Mid-shear mixer for powders and bulk solids

Achieve ultra-short mixing cycles and superior homogeneity without the need for lump breakers, optimizing both mixing efficiency and energy consumption in your production process.

Mixes and Blends Powders, Slurries, and Liquids

The Vitomix Ribbon Screw Mixer from Hosokawa Micron combines efficiency and versatility for diverse industrial applications. It features a unique dual-ribbon design on an orbital arm, facilitating rapid and even mixing by transporting materials vertically within the vessel. This design significantly enhances batch cycle times and mixing homogeneity, crucial for processes involving powders, pastes, and slurries.

Ideal for a range of end-products like protein powder blends, sauce bases, and cosmetic creams, the Vitomix excels in blending operations without requiring lump breakers. Available in capacities from 500 to 10,000 liters, it adapts seamlessly into your production line, supported by precise liquid addition via its integrated spraying system.

Engineered for energy efficiency, the Vitomix reduces operational costs, utilizing a broad speed range of 0.4 m/s to 6.0 m/s for optimal performance. Constructed with reliability in mind, it supports continuous operations while offering quick and thorough discharge capabilities with its specially designed bottom valve.

Compliant with stringent industrial standards, the Vitomix is equipped to handle various cleaning demands with optional CIP systems, ensuring minimal downtime. Customize your mixer with options like corrosion-resistant materials and additional engineering support, tailoring the system to your specific industry needs.

Benefits

  • Enhances production efficiency with cycle times up to 8 times faster than traditional mixers.
  • Minimizes energy costs through optimized speed control and efficient power use.
  • Accommodates versatile mixing needs, reducing the need for multiple equipment types.
  • Ensures homogenous product quality without additional lump-breaking steps.
  • Integrates seamlessly into existing systems, supporting flexible process configurations.

General


Applications
Coloured products,Fats,Granulated products,Heated/cooled products,Flavoured products,Pastes,Powders,Slurries,Coating powders,Liquids
End products
Slurry paints,Cosmetic creams,Instant soup bases,Chocolate coatings,Flavoured drink mixes,Salad dressings,Sauce bases,Confectionery coatings,Protein powder blends,Powdered dairy formulations,Food colour formulations,Spice mixes,Pharmaceutical granules
Steps before
Grinding,Size Reduction,Drying,Agglomeration
Steps after
Flavouring,Colouring,Granulating,Coating,Packing
Input ingredients
powders,pastes,slurries,liquids,fats
Output ingredients
homogeneous mixture,lump-free mixture,flavoured powders,coloured powders,coated powders,granulated materials
Market info
Hosokawa Micron is renowned for specializing in the manufacturing of powder and particle processing technologies, including mixing, drying, and milling equipment. They are respected for their innovative solutions and engineering excellence in industrial engineered-to-order equipment markets.

Technical Specifications


Agitator speed
0.4–6.0 m/s
Batch size
500–10,000 litres
Transport volume
Up to 8 times more than conventional mixers
Motor power
1.1–110 kW
Vessel height
1260–3350 mm
Vessel diameter
1230–3200 mm
Height incl. motor
1590–4570 mm
Mixing technology
Nauta® enhanced
Energy efficiency
Reduces energy costs
Discharge type
Bottom discharge valve
Operation type
Batch

Operating Characteristics


Working mechanism
Ribbon screw mounted on orbital arm
Batch vs. continuous operation
Batch
Mixing speed range
0.4 m/s to 6.0 m/s
Energy efficiency
Reduces energy costs
Material handling
Gentle and mid to low shear
Transport capacity
Up to 8 times more than standard mixers
Discharge method
Fast and full discharge with bottom discharge valve
Liquid addition capability
Liquid spraying system

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Physical Characteristics


Machine footprint
Compact
Vessel volume
500 to 10,000 litres
Vessel diameter
1230 - 3200 mm
Vessel height
1260 - 3350 mm
Height including motor
1590 - 4570 mm
Discharge method
Bottom discharge valve

Custom Options


Control panel type
PLC/HMI
Liquid spraying system
Hollow axle integration with adjustable nozzles
Discharge method
Fast and full discharge with bottom discharge valve
