Industrial dust collection system for air filtration
Optimize air quality in your production line with this compact dust collection system, designed to efficiently filter and separate air particles for enhanced operational safety and compliance with environmental standards.
Separates and Collects Dust in Diverse Industries
The WAMAIR Flanged Polygonal Dust Collectors from WAMGROUP are engineered to streamline dust management across multiple industries, including concrete production, food processing, and pharmaceuticals. Utilizing a pulse-jet cleaning system, these dust collectors effectively separate dust particles from airflows, integrating seamlessly with existing production lines for both venting and suction applications. They feature a range of filter elements, including pocket and POLYPLEAT types, to suit various operational needs, with a filter surface area ranging from 3 to 70 m² and handling air volumes up to 9,000 m³/h. Designed for continuous and automatic operations, the units ensure low emissions and meet BIA/IFA certification standards for advanced dust filtration technology. Constructed from corrosion-resistant stainless steel, they are built to withstand a wide range of dust temperatures, making them suitable for outdoor installation. Easy maintenance is facilitated through the accessible hinged front door, allowing for quick filter element replacement from the clean air side. Customization options include varied mounting configurations, fan integration, and multiple voltage compatibility, supported by WAMGROUP’s global network for after-sales service and spare parts availability.
Benefits
- Enhances air quality and safety with low emission levels.
- Reduces maintenance time with easy filter replacement from the clean air side.
- Supports various industrial applications with versatile configuration options.
- Minimizes energy usage through a highly efficient compressed air system.
- Offers reliable performance with durable, corrosion-resistant materials.
- Applications
- Sugar processing,Ready-mix concrete production,Rubber processing,Waste handling and treatment,Bakery plants,Drymix building materials processing,Animal feed milling,Beverage processing,Pharmaceuticals processing,Environmental technology applications,Iron and steel mills,Flour milling,Paint and varnish processing,Spices,Glass processing,Grain storage,Ceramic production,Coffee processing,Cement processing,Construction materials,Convenience food,Detergent processing,Foundries,Precast concrete production,Bakeries,Cocoa and chocolate processing,Carpet manufacturing,Salt processing,Plastics raw material processing,Fertilizer processing
- End products
- Bread,Concrete mix,Wheat flour,Nitrogen-based fertilizers,Pastry,Poultry feed,Wheat grain,Polyethylene pellets,Ceramic tiles,Pharmaceutical coatings,Glass sheets,Portland cement,Synthetic rubber,Coffee beans,Drywall panels,Compost,Ground spices,Mortar,Acrylic varnishes,Granulated sugar,Precast concrete elements,Laundry detergents,Steel castings,Instant noodles,Recycled materials,Table salt,Bottled beverages,Pig iron,Chocolate bars,Carpet fibers,Tablets,Water-based paints
- Steps before
- Material Conveying,Grinding,Crushing,Material Mixing
- Steps after
- Dust Collection,Material Packaging,Loading,Quality Control
- Input ingredients
- dust,dirty air,heavier particles,air flow
- Output ingredients
- clean air,filtered dust,collected dust
- Market info
- WAMGROUP is known for its expertise in manufacturing bulk material handling and processing equipment, including screw conveyors, dust collectors, and valve systems, with a strong reputation for innovation, quality, and global market presence.
- Filter Surface
- 3 ~ 70 m² (32 ~ 755 sq ft)
- Air Volume
- 250 ~ 9,000 m³/h (147 ~ 5,300 cfm)
- Compressed Air Pulse-jet Cleaning System Pressure
- 4 ~ 6 bar
- Dust Temperature Range
- -20 ~ 80 °C (-4 ~ 176 °F)
- Filter Elements
- Pockets,POLYPLEAT
- Automation level
- Manual / PLC / SCADA
- Batch vs. continuous operation
- Batch / Inline Continuous
- CIP/SIP
- CIP 121°C / SIP 135°C
- Cleaning method
- CIP / Manual
- Energy efficiency
- 0.5–2 kWh/kg moisture
- Cleanability
- Easy filter removal and cleaning
- Corrosive resistance (e.g. acids)
- Stainless steel,resistant to corrosion
- Temperature compatibility
- -20 ~ 80 °C (-4 ~ 176 °F)
- Density/particle size
- Variety of dust densities/particle sizes
- EC Certification
- EC 1935/2004
- Casing Material
- 304/316 Stainless Steel
- Compact Design
- yes
- Filter Surface Area
- 3 ~ 70 m² (32 ~ 755 sq ft)
- Air Volume Handling
- 250 ~ 9,000 m³/h (147 ~ 5,300 cfm)
- Filter Elements Position
- Horizontally or Vertically Mounted
- Access Door
- Hinged,Removable Rear Panel
- Fan Integration
- Silenced Fan Integrated into Access Door
- Temperature Range
- -20 ~ 80 °C (-4 ~ 176 °F)
- Pulse-Jet Cleaning System
- Compressed Air 4 ~ 6 bar
- Control panel type
- Multifunctional,multi-voltage electronic control panel
- Installation configuration
- Horizontally or vertically mounted filter elements
- Fan integration
- Silenced fan integrated into access door
- Pulse-jet cleaning system
- Compressed air pulse-jet cleaning system
- Filter element options
- Pockets,POLYPLEAT
- Material options
- 304 / 316 stainless-steel casing
- Access panel customization
- Removable rear panel or with inspection hatch
- Door hinge customization
- Left or right-side door hinges
- Weather protection
- Weather protection cover with clean air outlet
- Automation,control
- Advanced electronic panel with differential pressure meter
