Centrifugal mill for fine grinding in industrial processes

Achieve exceptional fineness without overheating your materials. This centrifugal mill ensures precise grinding while maintaining moisture content, ideal for products sensitive to temperature variations.

Grinds and Sifts Fine Powders and Granules

The Dinnissen Centrifugal Mill is engineered for precision grinding in diverse sectors such as food, pharmaceuticals, and chemicals. This robust mill utilizes a rotor-stator design, leveraging centrifugal force to process products into ultra-fine powders, ideal for applications like chocolate powder and pharmaceuticals. It offers efficient high-speed operation with capacities ranging from 100 to 11,500 kg/hour, depending on product type and fineness. Ensuring energy efficiency, the mill features variable-speed control to minimize energy consumption while maintaining the desired particle size. Constructed with durable materials, including a stainless steel option for corrosion resistance, it meets stringent hygiene standards and is available in an EHEDG-compliant version. Integration is seamless with PLC control and remote monitoring for intuitive operation. Maintenance is simplified through a single-bearing design, enabling quick rotor removal for cleaning—a particularly useful feature in maintaining product integrity across different batches.

Benefits

  • Achieves ultra-fine particle sizes, ensuring consistent product quality across diverse applications.
  • Optimizes energy use with variable-speed motor control, reducing operational costs.
  • Simplifies maintenance and minimizes downtime with quick-access rotor design.
  • Complies with stringent hygiene and safety standards, ideal for food and pharmaceutical production.
  • Adapts to various product types with customizable rotor and stator configurations.

General


Applications
Food,Chemicals,Feed,Pet food,Pharma,Cocoa cake,Minerals,Cinnamon sticks,Aquafeed,Filter cake
End products
Mineral supplements,Fine spice powders,Extruded pet food pellets,Chocolate powder,Baking powder,Essential oil powders,Hydrocolloids,Filter media,Cocoa butter substitutes,Fish feed granules,Cosmetic exfoliants,Pharmaceutical powders,Stabilizers
Steps before
Intake,Emptying,Conveying,Handling,Feeding,Weighing,Mixing,Processing
Steps after
Sifting,Screening,Packaging,Filling
Input ingredients
cocoa cake,filter cake,cinnamon sticks,greasy products,sticky products
Output ingredients
very fine product grinding,final fineness 700 to 30 microns
Market info
Dinnissen is renowned for its expertise in process technology, specializing in innovative solutions for powder handling, mixing, and bulk materials processing for various industries, including food, feed, and chemicals, with a reputation for quality and custom engineered solutions.

Technical Specifications


Final Fineness
700–30 microns
Capacity
100–11,500 kg/hour
Pressure Impact Resistance
Up to 10 bar
Rotor Speed
High (Exact Value Not Specified)
Cooling Mechanism
Air/gas displacement with fan

Operating Characteristics


Final Fineness
700 to 30 microns
Capacity
100 to 11,500 kg per hour
Centrifugal Force Principle
Circular motion with centrifugal force
Rotor and Stator Designs
Pins,turbo motor,paddle wheel
Product Cooling
Air movement by rotor speeds
Hygienic Design
Dust-proof,EHEDG version available
Cleaning Accessibility
Single bearing,rotor movable
System Integration
Filter systems and fan
Moist and Greasy Product Handling
Air displacement for cooling
Grinding Path Management
Impeller for sticky products

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Physical Characteristics


Material to be ground
Various types
Grinding track type
Rotor and Stator
Final fineness
700 to 30 microns
Capacity
100 to 11,500 kg/hour
Bearing design
Single bearing

Custom Options


Rotor Design
Pins/Turbo Motor/Additional Paddle Wheel
Stator Design
Pins/Turbo Motor/Additional Paddle Wheel
Pressure Impact Resistant Version
Up to 10 bar
Material Construction
Cast Steel/Stainless Steel
Cooling System
Air Displacement for Cooling
Filter System
Extensive Filter Systems with Fan
Product Testing Facility
Dinnissen D-Innocenter
