Industrial drying machines are designed to remove moisture from your product. But the drying process must cater to variations in the state of matter and molecular structure of the input material. Industrial dryer technology exploits the modes of heat transfer (convection, conduction, radiation, evaporative cooling) to control the moisture content.

Drying

Flour processing technology has changed drastically since the days of the millstone pulled by a mule. But demand for more refined flour means that the production process is now slower than with more rudimentary techniques. When mixed with water, protein in wheat flour form an elastic gluten structure, giving bakery products their irresistible fluffiness.

Flour

Flash drying refers to the removal of moisture by a stream of hot gas that goes through a stream of small particles that moves in the opposite direction. When drying large quantities of bulk powders, it can be important to better control the output characteristics of the powder. For this, combining drying, milling and classifying steps in one piece of equipment can be beneficial.


<h2>More control in your flash drying system</h2>
The Micron Dryer flash dryer, Drymeister® (DMR-H) from Hosokawa, can dry temperature-sensitive products, safely, even under increased temperatures, in a matter of seconds. Process parameters like classifier speed and outlet temperature can be adapted to control moisture content and particle size of the end product. The drying system is very flexible, handling moisture content fluctuations from a few % up to more than 80% in suspensions, slurries, pastes, dough, filter cakes and wet powders. The Drymeister® requires 75% less space and uses about 30-40% less energy per kilogram of evaporated water than conventional methods. The Flash combines drying system can be used in different industries such as the food industry, the chemical industry with applications in products such as pesticides, inorganic pigments and fish feed.

Flash drying system

Purposely focused on the indirect heating and drying of slurry, filter cakes, powders, pastes and granulates at a high speed - Dispersing liquids quickly and transforming products such as filter cakes and slurries from centrifuges, wet solids from decanters and press cake after press filtration into dry powders are among its striking features.


<h2>Continuous paddle dryer for rapid and effective indirect drying</h2>
This continuous paddle dryer from Hosokawa Micron is a high-speed dryer. It consists of a fixed cylindrical chamber with an eccentric agitator inside and two independent movements, perfectly capable of rotating on its own axis and tangentially to the cylindrical chamber too.

It has a patented jet rotor design, which allows the injection of a gas or liquid through the paddles and into a thin layer of material as it spirals along the cylindrical wall of the unit. This continuous paddle dryer is designed to be utilized with a variety of heat sources and for other numerous applications, not to mention its speed and effectiveness.

&nbsp;

Continuous paddle dryer

Enable vacuum, atmospheric and pressurized processing of a variety of materials such as powders, filter cakes, pastes and viscous slurries, especially when they are brittle and/or heat sensitive.


<h2>Fast-drying in a compact, multi-functional design</h2>
The Conical Paddle Dryer from Hosokawa Micron is a vertical, centrally-driven dryer that combines extremely fast drying rates with a compact design. This combination of several processes in one vessel offers savings on investment costs, labor and space.
Originally designed for vacuum drying of solid-based materials, but can be used in a wide range of other applications requiring thermal processing or vacuum treatment of solids.
<h4></h4>

Vertical paddle dryer

When you need to produce ultra-fine powders, the milling and drying process employed is what ensures the consistency of your product. To process minerals and chemicals, you need a machine which is powerful, flexible, simple to maintain.


<h2>Versatile and highly efficient milling and drying</h2>
Atritor’s cell mill has been constructed to produce ultra-fine powders. It is able to grind, flash dry, classify and surface coat powders at the same time. Its capacity ranges from 50 kilograms per hour to 15 tonnes per hour, with evaporation rates up to 3,000 kilograms per hour.

The feed can be dosed directly into the machine via a screw feeder or via the inlet air duct. It is then ground in a vertically mounted, multi-stage rotating rotor. Each of the rotor sections is constructed with up to 200 quick-change blades. There is also the possibility for a classifier which is mounted at the discharge section to ensure that oversized feed particles are either discarded or recirculated.

The mill acts as an efficient dryer when the process air is heated using a hot air generator or even waste heat from another process. It can reach an inlet temperature of up to 450ºC. Heat energy from the process can be recovered from the heated air stream and utilized to preheat the intake air. After flash drying, the product is kept cool due to evaporative cooling via the constant exposure of new surface areas of the product created during attrition.

In the case of minerals that require surface treatment, the cell mill provides a range of coatings and surface modifiers that can be added on the side of the machine during the milling process. It has a wide range of applications, from minerals like GCC, clay and limestone to chemicals, dyes, pigments and a wide range of food ingredients and by-products.

Milling and drying machine for fine powders

Find production technology for Flour drying, and connect directly with leading machine manufacturers worldwide

Flour drying

Which flour drying equipment do you need?

Flash drying system

Continuous paddle dryer

Vertical paddle dryer

Milling and drying machine for fine powders
