have little or no value and are difficult to process further. However, this pelleting line for manure fertilizer combines these substances for effective and configurable production of green chemical fertilizer. This results in a customer specific supply of fertilizer to the end-user.

Pelleting line for manure fertilizer

Compaction machines and technologies crush or compress materials and make them denser. Compaction can be used to simply save space or to shape materials into a desired form or format. Tablets, pellets, or briquets are formed by compactors but powder presses also help form cosmetic eyeshadow or face powder.

Compaction

Scraps are an inevitable byproduct of biscuit and bread production. While these can be sold on as scraps to recoup some of the loss, this involves collection and storage and additional handling. By integrating a rework system into your biscuit or bread production line you can turn scraps into powder ingredients that can be fed straight back into the line, increasing efficiency and reducing costs.


<h2>Low-cost reworking solution for biscuit and bread production lines</h2>
The Biscuit Re-Work system from Cepi is an automatic biscuit scrap processing, storage and pneumatic delivery system designed specifically for the bakery industry.

Offering excellent returns on a moderate investment, the Biscuit Re-Work system operates via manual loading into a high-efficiency cutting mill.  Pneumatic conveying takes the milled powder to a self-contained holding vessel where it can then be sent for packing or returned to your biscuit line.

Features include a built-in magnet to remove metallic contaminants, dust filtration for the storage tank, and all-stainless steel construction for durability and easy clean down.

Automatic rework system for biscuit and bread scrap

A loading system feeds your continuous or batch processing machine with the specified material or item in line with the flow of production. Loaders transfer the articles from one stage of preparation to the next with uniformity and accuracy.

Loading

Pharmaceutical and cosmetic creams, ointments, gels and pastes can deliver a wide range of active ingredients. Particle size is a key factor in determining the effectiveness of the emulsion in delivering maximum skin absorption of the ingredients. For high-quality, small batch ointment production, a dedicated, easy-to-use, yet low-cost mill is the ideal solution for achieving optimum particle size.
<h2>Easy to use triple roller mill for ointments and creams</h2>
The MPC Ointment Mill from Multigel is a small form-factor mill for fine trituration and homogenization of ointments, creams, pastes, gels and suspensions.

This mill has been designed specifically to reduce the particle size for increased product quality through better absorption into the skin.

The MPC has three specially-designed ceramic rollers made from aluminium oxide (Al2O3 99.7%). These provide fine trituration while being extremely easy to clean with non-abrasive detergent and alcohol.

To assist with compound placement and reduce wastage, two side guides are fitted on top of the rollers. Once passed through the rollers, the compound is removed by a scraper plate and falls down a collection chute. Multiple compound runs are possible until the desired level of trituration has been achieved.

Benchtop mill for ointments

The production of high-quality chocolate from the bean can often be out of the reach of small producers, who often have had to rely on using chocolate produced by others to create their own confections. An affordable, small scale bean to bar machine can allow small-scale producers to create handcrafted chocolates to their own recipe, adding significant value to their product by selecting specific beans, including single-origin.


<h2>Compact machine to produce high-quality chocolate directly from cocoa nibs</h2>
The Multiprocess C from Tecno 3 is the first small-scale machine to produce chocolate directly from nibs. The unit combines all the processes for chocolate production in one easy-to-operate unit. Process steps include nib grinding, ingredient mixing, ball milling, conching, tempering, and refrigeration. Ease of use and maintenance is ensured by the lack of any pumps or connection pipes, making cleaning straightforward. The entire machine is constructed of AISI 304 stainless steel for strength, longevity and hygiene.

The bean to bar machine is available with 3 mixer sizes allowing the production of batches of 5kg, 25kg or 50kg of chocolate. As well as high-quality bars of dark, milk or white chocolate, the Multiprocess C can also produce Gianduja chocolate, chocolate spreads, nut pastes, and creamy chocolate fillings, providing even more flexibility to small-scale confectionery producers. Designed to be easy to use by a single operator, the Multiprocess C is fitted with a Siemens touch screen HMI to adjust recipe parameters and to monitor the chocolate production process.

Entry level bean-to-bar machine

Conching is a critical step in the manufacturing of chocolate. In this phase, your chocolate mix is agitated and superficially scraped by a conch, allowing the cocoa butter to separate amalgamated particles and distribute your cocoa butter more evenly. The heat generated by the process volatilizes acids improving the texture and aroma of the finished product. Early machines used vessels in the shape of a conch shell, giving the equipment its name.

Conching

Dosing systems are a line of hoppers, feeders, filling machines, and checkweighers that operate in sync to dispense materials accurately. Dosing is an essential feature of the packaging process, whether you’re filling shampoo bottles or tea bags. But dosing equipment is critical for formulations, too, particularly in the pharmaceutical and chemical industries. Imprecise dosing may cause quality degradation in the best-case scenario. In the worst scenario, it creates serious health risks.

Dosing

Enrobing your food products means coating them with additional ingredients such as chocolate, syrup, or sugar. By automating this process you produced homogeneous results and reduce wastage. Items are fed to the enrobing machine to be fully or partially covered. Following this, a blower and an agitator combine to shake any excess coating off the individual products.

Enrobing

<span style="font-weight: 400">The heating process is a step of raising the temperature of food, pharma, cosmetics, and many other types of products. You may employ different heating solutions for this process, depending on the type of product you intend to manufacture. Selecting the appropriate heater machine for your product is quite important since various products require different ranges of temperatures and different ways of heat transfer using exchangers. Industrial heating equipment varies in two ways - the type of material it can process and the reaction you want to achieve.</span>

Heating

<span style="font-weight: 400">The molding process is often included in bakery products. Utilizing molding equipment guarantees a uniform shape, weight, and size. The molding machine first gently flattens the dough mix by going through a sheeter, where a series of rollers press the thin piece of dough. The sheet is then cut into the specified shape and, depending on your final product, may be rolled by using a curling chain. After the molding, other ingredients may be added before the products are conveyed for baking or freezing.</span>

Moulding

For the highest quality chocolate production, complete control of the entire process is desirable. For small scale, artisanal producers this often means sourcing raw cocoa nibs from specialist producers. By investing in a dedicated, small form factor cocoa bean processing line, small scale producers can now take complete control of the chocolate production process by ensuring the cocoa beans you select are handled to your exact requirements and recipe.


<h2>Compact, space-saving machine to process raw cocoa beans for small-scale producers</h2>
The Multiprocess R from Tecno 3 is purpose-designed for the small-scale production of cocoa nibs as the first part of a “bean to bar” production process. This machine has been designed to be compact and portable, and yet it is able to dry, roast, sterilise, crush and winnow cocoa beans - all in one unit. The drying and roasting unit uses a partial air removal system to control moisture, and the roast is achieved via internal hot air circulation. Temperatures and times can be fully customised for drying and roasting times, allowing complete control of the process.

Three UV units ensure that the roasted beans are fully debacterialised. A screw feed and three belt system ensure that the beans are separated and exposed to UV on all sides, ensuring quality. After sterilization, the beans can either be removed from the process whole, or sent to the crusher and winnower, where the nibs are sieved into four sizes ready for chocolate production. Adding to the Multiprocess R’s flexibility, the machine can also be used to roast, peel, sanitise and crush various nuts, such as almonds, hazelnuts, and pistachios.

The entire system is constructed of AISI 304 stainless steel for strength and hygiene and is mounted on wheels for easy movement if required. Designed for single-operator use, the Multiprocess R features an easy-to-use Siemens touch screen and the entire process is visible to the operator thanks to transparent Lexan guards. It also makes an attractive sight if placed in an area where customers can see it operating.

Small scale cocoa beans processing machine

Many confectionery and bakery products use nuts as a key ingredient or decoration. The ability to accurately chop nuts into the desired size for a wide range of purposes is vital in many recipes. Traditional small-scale machinery tends to crush the ingredients, affecting quality and taste. A chopping solution provides flexibility as well as excellent product quality.


<h2>Accurate and adjustable chopper for chopping and granulating nuts</h2>
The TR100 from DSC is a versatile chopping and granulating machine for small scale production. Portable and robust, the TR100 is the ideal solution not only for nuts but also for other hard ingredients, including chocolate and biscuit.

Made from stainless steel and featuring removable feed hopper, the TR100 is easy to clean inside and out.

The machine features two pairs of individually adjustable chopping rollers, and a final pair of granite finishing rollers, again adjustable to allow a uniform final size of the product grains. Chop size can be adjusted from coarse grains down to a powder in increments of 0.1mm.

The unit has a simple control panel where the speed of the chopping rollers and finishing rollers can be individually controlled. The TR100 can utilise only one set of chop rollers if the production requires this.

Small scale nut chopping machine

When designing a new chocolate line or experimenting with new ingredients for existing processes, the ability to have a scalable roasting solution is particularly advantageous. Precise and repeatable temperature and grinding settings are necessary, and the ability to have a portable unit makes for efficient use of space a distinct advantage.


<h2>Portable roaster and grinder for lab-scale cocoa bean and nuts production</h2>
The IDB25 from DSC is a dedicated lab-line roasting and grinding solution for cocoa and nuts, with a design capacity of 15kg to 25kg per hour, depending on product and process.

This unit consists of an infrared toasting unit, a cooler/peeler unit, a grinding unit, and a sieving unit.

As well as cooling for cocoa beans, almonds and pistachios, the combined cooler/peeler can also clean toasted hazelnuts and peanuts.

The patented grinding system allows granulation without pressure or heat, retaining product quality, oils, and flavor compounds. It’s adjustable to provide grains above 4mm, 2 to 4mm, or flours of less than 2mm. In addition, it comes in all-stainless steel construction for strength and ease of cleaning.

&nbsp;

R&D roaster for cocoa beans

Sugar powder is a key ingredient in a wide range of bakery, confectionery, and patisserie products. For small-scale producers buying ready-milled Powdered sugar adds additional expense and storage requirements to your production line. A dedicated in-house small-scale sugar mill for grinding your own icing sugar can reduce ingredients costs and increase efficiency, allowing you to produce only the quantity you need.


<h2>Robust and high-quality sugar mill designed specifically for small-batch production environments</h2>
The MIA Food Tech Sugar Mill has been designed specifically for small-scale producers to make their own icing sugar from granulated sugar. The Sugar Mill offers high-quality milling and top-end components with a size of only  1000mm x 450mm x 1200mm.

As well as all sugar-contacting parts being made of stainless steel for sanitary purposes, the entire assembly is also manufactured from stainless steel. As well as making cleaning of the external parts easier, this ensures maximum robustness of construction and a long lifespan.

Simple to operate with only On and Off controls, the Sugar Mill is designed to work either in a stop/start fashion or to be operated for longer periods. When operating continuously, the Sugar Mill can process up to 35kg of granulated sugar per hour.

Granulated sugar is introduced manually into the upper hopper, which is highly polished to reduce friction to a minimum and ensure all the sugar passes smoothly to the milling blades. The output bin has an easy-open stainless steel lid, ensuring sugar dust is kept contained within the bin to improve the working environments around the machine.

Weighing only 150kg and fitted with high-quality wheels, the machine can be moved easily, allowing it to be stored away from the production area when not in use. The height of the input funnel has been specifically designed to make hand-loading comfortable for operators, and the wide opening reduces the risk of spillage and wastage.

Small sugar mill for entry level production

Decoration equipment adds the finishing touch to your industrially-prepared foods by depositing ingredients in a specified pattern on the surface of the products. Your items pass individually under a system of nozzles that lay the decorating formula precisely and uniformly. Popular in confectionery, decoration is used to differentiate products in the market.

Decorating

Many confectionery and bakery processes rely on the uniform grinding of raw ingredients such as nuts, nougat, cookie, chocolate and other small-size hard items. A modern grinder produces repeatable, consistent grinds for a wide range of raw ingredients without affecting flavour or quality.


<h2>Accurate and durable grinders for small particle down to powder grinding of hard products</h2>
The Crick-Crock Grinder from MIA Food Tech has been specifically designed for the efficient grinding of toasted nuts (including almonds, peanuts, walnuts, hazelnuts, and more), as well as other hard ingredients such as chocolate, nougat, cookies, crunchy, and other similar ingredients.

Engineered with small scale production in mind, the Crick-Crock Grinder is available in a range of sizes and capacities to suit all grinding requirements, from grain to powder.

Features of the Crick-Crock include rotary blade modules for rapid interchange and cleaning; all stainless-steel construction for longevity and ease of sanitising; product throughput of between 70 and 110kg per hour, depending on grind grain size.

Rotary blades provide an exceptionally uniform grain size while introducing minimum heat to the raw ingredients, ensuring maximum taste and flavour is carried through the grinding process.

Operator safety is ensured through the use of non-removable guards over the product entry hopper and exit chutes, and grind adjustment can be easily carried out in operation by use of the external grind adjustment knobs without the need to stop the machine or for the operator to come in to contact with moving parts.

Small scale nut grinder

<span style="font-weight: 400;">By shredding cooked cereals, innovative breakfast and snack products can be created, including single-ingredient items with healthy benefits. To achieve the highest quality and most consistent shredded products, specialist shredders with high specification are needed.</span>


<h2>High quality cereal shredder that can produce a range of shredded products</h2>
<span style="font-weight: 400;">The Baker Perkins ShredMaster Systems deliver high quality shredded cereal and snack products using best-in-class equipment.</span>

<span style="font-weight: 400;">The ShredMaster can produce a large variety of product, including multi-layered shredded wheats, 2, 3 or 4 layer corn, rice or wheat squares, and even shaped and filled products.</span>

<span style="font-weight: 400;">ShredMaster system uses pairs of contra-rotating shredding rollers. Several pairs can be used in series to lay webs of shredded grains on top of each other, forming a multi-layered sheet.</span>

<span style="font-weight: 400;">The versatility of the ShredMaster means it can produce products with up to 20 layers. It can also add fillings between the layers. Thus a variety of crunchy textures is possible, as well as enhancing health benefits with the addition of fruit or other natural fillings.</span>

<span style="font-weight: 400;">A large variety of finishing options is available, meaning that the finished shred sheets can be shaped, cut or slit into finished products ranging from bite-size pieces to larger bars.</span>

Cooked cereals shredder

A shredder is used to reduce the size of various materials through the cutting action of its contra-rotating shredding rollers or knife shafts. Industrial shredders come in many different designs, sizes, and variations. Shredders are best used for the disposal of used tires, scrap metal, car wrecks, garbage, recycling of plastics, paper, and shredding of various foods such as cooked cereals. The choice of a suitable heavy duty shredder depends on the properties of the material to be processed, the desired shred size, the size of the in feed material, and the volume of material to be processed.

Shredding

<span style="font-weight: 400;">For maximum value, a high-pressure homogenizer that’s suitable for both laboratory and pilot/small scale pharmaceutical production is the ideal choice. Full control over all process elements and 100% scalability coupled with cost-effective electric operation offers substantial cost-savings over alternative options.</span>
<h2>Cost-effective unit suited for both laboratory and pilot use</h2>
<span style="font-weight: 400;">The Mini DeBEE from BEE International is hydraulically driven homogenizer that is suitable for both laboratory use and in pilot plants or in small-scale production. Offering the highest process intensity available in its class, it will disrupt the toughest cells with the highest yield, or obtain the smallest particle size.  </span>

<span style="font-weight: 400;">With proprietary modular homogenising cell, the Mini DeBEE offers completely independent control of pressure, flow, cavitation, impact, shear and process duration. The minimal sample size of only 10ml makes it an excellent choice for R&amp;D and lab work. Because it guarantees 100% scalability, it can easily be transferred to pilot operations, or the machine itself can also be used for small-scale and batch production, offering continuous flow of up to 15 litres per hour.</span>

<span style="font-weight: 400;">PLC control with digital interface means simple operation and monitoring, with user-adjustable operating pressure from 2,000 to 45,000 PSI. Coupled with a wide range of options, this makes the Mini DeBEE suitable for application in the pharmaceutical, biotech, chemicals, cosmetics and food industries.</span>

Pilot high pressure homogenizer

Biotech equipment is used for cellular and biomolecular processing to develop products that improve our lives and the planet. With the help of specialized lab equipment, the active substance is manufactured or extracted from biological origin materials and typically produced in bioreactors by plant cells, microbial cells, yeast cultures, or mammalian cells. Cell isolation, cultivation, cell banking, and culture expansion are called upstream processes. After harvest, the production process moves into a downstream process to meet purity and quality requirements which is divided into cell disruption, purification, and polishing. Biotechnology equipment makes use of various laboratory machinery such as bioreactors, centrifuges and incubators.

Biotech

<span style="font-weight: 400;">Offering lab-scale to small pharmaceutical production scale output for in one unit means maximum cost-benefit when acquiring a homogenizer. Capable of achieving a range of processes including cell disruption, particle size reduction, creating stable nano/micro emulsions and working with polymers and liposomes, this benchtop scale unit can operate at up to 15 litres per hour capacity, yet still offer lab quality results.</span>
<h2>Air-operated, compact, bench-top homogenizer suitable for a broad range of applications</h2>
<span style="font-weight: 400;">The Micro DeBEE from BEE International is a compact, laboratory-scale homogenizer that can also be used for small-scale production. This is an air-powered unit that can process as little as a single 5ml sample, up to as much as 15L per hour, offering exceptional flexibility.</span>

<span style="font-weight: 400;">Features that make it an excellent R&amp;D machine include maximum pressure of 45,000 PSI/3100 bar (at 150 PSI, 55 CFM). In addition, the back pressure can reach 5,000 PSI/350 bar, but this is adjustable to your specific process.</span>

Micro DeBEE is simple in operating, and exceptionally easy to maintain and clean (with no disassembly required), adding further to the value proposition.

High pressure air powered laboratory homogenizer

<span style="font-weight: 400;">It’s vital that small units for experimentation can scale up with 100% accuracy. Ease of use, reliability and simple maintenance means increased work efficiency, and rapid cleaning and suitability for sanitary uses increase flexibility and improve return on investment.</span>
<h2>Cost-effective benchtop homogenizer with reliable and consistent process for R&amp;D</h2>
<span style="font-weight: 400;">The Nano DeBEE from BEE International is a market-leader in laboratory-scale homogenizers. Designed for maximum flexibility, the Nano DeBEE can be used for a range of procedures including cell disruption, particle size reduction, nano/micro emulsions and nano/micro dispersions. Despite the minimum sample size of only 5ml, the results obtained from the DeBEE are guaranteed 100% scalable to production processes.</span>

<span style="font-weight: 400;">Offering excellent value for money, the Nano DeBEE can operate at up to 45,000 PSI of pressure and yet it is simple to clean and maintain and it’s suitable for sanitary applications where required. A further major benefit is that DeBEE will provide new staff training for the lifetime of the product.</span>

High pressure electric laboratory homogenizer

<span style="font-weight: 400;">For any industrial pharmaceutical process that relies on high pressure homogenization it’s vital that the equipment used is robust enough to cope with the demands of continuous operation. More than this, modern production demands high levels of process control and automation, as well as seamless integration with plant controls and providing results that satisfy the highest regulatory demands.</span>
<h2>Homogenizer offering the highest level of automation, compliance and capacity</h2>
<span style="font-weight: 400;">The DeBEE 4000 series from BEE International is the company’s top-of-line homogenizing solution for high performance situations. Designed from the ground up to achieve the best results as efficiently as possible, the DeBEE 4000 uses DeBEE’s proprietary homogenization technology for unequalled results, coupled with a hydraulically driven vertical intensifier pumps with a slow stroke rate to provide higher pressure and higher process intensity, all with lower maintenance costs.</span>

<span style="font-weight: 400;">Featuring a PLC with bespoke HMI software and full-colour touch screen, the DeBEE 4000 offers easy access to several features including security modes and authorisations, integrations with plant controls using network data gathering, and dynamic visual schematics for at-a-glance system status and component parameters.</span>

<span style="font-weight: 400;">The DeBEE 4000 features a fully sanitary design making it ideal for pharmaceutical and biotech production, as well as use in the chemical industries.</span>

High pressure industrial homogenizer

<span style="font-weight: 400;">Biotech and pharmaceutical development programs often require a mixing method that achieves both particle size reduction and complete cell lysis. When piloting production systems, it’s vital that you have complete control over the pressure to accommodate all cell types, and that the results of testing are completely scalable to full production.</span>
<h2>High-pressure homogenizer offering all configurations</h2>
<span style="font-weight: 400;">The DeBEE 2000 from BEE International is a complete pilot solution for high pressure homogenization in a highly compact format. Offering user-adjustable pressure control from 5,000 to 45,000 psi, the unit is suitable for a wide range of pharmaceutical and biotechnology applications and its modular design means lower costs of maintenance and repair.</span>

<span style="font-weight: 400;">This pilot unit also offers a wide range of options to suit all process and budget requirements, including Dual Feed, Dual Jet, control of cavitation, shear and impact and secondary additive feed for particle synthesis.</span>

<span style="font-weight: 400;">PLC control and HMI touch screen provide simple monitoring, and the unit is designed to be easily cleaned (Clean in Place) and portable.</span>

High pressure pilot homogenizer

Silos, hoppers, bins, and other containers can build up a layer of powdered product on the internal walls. A mechanical shock is required to dislodge this layer for processing. Difficult to discharge materials may also need a shock to improve the flow.


<h2>Remove material build-up on sidewalls with air shocks</h2>
Air Shocking Hammer (ASH) from GVF Impianti helps remove layering of powdered material on the internal walls of silos, bins, and hoppers. It delivers an impact comparable to that of a hammer to remove the layered material. The ASH System is preferred to the normal vibration equipment because it does not unnecessarily stress the welded joints of the bin. It has very low air consumption and is virtually maintenance-free. ASH systems are used to improve the flow of difficult-to-discharge materials. They are suitable for silos, hoppers, and bins containing powders. They are also used to completely remove the product from the vessel when switching products.

&nbsp;

Airshocking hammer

When your raw materials include agglomorated suspensions of grainy or crystalline solids and your process needs a steady, consistent flow of smaller particle sizes you need a high performance mill that is both powerful and flexible.  Furthermore, to ensure an efficient facility and maximum machine up time, the equipment should have a minimal footprint and be easy to clean.
<h2>Powerful and consistent milling of tough particles and viscous mixtures</h2>
IKA's MKO 2000 is a high-performance inline cone mill capable of performing wet and fine milling of tough and grainy or crystalline raw materials. The MKO 2000 is especially suitable for the de-agglomeration of suspensions. Excellent dispersing performance allows the IKA Cone Mill MKO 2000 to be used for continuous processes, providing a narrow distribution range of ground particles in a single pass.

For challenging milling tasks the cone mill can be installed into a recirculation loop with a working vessel by means of tube connections.  The gap between the conical shaped rotor and stator is infinitely adjustable allowing for excellent control of particle and droplet size.  Rotation speed and the resultant dispersion effect are also adjustable.  the unique conical milling head geometry also allows excellent grinding performance while the rotor and stator tools are never in contact with one another.  This, together with the extremely tough and high quality surface finishes on the tools, prolongs life and reduces contamination of the product due to machine wear.  The units are designed for easy and reliable scalability and sizes are available with flow rates from 150 to 6000 liter per hour.

Cone mill machine

For creating extremely fine emulsions and high quality dispersions a high pressure homogenizer is often chosen.  These machines use pressure shock to create very even distributions of extremely small particles.  They are; however, limited in their available flow rates and their ability to handle tough agglomerations of solids.  For these applications where a high pressure homogenizer cannot handle the raw materials or provide enough throughput, a colloid mill is often the better choice.
<h2>Extremely high quality dispersions of consistently sized particles with a very high throughput</h2>
The IKA MK 2000 is a high-performance inline colloid mill capable of performing wet and fine milling of tough and grainy raw materials. The MK 2000 is especially suitable for the production of colloidal solutions or extremely fine emulsions and suspensions. Excellent dispersing performance allows the IKA Colloid Mill MK 2000 to be used for continuous processes, providing a narrow distribution range of ground particles in a single pass. For challenging milling tasks the colloid mill can be installed into a recirculation loop with a working vessel by means of tube connections.

The conical geometry of the milling tools enables an axial displacement of the stator for an infinite adjustment of the milling gap. This allows influencing the dispersing effect, particularly regarding tasks with variable raw materials.

As neither the rotor nor the stator is slotted throughout, the probability of particles passing through the generator untreated is negligibly small. These collective features enable the IKA Colloid Mill MK to achieve the finest particle size reduction, thereby contending with a high pressure homogenizer by attaining similar dispersing results at higher flow rates.

The machines are designed for easy and reliable scalability and sizes are available with flow rates from 200 to 80,000 liters per hour.

Colloid mill

For products of medium viscosity and relatively consistent particle size such as honey, cremes, and some plastics, a simple, low cost mixing machine is useful to ensure even dispersion.  The most efficient production plants take advantage of such equipment in continuous production processes to minimize required floor space and serve double-duty as mixing and pumping/transfer equipment.
<h2>A basic effective mixing machine with transport pump capabilities and low cost</h2>
The lower-priced ULTRA-TURRAX UTL 1000 machines from IKA are particularly multifunctional and are used for the mixing, dispersing (emulsifying/suspending) and homogenizing of solid and liquid substances up to viscosities of several thousand mPa·s, such as honey, plastic masses and crèmes. The mixing components are fed into the machine at the inlet connection. The materials are mixed, homogenized and then discharged from the machine via the outlet connection. The economic dispersing machine does not have automatic suction, but does have a conveyor height of up to 20 meters.  Units are available with flow rates from 4.800 to 125.000 liters per hour.

&nbsp;

Economic dispersing machine for emulsions and suspensions

Dispersing systems are used to produce emulsions of two immiscible liquids or dispersions of solid particles in a liquid medium. The mixers generally operate on the rotor/stator principle and apply a high shear force on the suspended particles to break them down. The choice of a dispersion mixer depends on the physical state of the material being dispersed, the continuous or batch nature of the process, desired particle size, and the viscosity of the mixture. Dispersion mixers are widely used in the food industry for the dispersion of solid ingredients in oil or water and in the coatings industry for the dispersion of pigments.

Dispersing

An emulsifier is used to mix two immiscible liquids. Heating or cooling requirements during emulsification, overpressure or vacuum requirements, the need for wall scrapers, design of the mixing head, the viscosity of the liquids, and the desired droplet size are all important considerations when selecting an emulsifying system. Emulsifiers are typically used in the food industry for the production of batters, creams, and sauces, in the pharmaceutical and cosmetics industry for the production of creams and lotions, and in the chemical industry for the production of paint and other emulsions.

Emulsifying

Equipment operating under the rotor/stator principal is often employed when more traditional methods of stirring cannot achieve desired results. High performance continuous dispersing equipment is needed to achieve desirable results for almost any mixing process in circumstances where other machines fail.
<h2>Rotor/stator mixing in a robust and simple package that is easy to clean</h2>
The IKA ULTRA-TURRAX UTL 2000 is inline high-performance single-stage dispersing machine used for the production of emulsions and suspensions. The UTL 2000 uses the rotor/stator principle and is best suited for continuous applications that cannot be accomplished using conventional stirring methods.

During the full continuous process the components to be mixed are fed into the machine at an appropriate rate through various inlet connections. These components are then thoroughly mixed, dispersed or homogenized within the machine and discharged from the machine through the outlet. Thus, all particles or droplets are treated producing a narrow particle or droplet size distribution with minimal concentration/quality variations. Additionally, the UTL 2000 creates a pumping action which can be used for transfer purposes at low to moderate viscosities with a maximum of about 20 m (ca. 2 bar).

The machines are designed for easy and reliable scale-up and sizes are available with throughput from 50 to 125.000 liters per hour.

Continuous milling solutions

Which continuous milling solutions technology do you need?
