Rotary turbine vibrators for bulk solids discharging

Enhance the efficiency of material handling with high-speed, low-noise turbine vibrators designed to facilitate bulk solids flow in production processes, ensuring seamless discharge and loading operations.

Facilitates Vibration, Compaction, and Material Flow

The OT Series from WAMGROUP features Rotary Turbine Vibrators crafted for diverse industrial applications, ranging from concrete to food processing. Utilizing a high-frequency, low-amplitude working principle, these vibrators ensure continuous operation to aid in material flow, compaction, and bulk solids handling efficiently. Specializing in high-speed vibration, they are integral to production lines in sectors including construction, pharmaceuticals, and heavy industries, tackling challenges in material discharge and loading. Designed for automated systems, the OT Series offers seamless integration with PLC-controlled setups. Energy efficiency is enhanced with optimized operational mechanisms, reducing noise while maintaining centrifugal force. Available in various sizes, the aluminum-cased vibrators meet ATEX EX II 2DG cT(x) certification, suitable for hazardous environments. Maintenance is simplified with robust construction and engineering support available for custom configurations, ensuring a durable solution for high-demand operations.

Benefits

  • Enhances operational efficiency with high-speed, continuous vibration.
  • Lowers noise levels while maintaining high centrifugal force, improving workplace conditions.
  • Supports safe operations in explosive environments with ATEX certification.
  • Integrates easily into automated production lines, reducing manual intervention.
  • Customizable configurations optimize performance across various industrial applications.

General


Applications
Bakery,Noodles,Cosmetics,Pesticides,Chocolate,Insecticides,Detergents,Glass,Spices,Rubber,Cocoa,Animal feed,Pasta,Pet food,Sugar,Convenience food,Varnish,Biscuit,Rice,Plastics,Resins,Baby food,Salt,Fertilizers,Pharmaceuticals,Beverages,Steel,Fish food,Paint,Coffee,Flour,Iron,Breweries,Concrete
End products
Organophosphate pesticides,Infant formula,Wheat flour,Nitrogen-based fertilizers,Graham crackers,Ready-mixed concrete,Rubber tires,Curry powder,Jasmine rice,Pellet animal feed,Cocoa powder,Canned soup,Steel beams,Dry dog food,Fish pellets,Croissants,Soda-lime glass,Roasted coffee beans,Polyethylene sheets,Pyrethroid insecticides,Penne pasta,Milk chocolate,Liquid laundry detergent,Lager beer,Granulated sugar,Ramen noodles,Cast iron,Alkyd paint,Facial cream,Carbonated soft drinks,Polyester resins,Iodized table salt,Epoxy varnish,Paracetamol tablets
Steps before
Material Storage,Material Conveying,Weighing,Mixing
Steps after
Compaction,Form Setting,Packaging,Loading
Input ingredients
bulk solids,material flow,explosive environments
Output ingredients
high centrifugal force,low amplitude high frequency vibration,silent operation,aided material flow
Market info
WAMGROUP is known for its expertise in manufacturing bulk material handling and processing equipment, including screw conveyors, dust collectors, and valve systems, with a strong reputation for innovation, quality, and global market presence.

Technical Specifications


Vibration Amplitude
Very low
Vibration Frequency
High
Operating Pressure
2 to 6 bar (29 ~ 87 PSI)
Working Temperature
Up to 120 °C (250 °F)
Material
Aluminium casing with a black cover
Size Variants
Twelve different sizes
Compliance
ATEX EX II 2DG cT(x)
Noise Levels
Silent operation

Operating Characteristics


Working mechanism
Rotary turbine with eccentric weights
Vibration amplitude
Very low
Vibration frequency
High frequency
Noise level
Silent operation
Operation pressure range
2 to 6 bar (29 ~ 87 PSI)
Operation temperature
up to 120 °C (250 °F)
Environment suitability
Explosive environments
Use in explosive environments
ATEX EX II 2DG cT(x) compliant

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm


ATEX certification
EX II 2DG cT(x)

Physical Characteristics


Machine footprint
Compact design
Material
Aluminium casing with black cover
Shape
Rotary Turbine
Size
Twelve different sizes available
Noise Level
Silent operation
Explosion Proof
ATEX EX II 2DG cT(x) compliant
Temperature Range
Up to 120 °C (250 °F)
Working Pressure
2 to 6 bar (29 ~ 87 PSI)
