Rotary tablet press for abrasive powders

Achieve precise tablet sizing and bilayer production, even with abrasive powders, using a robust press that enhances efficiency and minimizes wear, ensuring consistent quality across high-speed, continuous operations.

Processes Abrasive Powders into Tablets and Bilayer Products

The PERFORMA P from GEA Group is a sophisticated rotary tablet press tailored for industrial and non-pharmaceutical applications. Its unique design incorporates an exchangeable turret system, enhancing versatility by allowing quick and cost-effective changeovers. This system, along with duplicate exchangeable die discs (EDDs), minimizes investment costs while maximizing output. Capable of processing abrasive powders, the PERFORMA P is ideal for manufacturing grinding wheels, detergent pods, and automotive parts, among others.

Equipped for bilayer production, the machine features a tamping station and a robust 80 kN final compression station, ensuring high-quality output even at high speeds. Integrated dust extraction nozzles and exceptional accessibility to the compression area reduce cross-contamination and improve efficiency. The PERFORMA P accommodates various tooling options (D, B, BB, BBS, A) and can produce up to 374,000 tablets per hour, making it suitable for continuous, high-speed operations.

Its energy-efficient design operates on 3-phase power with a maximum power consumption of 11.9 kVA. Available in durable materials tailored for corrosion resistance and long-term industrial use, it supports clean, dry compressed air, and easy-to-access component cleaning.

For clients requiring specific configurations, GEA offers customization and engineering support to ensure seamless integration into existing production lines.

Benefits

  • Enhances production efficiency with quick format changeovers, reducing downtime.
  • Lowers capital expenditure by using duplicate EDDs instead of entire turret replacements.
  • Ensures contamination-free production with integrated dust extraction capabilities.
  • Supports versatile production needs, including bilayer tablets, without significant retooling.
  • Delivers high-quality compression at high speeds, ensuring reliability across diverse applications.

General


Applications
Detergents,Coffee pods,Salt tablets,Batteries,Confectionery,Industrial applications,Abrasive powders,Hard metals,Bilayer production,Nuclear fuel pellets,Catalysts,Non-pharma applications,Automotive parts
End products
Salt water softener pellets,Laundry detergent pods,Polishing compounds,Grinding wheels,Catalytic converter elements,Tungsten carbide inserts,Espresso pods,Chocolate bars,Uranium fuel rods,Dishwasher tablets,Car brake pads,Lithium-ion battery cells
Steps before
Drying,Grinding
Steps after
Bilayer production,Packaging,Dust extraction,Sterilization
Input ingredients
abrasive powders,second-layer feeder materials
Output ingredients
tablets,single-layer tablets,bilayer tablets,tablets with vertical holes
Market info
GEA is known for its expertise in engineering innovative and sustainable equipment and solutions, focusing on sectors such as food, beverages, pharmaceuticals, and energy, with a reputation for quality, efficiency, and advanced technological applications in industrial processing.

Technical Specifications


Max. tablet diameter
25,4 mm
Max. pre-compression force
10 kN
Max. compression force
100 kN
Max. output capacity
374,000 tab/h
Electrical requirements
3phase+PE – 380/400/415/460/480 V – 50Hz/60Hz
Power consumption
nominal 6 kW / installed 11.9 kVA
Compressed air requirements
Clean,dry / 7-8 bar / 500l/m
Dust extraction requirements
150 m³/h at 15 mbar
Machine dimensions
W = 1,030 mm x D = 1,555 mm x H = 2,170 m
Machine weight
2,500 kg
Number of stations
24,30,36,39,51
Tamping station force
2.5 kN
Final compression station
80 kN
Tooling type
D,B BB,BBS,A EU / TSM

Operating Characteristics


Working mechanism
Rotary tablet press
Process type
Single-layer and bilayer production
Automation level
PLC / SCADA
Changeover time
Fast and easy format changeovers
Cleaning method
Integrated dust extraction
Batch vs. continuous operation
Batch
Energy efficiency
Minimized investment cost with EDD

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm


ISO Certification
ISO 9001

Physical Characteristics


Machine Dimensions
W = 1.030 mm x D = 1.555 mm x H = 2.170 m
Machine Weight
2,500 kg
Max. Tablet Diameter
25.4 mm
Punch Body Diameter
25.4 mm
Die Diameter
38.1 mm
Discharge Method
Automatic

Custom Options


Interchangeable Turret
Yes,with EDD concept
Turret Parts
Upper punch guide,EDD,Lower punch guide
Bilayer Production Capability
Yes,with additional parts
Second-Layer Feeder
Can be shut off for sampling
Compression Area Accessibility
Unmatched
Dust Extraction Nozzles
Integrated
Changeover System
Fast format change with EDD
Dwell Time Control
Set independently of linear speed
Tooling Flexibility
D,B,BB,BBS,A tooling
