Mango juice production line

Streamline your mango juice production with a complete solution that efficiently transforms fresh mangoes into concentrated juice—ensuring high juice yield and maintaining nutritional integrity from raw processing to final aseptic packaging.

Processes and Extracts Mango Juice Efficiently

The Mango Juice Production and Processing Line by Taizy Machinery, a leader in food processing solutions, offers a comprehensive system for transforming fresh mangoes into a variety of juice-based products. This equipment is specialized for high-volume operations, capable of processing between 10 to 2500 tons of raw mangoes daily. With a focus on efficient extraction and refined processing, it incorporates a range of machines including washing units, juice extractors, preheating enzyme killers, and automated filling systems. Its PLC-controlled operation ensures seamless integration into existing production workflows, while maintaining energy efficiency through variable-speed motor control. Constructed from food-grade stainless steel, the equipment meets stringent food safety standards, with options for customizing system components to meet specific production needs. Optimal for producing concentrated mango juice, pulp, and drinks, this line is a valuable asset for manufacturers in the food and beverage industry looking to maximize juice yield while minimizing contamination. The system also supports cleaning-in-place (CIP) capabilities for expedited maintenance, reducing downtime and ensuring hygiene standards are consistently met.

Benefits

  • Maximizes production capacity with throughput ranging from 10 to 2500 tons per day.
  • Ensures product safety and extended shelf life with effective sterilization processes.
  • Reduces operational costs with PLC-controlled automation and energy-efficient design.
  • Achieves high juice yield and quality with precision extraction and refinement.
  • Facilitates easy maintenance and quick cleaning through CIP systems, minimizing downtime.

General


Applications
Sauces,Food additives,Concentrated juices,Condiments,Fruit juices,Nutritional drinks,Fruit pulp,Fruit-based drinks
End products
Fruit puree beverage,Concentrated apple sauce,Fruit-based nutritional drink,Apple juice,Pineapple juice,Mango juice,Orange juice,Mango concentrate,Aseptic mango pulp,Tomato ketchup
Steps before
Cleaning,Selection,Core Removal,Preheating
Steps after
Sterilization,Filling,Packaging
Input ingredients
fresh mangoes,apple,raw mangoes
Output ingredients
concentrated juice,concentrated jam,mango juice,fruit juice drinks,ketchup,concentrated sauce
Market info
Taizy Food Machinery is known for manufacturing industrial food processing equipment, specializing in engineered-to-order (ETO) machinery. They have a reputation for innovative, high-quality solutions tailored to meet various customer specifications globally.

Technical Specifications


Capacity
10–2500 tons/day
Juice yield
75%
Automation
Intelligent PLC-controlled
Final concentrated juice concentration
65~72 Brix
Mango Juice Beating Rate
98%
Filling and Packaging Method
Aseptic big bag / glass bottle / PET bottle
Power (Pulping Machine)
11–22.5 kW
Blade speed (Pulping Machine)
960–2200 r/s
Filter size (Pulping Machine)
0.6/0.8/1.1 mm

Operating Characteristics


Automation level
PLC Control
Batch vs. continuous operation
Continuous
Energy efficiency
High production capacity
CIP/SIP
CIP available

Material Compatibility


Corrosive resistance (e.g. acids)
Yes
Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Physical Characteristics


Machine footprint
1.8*1.3*1.6 m to 1.9*1.2*1.35 m
Tank shape and size
Varied depending on machine type
Hoist type
Food-grade material
Cleaning method
Spray and bubble cleaning
Discharge method
Automated with aseptic filling
Control panel type
Intelligent PLC control
Filling volume
Varied for different sizes and types of containers

Custom Options


Control panel type
PLC Control
Machine customization
Customizable length and capacity
Material customization
Food-grade stainless steel
Screen aperture size
Customizable (0.6/0.8/1.1 mm)
