Conical screw mixer for pharmaceutical and chemical industries

Optimize mixing precision and efficiency with a conical screw mixer designed to handle diverse particle characteristics and prevent segregation, ensuring consistent product quality for your batch or continuous operations.

Mixes and Blends Diverse Solids and Powders

The Conical Screw Mixer Series SF 010 – SF 3000 from BOLZ-SUMMIX features a rotating mixing screw guided along a conical vessel by an orbital arm, ensuring efficient, gentle mixing and preventing segregation in diverse industrial powders and granules. Ideal for pharmaceuticals, chemicals, and food products, this mixer accommodates batch or continuous operations with a flexibility range of 10% to 100% loading capacity.

Constructed with corrosion-resistant stainless steels like AISI 316L and Hastelloy C22, it operates at temperatures up to 240°C and pressures from -1 to +6 bar, aligning with GMP, FDA, and ATEX standards. The machine’s PLC-controlled system integrates seamlessly into production lines, offering diverse customization options, including rotary shaft seals and CIP/SIP systems for efficient cleaning. With accurate mixing for high-purity end products and reduced energy consumption through optimized drive power, this solution delivers reliable performance across various industries and operations.

Benefits

  • Enhances product uniformity and quality with consistent mixing, reducing batch variation.
  • Minimizes energy consumption through efficient drive power, lowering operational costs.
  • Offers versatility across multiple industries with customizable configurations and material options.
  • Ensures compliance with stringent industry standards, supporting regulatory requirements.
  • Simplifies cleanup processes with CIP systems, boosting operational efficiency and hygiene.

General


Applications
Chemicals,Metal powders,Fine chemicals,Surface coatings,Food products,Recycling,Pharmaceuticals
End products
Specialty fine powders,Spice blends,Metal alloy powders,Chemical compounds,Powdered pharmaceuticals,Protein supplements,Protective coatings
Steps before
Grinding,Purification,Drying
Steps after
Packing,Coating,Sterilization
Input ingredients
bulk solids,pharmaceutical products,chemical products,food industry materials
Output ingredients
homogeneous product flow,blended materials,mixed industrial products
Market info
Heinkel (Bolz Summix) specializes in engineered-to-order industrial equipment, offering expertise in solid-liquid separation and mixing technologies, with a strong reputation for high-quality centrifuges, mixers, and dryers tailored to various industry needs.

Technical Specifications


Operating temperature (Orbital system)
160°C
Operating temperature (Central shaft)
240°C
Operating pressure
-1 bar to +6 bar
Explosion shock proof design
10 bar ESP
Drive power
Small
Load flexibility
10 to 100%
Discharge
Unrestricted,residue-free
Cleanability
Good,residue-free
Materials
Stainless steel (AISI 304,AISI 316L,AISI 316,AISI 904L,Hastelloy C22)
Surface finish
Product contact – fine polish / electro-polish|Externals – sanitary polish / glass blast bead
Seal type
Single/multiple lip seal,gas-purged,liquid quench

Operating Characteristics


Working mechanism
Rotating mixing screw with orbital arm
Batch vs. continuous operation
Batch
Product discharge
Central,unrestricted,residue-free
Cleanability
Good cleanability,residue-free drainage of cleaning fluids
Product load flexibility
10% to 100% load capacity

Material Compatibility


Cleanability
Good cleanability with residue-free drain
Corrosive resistance
Yes (Stainless steel,Hastelloy)
Density/particle size
Various densities,particle sizes,and shapes

Product type Characteristics


Diverse product handling
Density,particle size,shape variation


European PED Pressure Equipment Directive
AD-2000 calculation
ASME
Code VIII

Physical Characteristics


Tank shape
Conical
Discharge method
Central,unrestricted and residue-free
Operating pressure
-1 bar up to +6 bar
Operating temperature
160°C (Orbital system)
240°C (Central shaft)
Drive power
Small,energy-efficient
Material
Stainless steel (AISI 304,AISI 316L,AISI 316,AISI 904L,Hastelloy C22)
Surface finish
Fine polish/electro-polish for product contact,sanitary/glass blast bead for externals

Custom Options


Material selection
Stainless Steel (AISI 304,316L,316,904L),Hastelloy C22
Surface finish
Fine polish / Electro-polish
Heating options
Heating jacket / Insulating jacket
Sealing options
Single or multiple lip seal,gas-purged,or mechanical seals
Pressure design
Explosion shock proof (ESP) design up to 10 bar
Regulatory compliance
PED,ASME,ATEX,FDA,REACH,etc.
Temperature monitoring
Diverse sensors for temperature
Pressure monitoring
Diverse sensors for pressure
Cleaning system
WIP / CIP / SIP nozzles
Sampling options
Sampling valves with containment
