Shaftless spiral conveyor for waste water treatment
Efficiently handle challenging materials like de-watered sludge and screenings with a shaftless spiral conveyor, designed to prevent tangling and ensure smooth material flow. Ideal for operations needing robust solutions to manage diverse waste types and maintain continuous processing without intermediate bearing obstructions.
Conveys and Manages Difficult Waste Materials
The Shaftless Spiral Conveyor SSC from WAMGROUP is engineered for efficient handling of challenging waste materials. This equipment is distinguished by its shaftless design, allowing for the transport of sticky, tangled, or highly variable materials without clogging, thanks to its robust, wear-resistant spiral. Ideal for applications in wastewater treatment and food processing, the SSC can manage diverse wastes like sludge cake, packaged food waste, and industrial slurries.
Production processes benefit from its simple design and minimal maintenance, with a throughput of up to 45 m³/h for sludge. The conveyor’s energy efficiency is enhanced by a variable-speed motor, and its material construction choice between carbon steel and stainless steel offers excellent corrosion resistance. Automation is facilitated through PLC control, while its modular components and various liner options allow for tailored solutions to fit specific operational needs. The design includes features for easy access and cleaning, ensuring quick maintenance and uninterrupted operations.
Benefits
- Ensures uninterrupted operation by eliminating intermediate bearings that cause clogs.
- Reduces maintenance costs with a robust, simple design requiring fewer components.
- Increases process efficiency with its ability to handle diverse, difficult materials reliably.
- Supports environmental compliance through odor-free and leak-proof operation.
- Customizable for various needs with modular components and liner options, enhancing operational versatility.
- Applications
- Conditioned sludge,De-watered sludge,Screenings and floating matter,Thickened sludge,Urban solid waste,Packaged food,Meat processing waste,Fruit processing waste,Vegetable processing waste,Pastes,Fish processing waste,Creams
- End products
- Cosmetic creams,Vegetable pulp,Fish slurry,Processed food packages,Meat slurry,Food pastes,Waste bales,Fruit pulp,Sludge cake
- Steps before
- Screening,De-watering,Thickening,Conditioning
- Steps after
- Solid Waste Treatment,Sludge Treatment,Waste Disposal,Recycling
- Input ingredients
- urban solid waste,screenings,floating matter,de-watered sludge,thickened sludge,conditioned sludge,packaged food,creams,pastes,waste from meat processing,waste from fish processing,waste from fruit processing,waste from vegetable processing
- Output ingredients
- processed waste,conveyed solids,efficiently transferred materials
- Market info
- WAMGROUP is known for its expertise in manufacturing bulk material handling and processing equipment, including screw conveyors, dust collectors, and valve systems, with a strong reputation for innovation, quality, and global market presence.
- Capacity
- Up to 45 m³/h for sludge
- Up to 12.9 m³/h for screenings
- Drive Power
- 0.55 kW ~ 9.2 kW
- Material
- Carbon or 304L / 316L stainless steel
- Liner Material
- UHMWP trough liner
- Trough Design
- Longitudinally divided U-section
- Outlet Type
- Vertical or flush-type
- Loading Option
- From above,inlet spout,or side inlet
- Operation
- Enclosed trough with gaskets
- Screw Type
- Heavy-duty shaftless screw
- Liner Options
- With wear signaling,bottom bars or plates
- Power Transmission Type
- Direct,coupling transmission,chain transmission,belt transmission
- Emptying Capability
- Complete emptying
- Working mechanism
- Shaftless Spiral
- Handling capacity
- Up to 45 m³/h for sludge,12.9 m³/h for screenings
- Automation level
- Manual / PLC
- Batch vs. continuous operation
- Continuous
- Odour-free operation
- Yes
- Cleaning method
- Easy access for inspection and cleaning
- Maintenance requirement
- Low maintenance
- Abrasion resistance
- High
- Corrosive resistance (e.g. acids)
- Yes
- Density/particle size
- 0.5–2.5 g/cm³ / 50–1000 µm
- Cleanability
- Easy
- Machine footprint
- Compact design,small footprint
- Material of construction
- Carbon steel,304L / 316L stainless steel
- Discharge method
- Vertical or flush-type outlet
- Trough shape
- U-section trough
- Feed method
- Loaded from above,inlet spout or side inlet
- Liner type
- UHMWP liner,optional liners available
- Control panel type
- PLC / Manual
- Power transmission type
- Direct / Coupling / Chain / Belt
- Material type
- Carbon steel / Stainless steel (304L / 316L)
- Trough cover type
- Open / Bolted
- Liner type
- Varies with wear signalling,bottom bars,or plates
- Loading options
- Top / Side Inlet
- Drive unit alignment
- Vertical / Flush-type
