Roll support dryers for web transportation
Eliminate web curl issues and enhance drying precision for diverse materials with roll support dryers, designed to seamlessly transport and condition webs unsuitable for flotation, ensuring optimal processing efficiency.
Facilitates Precise Web Drying and Transport
Dürr’s Roll Support Dryers are engineered for precision in web handling and drying applications, catering to industries such as automotive and electronics. Utilizing a patented curved roller design, these dryers ensure the non-contact transport of webs, crucial for applications like lithium-ion battery electrodes and photovoltaic backsheets. Their integration into roll-to-roll production lines allows for smooth transitions and curl elimination, essential for maintaining product integrity.
Handling diverse applications, from drying composites to curing coatings, these dryers accommodate full-scale to bench-top operations, supporting industries from chemical to flexible packaging. Designed for energy efficiency, they feature customized impingement nozzles that optimize air delivery and uniform heat distribution. With options for material selections like stainless steel, they ensure durability and chemical compatibility.
These dryers support precise thermal management through PLC-controlled systems, allowing for seamless integration with existing production lines. They offer multi-zone capabilities for tailored drying profiles and meet industry standards, making them a robust choice for manufacturers looking for reliable, efficient web processing solutions.
Benefits
- Enhances efficiency by eliminating web curl and damage through precise roller design.
- Integrates seamlessly into existing production lines, minimizing installation and compatibility issues.
- Reduces energy costs with optimized air delivery and uniform heat distribution.
- Adapts to various industry needs with customizable multi-zone drying profiles.
- Ensures product integrity, crucial for sensitive applications like battery materials and flexible packaging.
- Applications
- Nonwovens,Composites,Printing,Converting,Solar films,Coil coating,Coating,Advanced battery materials,Flexible packaging,Electronics,Membranes
- End products
- Photovoltaic backsheet,Stand-up pouches,Spunbond nonwoven fabric,Printed circuit boards,Car body coating,Lithium-ion battery electrodes,Prepainted metal sheets,Carbon fiber reinforced plastics,Filtration membranes,Flexographic printing products,Pressure-sensitive labels
- Steps before
- Coating,Formulation Development,R,D Testing,Pilot Project Preparation
- Steps after
- Heat Setting,Tempering,Curing,System/Process Validation
- Input ingredients
- web materials,heavy webs,roll-to-roll materials,materials for drying,materials for curing,advanced battery materials,coatings,composites,solar films,membranes,flexible packaging,coil coatings,converting materials,printing substrates,electronics substrates,nonwovens
- Output ingredients
- dried materials,cured films,heat-set webs,finished roll-to-roll products,processed advanced battery materials,processed coatings,processed composites,processed solar films,processed membranes,finished flexible packaging,coated coils,converted materials,printed substrates,processed electronics substrates,processed nonwovens
- Market info
- Dürr is known for its expertise in industrial engineering and manufacturing solutions, specializing in automotive painting technology, environmental technology, and production efficiency systems. It has a strong reputation for innovation and quality in engineered-to-order equipment.
- Drying Method
- Impingement / Roll Support / IR
- Air Delivery
- Uniform through impingement nozzles
- Thermal Management
- Patented Dürr system
- Multi-zone Capabilities
- Yes
- Drying Process
- Roll-to-roll
- Non-contact Drying
- Flotation dryers
- Web Transportation
- Rollers beneath the webs
- Curl Elimination
- Curved design system
- Drying Analysis and Modeling
- Yes
- 3D Film Measurement
- 3D Microscope
- Infrared (IR) Technology
- Air bar technology
- Heat Transfer Analysis
- Heat transfer stand
- R,D Scaling
- Bench-top to full-scale production
- Pilot Line Validation
- Full-scale pilot line
- Working mechanism
- Roll support with curved design
- Web handling ability
- Optimized for non-flotation webs
- Drying process type
- Roll-to-roll processing
- Impingement drying
- With impingement nozzles and slot nozzles
- Automation level
- Customized designs available
- Energy efficiency
- Thermal air management systems
- Multi-zone capabilities
- Included for optimal performance
- Non-contact drying option
- Available with air bar technology
- Machine footprint
- Customizable based on application
- Roller configuration
- Curved patented system
- Web size handling
- Dependent on process needs
- Nozzle type
- Impingement Nozzles
- System design
- Multi-zone capabilities
- Heat management system
- Patented Dürr thermal air management
- Control panel type
- PLC / HMI
- Integration possibilities
- SCADA / Plant Network Connectivity
- Customized Design
- Multi-zone capabilities / Tailored configurations
