Double-sized bi-layer tablet press

Achieve high-volume production with precision using a double-sized bi-layer tablet press designed to minimize downtime and cross-contamination, ensuring optimal bonding and consistent tablet quality in every batch.

Compresses and Controls Bi-Layer Tablet Production

The MODUL D from GEA is a high-capacity tablet compression machine designed for pharmaceutical manufacturers focusing on bi-layer and high-volume tablet production. With a standout feature of the Exchangeable Compression Module (ECM), it ensures a clean production environment by encapsulating all product contact parts. Capable of producing over 1 million tablets per hour, it is ideal for products like extended-release pain relief and effervescent vitamin C tablets. The machine’s dual control system enhances batch consistency and minimizes waste. Its zero-gap powder feeder and innovative extraction nozzles reduce cross-contamination during bi-layer tableting. The MODUL D supports GMP compliance and offers ease of cleaning with reduced downtime, thanks to its modular ECM. Advanced features like automated weight control and hardness adjustment further optimize production efficiency.

Benefits

  • Enhances productivity with a production capacity exceeding 1 million tablets per hour.
  • Minimizes downtime through rapid product changeover enabled by the ECM.
  • Ensures precise tablet quality with sensitive weight and hardness control systems.
  • Prevents cross-contamination with a zero-gap closed powder feeder.
  • Facilitates safe operation and easy maintenance with fully encapsulated product contact components.

General


Applications
Vitamins,Supplements,Pharmaceutical tablets,Nutraceuticals,Pharmaceutical powder
End products
Protein powder tablets,Antihypertensive medication tablets,Probiotic supplement tablets,Iron deficiency tablets,Multivitamin supplements,Herbal nutraceuticals,Extended-release pain relief tablets,Calcium citrate tablets,Bi-layer tablets for controlled drug release,Effervescent vitamin c tablets
Steps before
Formulation development,Powder preparation,Blending,Granulation,Drying
Steps after
Tablet inspection,Coating,Packing,Quality control testing,Labeling
Input ingredients
powder,bi-layer tablet ingredients
Output ingredients
tablets,bi-layer tablets
Market info
GEA is known for its expertise in engineering innovative and sustainable equipment and solutions, focusing on sectors such as food, beverages, pharmaceuticals, and energy, with a reputation for quality, efficiency, and advanced technological applications in industrial processing.

Technical Specifications


Max. tablet diameter
35 mm
Punch body diameter
35 mm
Outside die diameter
52 mm
Die height
30 mm
Number of stations
39 to 88
Max. fill depth
20 (25) mm
Max. pre-compression force
10 kN
Max. compression force
100 kN
Max. output capacity
1,069,000 tablets/h
Electrical requirements
380 / 400 / 415 / 460 / 480 V – 50Hz / 60Hz
Compressed air requirements
Clean,dry
7-8 bar
500 l/m
Dust extraction requirements
150 m³/h at 15 mbar (single-layer)
Machine dimensions,weight
W = 2,000 mm x D = 1,500 mm x H = 2,250 mm – 6,000 kg

Operating Characteristics


Working Mechanism
Double-sided production / Bi-layer production
Automation Level
PLC-controlled / SCADA
Batch vs Continuous Operation
Batch
Changeover Time
Minimal with ECM
Cleaning Method
ECM removal eliminates cleaning needs
Energy Efficiency
High productivity with minimal downtime

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Physical Characteristics


Machine footprint
W = 2,000 mm x D = 1,500 mm x H = 2,250 mm
Machine weight
6,000 kg

Custom Options


Control panel type
Latest HMI for complete process control
Bi-layer manufacturing option
Unique bi-layer manufacturing
Exchangeable Compression Module (ECM)
Yes,for D,B,BB and other sizes
High sensitivity weight control
For small tablets and low compression forces
Dual control system
Yes,reduces wastage and ensures batch consistency
