Bioreactors for cell culture processes

Efficiently cultivate sensitive cell lines with customizable bioreactors designed to optimize aeration, mixing, and temperature control for diverse production needs, from vaccines to nutraceuticals.

Cultivates and Processes Cell Cultures Efficiently

Bioengineering AG offers custom bioreactor systems designed for precision in cell cultivation. These bioreactors use innovative aeration strategies and wide impellers to accommodate shear-sensitive cells in applications ranging from monoclonal antibody production to skincare serum formulation. Capacities range from 30 to 25,000 liters, supporting continuous production with integrated perfusion systems. The BioSCADA software allows seamless automation and monitoring, enhancing efficiency with energy-saving temperature control and gas-mixing stations. Available in stainless steel, these systems comply with cGMP standards, ensuring compatibility and corrosion resistance. For flexible operation, optional CIP systems enable efficient cleaning, minimizing downtime, while comprehensive engineering support is available for tailored configurations.

Benefits

  • Enhances production efficiency by optimizing cell cultivation processes.
  • Minimizes operational costs with energy-efficient temperature and gas control.
  • Complies with global cGMP standards, ensuring regulatory adherence in pharmaceutical manufacturing.
  • Enables quick turnaround with customizable clean-in-place systems.
  • Supports flexible production scales, from lab to pilot, accommodating diverse industry needs.

General


Applications
Homeopathy,Beverages,Food and nutritional products,Metallurgy,Fine chemicals,Nutraceuticals,Alternative medicine,Performance materials,Cosmetics,Biopharmaceuticals,Chemical,Petrochemical,Mining
End products
Carbonated beverages,Amino acids,Vitamins,Mineral water,Vaccines,Metal nanoparticles,Industrial enzymes,Insulin,Monoclonal antibodies,Protein shakes,Biopolymers,Cell culture media,Herbal tinctures,Essential oils,Skincare serum,Anti-aging creams,Dietary supplements
Steps before
Engineering and Design,Fabrication,Installation,Automation,Commissioning,Qualification,Process Control,Aeration Strategies,Media Preparation,Gas-mixing,Temperature Circuit Setup,Perfusion System Integration
Steps after
Sterilization,Data Analysis,Continuous Production,Installation of Super Skids,Spare Parts Management,Technical Support,Product Quality Assurance
Input ingredients
mammalian cells,plant cells,insect cells,viruses cultivated on cells,heat-instable media,shear-sensitive cells,adherent cells on micro-carriers,suspended cells,gas-mixing stations,sterilization strategies,auxiliary vessels for metering solutions
Output ingredients
cultivated cell cultures,continuous production with perfusion systems,processed cell culture products,high efficiency plants
Market info
Bioengineering is known for its expertise in designing and manufacturing customized bioreactors and fermenters, serving the biotechnology and pharmaceutical industries. They are reputed for high-quality, engineered-to-order solutions and innovative process technologies.

Technical Specifications


Capacity
30 to 25,000 liters
Vessel geometry
h
Aeration strategies
Gas-mixing stations,surface gassing,bubble-free gassing
Impeller type
Wide impellers with low rpm
Perfusion systems
Internal or external spin filters
Temperature control
Tech core for temperature circuits
Sterilization strategies
For heat-sensitive media
Automation
BioSCADA software
Super skids
For reducing installation time

Operating Characteristics


Automation level
SCADA
Batch vs. continuous operation
Batch / Inline Continuous
CIP/SIP
CIP 121°C / SIP 135°C
Cleaning method
CIP
Changeover time
Rapid

Material Compatibility


Corrosive resistance (e.g. acids)
Yes

Product type Characteristics


Cell type compatibility
Mammalian / Plant / Insect / Virus

Physical Characteristics


Vessel Capacity
30–25,000 liters
Typical Vessel Geometry
Height to diameter ratio
Impeller Design
Wide impellers with low rpm
System Configuration
Benchtop to pilot scale
Skid Design
Super skids for reduced installation time

Custom Options


Control panel type
Touchscreen
Integration possibilities
BioSCADA software
Automation level
SCADA integration
System configuration
Benchtop to pilot scale
Vessel capacity
30 to 25,000 liters
