Anti-wear elbows for pneumatic conveying systems

Reduce wear and extend the lifespan of your pneumatic conveying systems with specialized pipe elbows designed for efficient material diversion, minimizing pressure loss and preventing particle breakdown. Perfect for applications requiring durable and reliable material transport solutions.

Diverts and Protects Material Flow in Conveying Systems

The EXTRABEND Anti-Wear Pipe Elbows from WAMGROUP introduce a cutting-edge solution designed to optimize pneumatic conveying across a broad spectrum of industries. Crafted from a robust SINT engineering polymer, these elbows feature a unique geometry that reduces wear by creating a buffer zone at material diversion points. This makes them particularly valuable in handling abrasive and chemically aggressive powders. Capable of integrating seamlessly into existing conveying lines, EXTRABEND elbows support both vacuum and positive pressure systems, optimizing material flow without particle degradation. They are ideal for applications that include building materials, plastics, chemicals, and food processing, delivering reliable performance with minimal pressure drop and energy consumption. Lightweight yet durable, the EXTRABEND elbows offer easy installation, reduced noise levels, and compliance with industry standards, including food-grade options for sensitive materials. With a focus on longevity and efficiency, these pipe elbows provide a durable alternative to traditional steel elbows, ensuring your operations remain smooth and cost-efficient.

Benefits

  • Minimizes maintenance costs by reducing wear through innovative design.
  • Enhances energy efficiency with decreased flow resistance.
  • Preserves product integrity by preventing particle breakdown.
  • Offers easy retrofitting into existing systems with versatile connectivity options.
  • Supports eco-friendly operations with reduced noise and self-cleaning features.

General


Applications
Granules,Rubber processing,Biscuit processing,Pesticide processing,Paint processing,Animal feed milling,Beverage processing,Chemically aggressive powders,Pharmaceuticals processing,Plastics processing,Cosmetics processing,Noodle making,Abrasive powders,Chocolate processing,Fine powders,Plastic pellets,Cocoa,Coffee processing,Cement processing,Pasta,Building materials,Detergent processing,Resin processing,Varnish processing,Soap processing,Sand,Insecticide processing,Lime processing,Gypsum processing,Salt processing,Minerals processing,Fertilizer processing,Breweries
End products
Herbicide pellets,Silicon carbide powders,Nitrogen-based fertilizers,Poultry feed,Laundry detergent powders,Rubber tires,Spaghetti noodles,Cocoa powder,Polyethylene granules,Soda beverages,Chocolate chip cookies,Hdpe granules,Epoxy resin,Portland cement,Iodized salt,Roasted coffee beans,Acrylic paint,Facial creams,Gypsum drywall,Pvc pellets,Milk chocolate bars,Talcum powder,Lacquer,Sulfuric acid powders,Slaked lime,Silica sand,Iron ore concentrate,Mosquito repellent coils,Glycerin soap bars,Aspirin tablets,Dry mortar,Ale
Steps before
Grinding,Drying,Emulsification,Purification
Steps after
Packing,Coating,Sterilization
Input ingredients
plastic pellets,granules,sand,fine powders,abrasive powders,chemically aggressive powders
Output ingredients
conveyed material without particle breakdown,diverted material flow,material buffer cushion
Market info
WAMGROUP is known for its expertise in manufacturing bulk material handling and processing equipment, including screw conveyors, dust collectors, and valve systems, with a strong reputation for innovation, quality, and global market presence.

Technical Specifications


Material used
SINT engineering polymer
Elbow design
Short radius
Application
Pneumatic Conveying Systems
Wear protection
Optimized body thickness
Connection type
PN-type flanges
Flow diversion geometry
Dead zone for wear reduction
Pressure drop
Minimized
Operating pressure
For both positive and vacuum pressure
Density phase
Suitable for dilute phase

Operating Characteristics


Batch vs. continuous operation
Inline Continuous
Automation level
Manual / PLC / SCADA
Energy efficiency
Substantial reduction in flow resistance
Wear reduction
High
Due to material cushion
Pressure drop
Minimized
Noise level
Reduced
Cleaning method
Self-cleaning

Material Compatibility


Abrasion resistance
SINT engineering polymer
Biological compatibility
FDA-approved
Corrosive resistance (e.g. acids)
Chemically resistant SINT polymer
Density/particle size
Handles sand,pellets,granules,and powders
Cleanability
Self-cleaning

Product type Characteristics


Handling capacity
Compatible with low density dilute phase systems

Physical Characteristics


Pipe Elbow Geometry
Short Radius
Material
SINT Engineering Polymer
Design
One-piece Cast
Connection Type
PN-type Connecting Flanges
Weight
Lightweight
Installation Type
Compact Design

Custom Options


Material type
SINT engineering polymer
Connecting flange type
PN-type connecting flanges
Customization for product type
Handling plastic pellets,granules,sand,or powders
Food-grade version
FDA-approved
Connecting spigot
For existing ducts
