Rotary ball vibrators for bulk solids discharging

Ideal for enhancing material flow, this equipment efficiently handles fine powders and granules, ensuring smooth discharge and compacting applications, even in challenging environments.

Compacts and Discharges Bulk Solids Efficiently

The S-series Rotary Ball Vibrators from WAMGROUP are engineered for optimal performance in bulk solids processing. Utilizing a high-frequency, low-amplitude vibration generated by an internal ball moving along an eccentric guide, these vibrators excel in compacting, discharging, and material flow aid applications across various industries, including construction, chemical manufacturing, and food processing.

They are particularly effective with fine powders and granular materials like powdered milk, granulated sugar, and silica sand. Operating at a pressure range of 2 to 6 bar with oiled air, these vibrators ensure economical use of energy resources. Constructed with a durable blue aluminum body and galvanized steel cover, they are available in eight sizes to accommodate different processing capacities.

Certified for explosive environments (ATEX EX II 2DG cT(x)), the S-series integrates seamlessly into both pneumatic and mechanical conveying systems, enhancing the efficiency of operations such as continuous feed processing and precise material handling. These units offer low air consumption, ease of installation, and a design that supports straightforward maintenance. Ideal for facilities requiring reliable and consistent material flow, the S-series equips you with robust support tailored to your production needs.

Benefits

  • Enhances process efficiency with low-amplitude, high-frequency vibration for faster material compaction and discharge.
  • Reduces energy costs due to minimal air consumption.
  • Ensures compliance and safety in explosive environments with ATEX certification.
  • Facilitates easy installation and maintenance, minimizing operational disruption.
  • Versatile across multiple industries, supporting diverse production needs from food processing to chemical manufacturing.

General


Applications
Pesticide,Gas,Tobacco,Building,Grain,Biscuit processing,Cosmetics,Chemical ad-mixtures,Soap,Seeds,Beverage processing,Detergents,Iron and steel,Granular materials,Insecticide,Noodle making,Glass,Chocolate processing,Spices,Fine powders,Industrial solid waste,Rubber,Resin,Cocoa,Animal feed,Fly-ash handling,Construction materials,Pasta,Pet food,Sugar,Convenience food,Varnish,Oil,Fertilizer,Plastics,Sand,Salt,Foundries,Wood,Pharmaceuticals,Bakeries,Paint,Coffee,Animal by-products,Breweries,Coking plants
End products
Antibiotic capsules,Dog kibble,Herbicide sprays,Concrete blocks,Cream-filled biscuits,Nitrogen-based fertilizers,Wheat grain,Sunflower seeds,Rubber tires,Spaghetti noodles,Craft beer,Polyethylene pellets,Cocoa powder,Wood varnish,Bar soap,Steel beams,Epoxy resin,Liquid foundation makeup,Artisan bread,Powdered milk,Espresso coffee,Chili powder,Liquid detergents,Plastic waste,Granulated sugar,Ramen noodles,Chemical additives,Acrylic paint,Organic pesticides,Refined sugar,Fly ash bricks,Petrol,Cat treats,Bone meal fertilizer,Carbonated beverages,Canned soups,Silica sand,Natural gas,Sea salt,Coke fuel,Chocolate bars,Cigars,Wooden furniture,Glass bottles
Steps before
Drying,Grinding,Material Sorting,Initial Mixing
Steps after
Compacting,Packing,Consolidation,Quality Inspection
Input ingredients
fine powders,granular materials,sand,seeds
Output ingredients
vibrated materials,compacted materials,discharged bulk solids
Market info
WAMGROUP is known for its expertise in manufacturing bulk material handling and processing equipment, including screw conveyors, dust collectors, and valve systems, with a strong reputation for innovation, quality, and global market presence.

Technical Specifications


Vibration Type
Low amplitude high frequency
Working Pressure
2 to 6 bar (29 ~ 87 PSI)
Material
Blue aluminium body with galvanized steel cover
ATEX Compliance
EX II 2DG cT(x)
Noise Level
90 dB(A)
Size Variants
8 different sizes available

Operating Characteristics


Working mechanism
Ball movement inside an eccentric guide
Vibration type
Low amplitude,high frequency
Pressure range
2 to 6 bar (29 ~ 87 PSI)
Noise level
90 dB(A)
Compliance with explosive environments
ATEX EX II 2DG cT(x)
Compact size variety
Eight different sizes
Application suitability
Fine powders and granular materials
Efficiency
Economical with low air consumption

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Product type Characteristics


Suitable for Explosive Environments
Yes


ATEX Certification
EX II 2D G cT(x)

Physical Characteristics


Material
Blue Aluminium Body
Cover Material
Galvanized Steel
Available Sizes
Eight Different Sizes

Custom Options


Size Options
Eight different sizes
Body Color
Blue
