Commercial chocolate refiner/conche
Elevate your chocolate production with a versatile 5-in-1 solution, integrating cocoa milling, sugar grinding, and precise conching to deliver consistent, high-quality products while optimizing your production line’s efficiency.
Processes and Refines Chocolate for Consistent Quality
The Next Generation RC3000 Refiner/Conche from Hamburg Dresdner Maschinenfabriken is designed to streamline chocolate processing by integrating key functions—grinding, mixing, refining, and conching—in a single unit. With its compact and hygienically closed design, this machine is ideal for small to medium-scale chocolate, compound, and confectionery producers. The RC3000 features a specially designed shaft with adjustable grinding bars and pressure mechanisms, ensuring uniform quality in every batch. Capable of processing solid and liquid forms, it reliably handles materials like caramel pralines, truffles, and peanut butter chocolate fillings. Automated control systems, including PLC with a 10-inch touchscreen, and options such as a shear attachment for low-fat masses, enhance operational flexibility. Energy efficiency is maximized with geared motors, while temperature control and automatic conching deliver consistent results. Easy maintenance with safety access covers and EWON remote access for diagnostics ensure longevity and reliability in your production line.
Benefits
- Enhances production efficiency by combining multiple processes in one machine.
- Maintains product consistency and quality across varied batches with precise pressure and temperature control.
- Reduces operational costs through energy-efficient motor designs.
- Lowers maintenance demands with a sealed hygienic design and easy access features.
- Supports versatile production needs, handling a range of chocolate and confections.
- Applications
- Pralines,Fillings,Compounds,Coatings,Sweets,Chocolate,Truffles
- End products
- Raspberry truffles,Peanut butter chocolate filling,Mint chocolate sweets,Ganache truffles,Dark chocolate bars,Milk chocolate pieces,Caramel pralines,White chocolate chips,Yogurt-flavored compounds,Chocolate-coated nuts,Hazelnut cream filling,Almond truffles,Nougat sweets,Compound chocolate for confectionery,Milk chocolate coating for ice cream
- Steps before
- Cocoa Liquor Milling,Sugar Milling,Mixing
- Steps after
- Sterilization,Coating,Packing,Filling
- Input ingredients
- cocoa liquor,sugar,liquid materials,powders
- Output ingredients
- chocolate,compounds,coatings,pralines,truffles,fillings
- Market info
- Macintyre Probat is known for manufacturing specialized industrial machinery, particularly in the cocoa and chocolate processing industry, offering engineered-to-order solutions with a reputation for innovation and reliability in their equipment designs.
- Capacity
- 3000 Kg
- Main Drive Motor
- 55 kW
- Power Assisted Motor
- 0.552 kW
- Electric Immersion Heater
- 2-3 kW
- Length
- 3350 mm
- Width
- 2035 mm
- Height
- 2483 mm
- Net Weight
- 8200 Kg
- Automation
- PLC-controlled
- Cooling Option
- Chilled Water Inlet Solenoid Valve,1” BSP,24V DC
- Air Flow
- Electric Extract Fan for Cross Refiner Air Flow
- Automation level
- PLC / Touchscreen control
- Batch vs. continuous operation
- Batch
- Automation procedure control
- Automatic conching procedure
- Temperature management
- Automatic temperature control system
- Energy efficiency
- Geared motor assembly
- Noise reduction
- Sound Reduction Cabinet
- Loading method
- Powder and liquid loading through hopper and pipes
- Abrasion resistance
- Yes
- Biological compatibility
- Food-Grade Materials
- Cleanability
- CIP/Manual Cleaning
- Corrosive resistance (e.g. acids)
- Yes
- Density/particle size
- Variable (depending on chocolate type)
- Machine Capacity
- 3000 kg
- Length
- 3335 mm
- Width
- 2035 mm
- Height
- 2483 mm
- Net Weight
- 8200 kg
- Compact Design
- Hygienically closed
- Discharge Method
- Hopper
- Control panel type
- 10” colour touchscreen
- Integration possibilities
- Siemens Profinet Protocol
- Remote access
- EWON remote access module
- Communication options
- LAN,WIFI,3G/4G Network
- Vibration reduction
- Anti-Vibration Strip
- Sound reduction
- Sound Reduction Cabinet
