Vacuum cold trap for lab applications
Ensure efficient separation and purification in biopharmaceutical applications with this vacuum cold trap, designed to protect your vacuum pump and optimize drying processes in high-throughput environments.
Preserves Vacuum Pump Efficiency by Capturing Residue
The MAXTRAP Vacuum Cold Trap from Cascade Sciences offers a sophisticated solution for laboratories and industrial settings needing efficient purification and drying processes. Engineered with a COLDWELL stainless steel trap, its patent-pending baffle system maximizes surface area while operating with a -50°C/-105°C refrigerated base manufactured by Labconco. This cold trap effectively enhances vacuum pump efficiency by capturing residues that could otherwise compromise system performance. It is ideal for applications in biopharmaceuticals, nutraceuticals, and chemical processing, producing end products such as purified antibodies, essential oils, and biodiesel.
With full KF25 inlet and outlet connections, MAXTRAP minimizes flow restrictions, ensuring optimal throughput in continuous and high-throughput operations. Energy-efficient refrigeration using Green CFC/HFC free refrigerants aligns with sustainable practices. Available in sturdy stainless steel, it is resistant to corrosion, making it suitable for harsh chemical environments. Compliant with industry standards, it supports easy cleaning and maintenance with a user-friendly design, and offers customization options to suit specific operational needs, including configurations for lab and industrial integration.
Benefits
- Extends vacuum pump lifespan by effectively capturing damaging residues.
- Enhances operational efficiency with unrestricted flow design.
- Reduces energy consumption with eco-friendly refrigerants.
- Adapts to various chemical processes with robust, corrosion-resistant materials.
- Supports continuous processing with easy-to-integrate design for minimal disruption.
- Applications
- Supplements,Vitamins,Liquid formulations,Fine chemicals,Nutraceuticals,Pharmaceutical powder,Biopharmaceuticals,Enzymes,Biofuel,Essential oils
- End products
- Biodiesel,Turmeric capsules,Purified antibodies,Vitamin c tablets,Ibuprofen powder,Liquid nutritional supplements,Omega-3 capsules,Paracetamol tablets,Lavender essential oil,Trypsin enzymes
- Steps before
- Sample Preparation,Outgassing,Moisture Reduction
- Steps after
- Vacuum Purging,High-Throughput Drying,Vacuum Processing
- Input ingredients
- solvents,air,high moisture,outgassing
- Output ingredients
- trapped matter,liquid oxygen,gases,ice
- Market info
- Precision Extraction Solutions is known for providing innovative, high-quality extraction equipment and solutions for the cannabis industry, specializing in systems that enhance efficiency and safety in extracting cannabinoids and essential oils.
- Temperature Range
- -50°C / -105°C
- Capacity
- 3 Quart (2839 ml)
- Material
- 304 Stainless Steel
- Inlet/Outlet Connections
- KF-25
- Refrigerant Type
- CFC / HFC Free
- Power
- 115V / 1ph / 3 AMP (60Hz)
- Weight (Thermo Mechanical Base)
- 60 lbs (MAXTRAP50),139 lbs (MAXTRAP105)
- Dimensions (MAXTRAP50)
- 13.5″ W x 23.5″ D x 12.0″ H
- Dimensions (MAXTRAP105)
- 24.1″ W x 23.9″ D x 12.6″ H
- Shipping Weight
- 95 lbs (MAXTRAP50),190 lbs (MAXTRAP105)
- Cooling Medium
- Ethanol,Glycol,Cryo-cool fluids
- Working Mechanism
- Mechanically refrigerated
- Temperature Range
- -50°C / -105°C
- Flow Control
- KF25 inlet and outlet connections
- Automation Level
- Manual control
- Cleaning Method
- Manual
- Changeover Time
- Quick through secondary trap
- Energy Efficiency
- Not specified
- Corrosive resistance (e.g. acids)
- Yes,stainless steel (304)
- Cleanability
- High,designed for easy maintenance and cleaning
- Biological compatibility
- N/A
- Abrasion resistance
- N/A
- ETL Mark
- UL61010
- Machine Footprint
- 13.5" W x 23.5" D x 12.0" H (MAXTRAP50)
- 24.1" W x 23.9" D x 12.6" H (MAXTRAP105)
- Weight
- 14 lbs (COLDWELL Stainless Trap)
- 60 lbs (Mechanical Base for MAXTRAP50)
- 139 lbs (Mechanical Base for MAXTRAP105)
- Capacity
- 3 Quart (2839 ml)
- Surface Area
- Patent pending series of filter baffles
- Inlet/Outlet Size
- KF-25
- Material
- 304 Stainless Steel Trap
- Version
- -105°C / -50°C
- Insulator Cap Type
- Neoprene
- Inlet/Outlet Connection Size
- KF-25
- Fluid Type for Transfer
- Ethanol,Glycol,Cryo-cool fluids
