Tablet compression technology for pharmaceutical production

Enhance your production capabilities with advanced tablet compression machines, perfect for achieving precise dosage and high-speed processing in pharmaceutical and nutraceutical manufacturing.

Compresses and Shapes Tablets for R&D

The FlexiTab XL from Syntegon is a versatile single punch tablet press that caters to the unique production challenges in pharmaceutical, nutraceutical, and confectionery industries. Designed for early-stage R&D and clinical trials, this machine excels in producing a wide range of tablets and oblong forms, including multi-layered dosages with up to three APIs. The FlexiTab XL offers precise control over layering and sequencing, thanks to its enhanced data acquisition (DAQ) software. Capable of rapid changeovers, it supports tight schedule demands in research and development environments. The machine’s compact design ensures seamless integration into existing labs, while its hygienic build meets cGMP standards, facilitating fast and easy cleaning. Fully manual or automated sequencing of tablet production accommodates varied operational needs, making it a highly adaptable tool for any tablet formulation requirement.

Benefits

  • Enhances precision in tablet formulation with automated powder sequencing.
  • Minimizes downtime with rapid changeovers and cleaning procedures.
  • Supports diverse applications with multi-layer and multi-API capabilities.
  • Integrates seamlessly into lab environments with a compact design.
  • Ensures regulatory compliance with cGMP hygienic standards.

General


Applications
Medicated lozenges,Vitamins,Pharmaceutical tablets,Nutraceuticals,Confectionery
End products
Vitamin b tablets,Vitamin c tablets,Mint candies,Chewable multivitamins,Nicotine lozenges,Omega-3 capsules,Cough suppressing lozenges,Paracetamol tablets
Steps before
Powder preparation,Granulation,Mixing,API blending
Steps after
Coating,Inspection,Packaging,Quality control
Input ingredients
powders,granules,APIs (Active Pharmaceutical Ingredients),excipients
Output ingredients
tablets,oblong tablets,multi-layer tablets,bilayer tablets,pharmaceuticals,nutrition and health products,confectionery (mints),nutraceuticals (vitamins),medicated lozenges
Market info
Syntegon is known for its expertise in processing and packaging technology, offering innovative solutions for the food and pharmaceutical industries. It has a strong reputation for advanced equipment, sustainability, and customer-oriented service.

Technical Specifications


Speed
230,000 to 1,000,000 tablets/hour
Capacity
Single to multi-layer tablets
Tablet size
Up to 16 mm
Die size
56 station die table
Automation
Enhanced DAQ software
Changeover time
Less than one hour
Compression force
Not specified
Cleaning method
Fast and easy cleaning
Feeding system
Two-paddle design,additional third paddle
Production zone
Two-level separation
Integration
Exchangeable turret option
Output
Up to 16 mm tablets
Material Compatibility
Pharmaceutical,nutraceutical,confectionery,non-pharmaceutical
Production Range
R,D to high volume production
Software
Same software throughout TPR range
Feeder and turret design
Suited for MUPS tablets
Operator protection
OEB 3 protection cabin
Bilayer tablet production
Yes

Operating Characteristics


Working mechanism
Compression with single or rotary punch
Integrated steps
Compression,tablet shaping,and optional bi-layer production
Automation level
Manual / PLC
Batch vs. continuous operation
Batch
Changeover time
Less than one hour
CIP/SIP
Available options for cleaning
Cleaning method
Fast and easy cleaning for hygienic design
Powder feeding system
Three-paddle design

Material Compatibility


Cleanability
cGMP standards
Corrosive resistance (e.g. acids)
Yes
Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Product type Characteristics


Tablet Types
Single-layer,bi-layer,multi-layer
Product compatibility
MUPS (Multiple Unit Pellet System)

Physical Characteristics


Machine footprint
Small / Compact
Turret removal system
Integrated
Design
Compact,hygienic
Paddle design
Single / Individually controlled
Discharge method
N/A
Control panel type
N/A

Custom Options


Control panel type
Standard HMI with DAQ software
Integration possibilities
Interchangeable turret system
Feeder and turret design
Two-paddle design with optional third paddle
Operator protection
OEB 3 protection cabin with glove port access
Production capability
Single,bi-layer,and multiple API tablets
Software
APD software for process parameter optimization
Cleaning method
Dry cleaning option available
Batch types
R,D,pilot,small to high volume production
Accessibility
Reduced width corner pillars for easier access
