Chocolate refiner/conche system

Streamline your chocolate production with a versatile solution that combines grinding, mixing, refining, and conching in one seamless process—ideal for enhancing the quality and consistency of chocolates, pralines, and other confectionery delights.

Processes and Conches Chocolate and Confectionery Products

The Next Generation Refiner/Conche from Hamburg Dresdner Maschinenfabriken is a versatile equipment designed to revolutionize chocolate and confectionery production. This all-in-one unit seamlessly integrates the processes of grinding, mixing, refining, and conching, crucial for producing homogeneous mass in chocolate production. Equipped with a specially designed shaft and adjustable grinding bars, it ensures consistent quality across batches. Ideal for creating a wide array of products—from milk chocolate bars and pralines to ganache and nougat fillings—this machine serves chocolate manufacturers and compound producers seeking precision and efficiency.

With model capacities ranging from 500 to 2000 kg (RC500, RC1250, RC2000), it caters to both batch and semi-automatic operations. The PLC-controlled system enhances automation, offering detailed process control via a user-friendly touch screen. Energy efficiency is optimized with an IE3 electric motor and temperature-controlled immersion heating. Constructed with durable materials, it promises minimal maintenance and easy cleaning, thanks to its hygienically closed design. Optional features, such as a shear attachment for low-fat processing, further bolster its adaptability to specific production requirements. Embrace this engineered solution for reliable and efficient chocolate processing challenges.

Benefits

  • Consolidates multiple processes into one unit, optimizing production efficiency and reducing equipment footprint.
  • Ensures consistent product quality with adjustable pressure and precise temperature control.
  • Minimizes operational downtime with low maintenance, durable construction.
  • Supports diverse product needs with optional attachments for specialty chocolate processing.
  • Enhances operational control and reduces labor costs through user-friendly PLC interface.

General


Applications
Pralines,Compounds,Chocolates,Coatings,Truffles,Fillings
End products
Confectionery coatings for candy bars,Ganache fillings,Hazelnut pralines,Nougat fillings,Caramel-filled chocolates,Chocolate compound disks,White chocolate chips,Dark chocolate couverture,Milk chocolate bars,Bonbon truffles
Steps before
Loading of cocoa liquor,Sugar loading,Mixer setup,Powder loading through hopper
Steps after
Refining and conching process,Product temperature control,Homogeneous mass formation,Cooling and storage
Input ingredients
cocoa liquor,sugar,chocolate ingredients,compound ingredients,coating ingredients,praline ingredients,truffle ingredients,filling ingredients,rework materials
Output ingredients
chocolate,compounds,coatings,pralines,truffles,fillings
Market info
Macintyre Probat is known for manufacturing specialized industrial machinery, particularly in the cocoa and chocolate processing industry, offering engineered-to-order solutions with a reputation for innovation and reliability in their equipment designs.

Technical Specifications


Machine Capacity
500 Kg,1250 Kg,2000 Kg
Main Drive Motor Power
15 kW,22 kW,37 kW
Electric Immersion Power
2-3 kW,2-5 kW,2-5 kW
Net Weight
2750 kg,4750 kg,6500 kg
Length
5491 mm,6088 mm,7250 mm
Width
1086 mm,1330 mm,1700 mm
Height
1517 mm,1640 mm,2015 mm
Product Temperature Control
Using PT100 probe,4-20 mA
Automation
PLC-controlled
Processing Type
Batch processing

Operating Characteristics


Working mechanism
5 in 1 manufacturing solution
Automation level
Automatic conching procedure control
Batch vs. continuous operation
Batch
Temperature control
Automatic temperature control system
Pressure control
Adjustable pressure mechanism
Cleaning method
Easy operation and low maintenance
Energy efficiency
IE3 motors for electric drive

Material Compatibility


Abrasion resistance
High
Biological compatibility
Food grade
Cleanability
CIP
Corrosive resistance (e.g. acids)
Yes
Density/particle size
Varies depending on chocolate type

Physical Characteristics


Machine footprint
Variable based on model (e.g.,RC500
Compact design
Yes
Feed method
Loading of powders through machine hopper and two infeed pipes for liquid materials at gearbox end,DN50 flanges
Discharge method
Via hopper vent,designed to reduce volatiles,acidity,moisture
Control panel type
Operator interface by 10" color touch screen

Custom Options


Control System
Siemens,Schneider,Allen Bradley,Rockwell,Mitsubishi
Operator Interface
10" color touch screen
Automatic Temperature Control
Yes
Automatic Conching Procedure Control
Yes
Sound Reduction Cabinet
Available up to 1250Kg
Shear Attachment
Optional
Anti-Vibration Strip
Optional
