Pneumatic dilute phase conveying system for powders and bulk materials

Optimize your production line’s efficiency with a conveying solution that effortlessly handles diverse powders and bulk materials, ensuring smooth integration and reliable performance in your manufacturing processes.

Transports Bulk Solids Efficiently

The Dilute Phase Pneumatic Conveying System from Gericke is designed for versatile and efficient transport of non-sensitive powders and bulk materials across diverse industries, including food, pharmaceuticals, and chemicals. It operates using a high-velocity airflow to keep particles suspended, ensuring smooth movement from silos to receiving hoppers. This system accommodates a variety of applications, such as conveying granules, flour, cement powder, and more. With an adjustable rotary valve that serves as an airlock, it offers flexible throughput control and can handle operations in both continuous and batch modes. Featuring options for hygienic design and easy cleaning, it integrates seamlessly with existing production lines and complies with key industry standards. Built for both pressure and vacuum configurations, the system is compact, requiring minimal headroom for installation. Additionally, robust construction and material options like stainless steel ensure durability and resistance to corrosion, making it a reliable choice for demanding industrial environments.

Benefits

  • Enhances operational efficiency with flexible throughput control via adjustable rotary valves.
  • Saves space with a compact design that requires minimal headroom.
  • Ensures compatibility with diverse materials, supporting numerous industrial applications.
  • Minimizes maintenance downtime with easy-clean features and robust construction.
  • Promotes safety by integrating flame propagation prevention in ATEX zones.

General


Applications
Lime,Vitamins,Steel,Snacks,Bakery,Noodles,Water treatment,Minerals,Battery production,Dairy,Animal food,Food,Chemicals,Cement,Detergents,Energy,Fragrances,Glass,Seasoning,Fly ash,Construction,Crop protection,Flavours,Pet,Rice,Soaps,Plastics,Flours,Salt,Fertilizers,Pharmaceuticals,Beverages,Environmental,Heavy industry,Confectionery,Coatings,Cereals,Gypsum
End products
Soap flakes,Protein shakes,Aspirin powder,Vitamin supplements,Lime powder,Gypsum board additives,Animal feed pellets,Effervescent tablets,Pigments,Seasoning blends,Recycled plastics,Glass fibers,Paint powders,Vanilla extract,Bread flour,Steel shot,Fish meal,Perfume ingredients,Plastic pellets,Instant coffee,Non-dairy creamers,Cornflakes,Laundry detergent powder,Cement powder,Cooked rice powder,Battery components,Milk powder,Granola,Fertilizer granules,Muesli base flakes,Table salt,Cake mixes
Steps before
Silo Loading,Big Bag Loading,Sack Tipping,Raw Material Handling
Steps after
Receiving in Hopper,In-line Sifting,Screening,Batch Distribution
Input ingredients
non-sensitive powders,non-abrasive bulk materials,grains,granules,fine flowing powders,raw materials from silos,Big Bag contents,sack tipping station materials
Output ingredients
conveyed powders,bulk solids,screened materials,materials in receiving hopper
Market info
Gericke is known for engineering and manufacturing innovative powder processing equipment, including mixing, feeding, and conveying solutions, catering to various industries. Renowned for their quality and expertise in bulk material handling, they provide tailored solutions to optimize production processes.

Technical Specifications


Conveying speed
Typically >20m/s
Conveying method
Vacuum or pressure system
Headroom requirement
Limited
Rotational speed control
Variable
Conveying mode
Continuous or batch
Conveying type
Dilute phase
Gas velocity
Typically >20m/s
Rotary valve integration
Airlock function
Screening integration
Inline sifter

Operating Characteristics


Working Mechanism
Dilute phase pneumatic
Integrated Steps
Rotary valve integration
Batch vs Continuous Operation
Continuous or batch mode
Headroom Requirement
Limited headroom necessary
Air Velocity Requirement
>20 m/s
Material Suitability
Non-sensitive and non-abrasive powders
Conveying System Design
Pressure or vacuum system

Material Compatibility


Abrasion resistance
Non-abrasive materials
Biological compatibility
Not applicable
Cleanability
Easy cleaning options available
Corrosive resistance (e.g. acids)
Not suitable for highly corrosive materials
Density/particle size
Suitable for grains,granules,and fine powders

Product type Characteristics


Material sensitivity
Non-sensitive
Bulk material type
Granules/Powders

Physical Characteristics


Footprint
Compact
Discharge method
Rotary valve
Piping system
Straight / Elbows
Installation height
Low headroom required
System design
Vacuum or pressure

Custom Options


Installation space (headroom)
Limited headroom required
Rotary valve cleaning option
Easy cleaning / Hygienic design
Rotary valve application
Heavy duty / Hygienic
