Steam-heated hemispherical bottom cookers for sauce production

Streamline your sauce and condiment production with multipurpose steam-heated cookers, designed for precise formulation and efficient temperature control to enhance flavor consistency.

Cooks, Formulates, and Pasteurizes Liquid Foods

The steam-heated multipurpose cooker and formulator is a versatile solution tailored for food manufacturers and sauce producers. It features a unique steam-heated hemispherical bottom design, enhancing heat distribution for efficient cooking and pasteurization. This equipment can handle diverse applications, accommodating multiple types of agitators for optimal formulation of sauces, jams, and soups. Built to FDA and EHEDG standards, it ensures hygienic operation and ease of cleaning, incorporating automatic washing systems. With integrated sensors and a user-friendly touch panel, you can manage recipes and control parameters for consistent results. Ideal for high-capacity operations, this cooker aligns seamlessly with your processing line, supported by customization options to fit specific production needs.

Benefits

  • Enhances product consistency and quality with precise process control and automation.
  • Minimizes cleaning time and risk of contamination through FDA-compliant easy-clean design.
  • Flexible production capabilities with customization to handle various sauces and liquid foods.
  • Increases operational efficiency by integrating multiple functions like cooking and pasteurization.
  • Supports scalable production with high-capacity output, accommodating up to 100 product references.

General


Applications
Sauces,Fast-food sauces,Tomato processing,White sauces,Fruit processing,Mayonnaises,Tomato-based sauces
End products
Ketchup,Hollandaise sauce,Fruit compote,Aioli,Condensed tomato soup,Fruit jam,Marinara sauce,Tomato paste,Diced fruit in syrup,Tartare sauce
Steps before
Emulsification,Ingredient Preparation
Steps after
Packing,Sterilization,Recipe Storage
Input ingredients
steam,agitators
Output ingredients
mayonnaises,fast-food sauces,white sauces,tomato-based sauces
Market info
FENCO Food Machinery is known for engineering and manufacturing high-quality, customized food processing equipment. Renowned for innovation and reliability, they specialize in designing machinery tailored to specific production needs in the food industry.

Technical Specifications


Agitator Types
Multiple / Dual
Compliance
FDA / EHEDG
Cleaning Method
Automatic washing
Control System
Touch panel / Software-managed
Product Capacity
Up to 100 references
Heater Type
Steam-heated
Bottom Design
Hemispherical
Automation Level
Automated Recipe Management
Parameter Control
Sensor equipped
Design
Easy-clean

Operating Characteristics


Working mechanism
Steam-heated hemispherical bottom cookers
Agitator options
Multiple types,potential for two together
Automation level
Touch panel,software,and settable parameters
CIP/SIP
Automatic washing
Process control
Equipped with sensors for parameter control
Batch vs. continuous operation
Batch
Recipe management
Management of several recipes
Data storage
Storage of plant history and personnel actions
Compliance
FDA and EHEDG regulations

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Physical Characteristics


Cooker type
Steam-heated hemispherical bottom
Agitator configuration
Multiple types available
Possibility of two agitators together
Compliance
FDA and EHEDG regulations
Touch panel type
User-friendly interface with software management for recipes
Automation
Automated washing and easy-clean design
Data storage
Plant history and personnel actions
Customization
Tailor-made according to customer needs

Custom Options


Agitator types
Multiple,with option for dual agitators
Control panel type
Touch panel with settable parameters
Cleaning
Automatic washing design
Materials
Compliance with FDA and EHEDG regulations
Customized design
Tailor-made to customer’s needs
Recipe management
Multiple recipe management via software
