High efficiency roller mill for grain and oilseeds

Optimize your crushing and grinding processes with a versatile roller mill designed for handling grain, oilseeds, biomass, and more, ensuring precise consistency and reduced energy consumption in your production line.

Crushes and Grinds Grain and Biomass

The Roller Mills HE-Serie from Ottevanger Milling Engineers is designed to efficiently crush and grind a variety of materials, such as grain, oilseeds, and biomass. This system is distinguished by its multi-unit structure, with one to three independently driven rollers that ensure consistent material flow and precision crushing. It excels in applications producing whole wheat flour, fish feed pellets, and wood pellets, with a throughput capacity ranging from 0 to 60 tons per hour depending on configuration. The system features an electro-pneumatic flap and frequency-controlled dual rotation feeder for optimal material handling and energy conservation. Constructed from durable ‘Hartguss’ material, the rollers offer an extended lifespan and reduced maintenance needs. Integration is seamless with automated roller adjustments and the option for manual engagement, enhancing operational efficiency. Additional benefits include oil-free transmission via double-toothed timing belts and compliance with industry standards, ensuring reliable performance in various production environments.

Benefits

  • Maximizes material processing efficiency with minimal downtime, achieving up to 60 tons per hour throughput.
  • Reduces maintenance costs and downtime through durable ‘Hartguss’ rollers and quick access for maintenance.
  • Decreases energy consumption with optimized frequency-controlled feeder systems.
  • Enhances product quality by ensuring precise crushing and grinding for various feed and biomass applications.
  • Supports seamless integration into existing lines with automated adjustments and flexible configurations.

General


Applications
Oilseeds,Pet food,Grain,Soybean processing,Aqua feed,Concentrates,Biomass,Premix,Compound feed
End products
Chicken feed,Whole wheat flour,Wood pellets,Mineral concentrate,Fish feed pellets,Cat kibble,Soy protein isolate,Canola oil,Vitamin premix
Steps before
Cleaning,Pre-cleaning,Product intake,Dosing,Weighing
Steps after
Mixing,Conditioning,Pelleting,Drying,Cooling,Crumbling,Sieving,Coating
Input ingredients
grain,oilseeds,biomass
Output ingredients
crushed material,ground material,pellet crumble
Market info
Ottevanger Milling Engineers is renowned for designing and manufacturing innovative milling equipment and complete production lines for the grain processing industry, including feed mills, flour mills, and biomass processing, with a reputation for quality, efficiency, and customized solutions.

Technical Specifications


Capacity
0-10 t/h,8-18 t/h,15-25 t/h
Roller working length/diameter
700/300 mm,1300/300 mm,1840/300 mm
Drive (kW)
1×18.5 kW,1×37 kW,1×45 kW
Automation
Automatic/manual roller adjustment
Adjustable Speed Rotating Feeder
Dual rotation direction
Adjustment Accuracy
0.01 mm (manual/automatic)
Inlet with flange
Inclusive counter flange
Design
Solid construction,mild steel

Operating Characteristics


Working mechanism
Independently driven rollers,axially riffled breaker rollers
Integrated steps
Adjustable-speed rotating feeder,crushing units
Automation level
Manual/Automatic adjustment (optional)
Batch vs. continuous operation
Continuous operation with adjustable flow
Energy efficiency
Low energy requirements
Changeover time
Easy access for maintenance,rapid roller exchange
Cleaning method
Electro-pneumatic operated flap ensures easy cleaning

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Physical Characteristics


Machine Footprint
Varies by model,e.g.,1446x1366x875 mm for Single Roller mills
Roller Dimensions
Working length/diameter
Discharge Method
Roller Breaker System
Structure Material
Mild Steel with 'Hartguss' Rolls
Unit Configuration
Single,Double,or Triple Roller Mills
