Chocolate chip depositor for small scale production

Achieve precise chocolate chip production with consistent size and weight control, ideal for confectionery makers seeking reliable, high-speed depositing solutions to streamline their production process.

Deposits and Precisely Shapes Chocolate and Confectionery

The Chocolate Drop Line Depositor from AMP-Rose is engineered for seamless integration into high-speed confectionery production environments. This depositor leverages a twin rotary valve with a horizontal piston design to deliver precise depositing of chocolate chips and confectionery drops, essential for consistent product formation.

Equipped with twin jacketed hoppers and stainless steel construction, it ensures durability and optimal thermal conditions. Its inline planetary gearbox and servo motor enable precise control over depositing speeds and strokes, with the capability to produce up to 250 kg/hr.

Applications range from chocolate chips to mini morsels, ideal for chocolate manufacturers and confectionery producers seeking to enhance their output. The equipment incorporates automation through an Allen-Bradley PanelView system, allowing process adjustments and quick changeovers via a touch interface.

This depositor minimizes energy consumption with its efficient design, supporting continuous operation and integrating smoothly with existing production lines. Maintenance is streamlined with easy access to piston assemblies for cleaning, ensuring maximum uptime and hygiene. With robust construction and heavy-duty materials, the Chocolate Drop Line Depositor offers reliability and efficiency, enhancing your confectionery processing capabilities.

Benefits

  • Enhances production efficiency by handling up to 250 kg/hr with consistent chip formation.
  • Minimizes labor costs with automated controls and quick-change capabilities.
  • Ensures product quality with precise control over deposit weight and shape.
  • Streamlines maintenance with easy access for piston assembly cleaning.
  • Durable stainless steel construction offers long-term reliability and optimal thermal conditions.

General


Applications
Sweets,Confectionery,Chocolate chips,Snacks
End products
Mini chocolate morsels,Confectionery drops,Small candy bites
Steps before
Chocolate tempering,Chocolate melting,Chocolate mixing
Steps after
Cooling,Packaging,Inspection,Storage
Input ingredients
chocolate
Output ingredients
chocolate chips,chips of 0.05g to 0.2g,0.05g – 2g chip weight
Market info
AMP Rose is renowned for manufacturing and supplying high-quality machinery for the confectionery, chocolate, and snack industries, offering innovative solutions and engineered-to-order equipment tailored to meet specific customer needs.

Technical Specifications


Output
0.05g – 2g chip weight range
Capacity
Up to 250 kg/hr
Speed
Up to 20 piston strokes/minute
Automation
Allen-Bradley servo motor
Stroke length
70mm maximum stroke
Lever radius
234mm
Shaft turning angle
17 degrees
Material
Stainless steel
Drive type
Inline planetary gearbox

Operating Characteristics


Working mechanism
Twin rotary valve with horizontal piston design
Automation level
Allen-Bradley Panel View 600 integration
Batch vs. continuous operation
Continuous operation at 20 strokes/minute
Cleaning method
Manual cleaning after disassembling pistons
Changeover time
Quick exchange of transfer plates

Material Compatibility


Abrasion resistance
Yes
Biological compatibility
Food-safe
Cleanability
Easy to disassemble and clean
Corrosive resistance (e.g. acids)
Stainless steel construction
Density/particle size
Chips 0.05g to 2g

Physical Characteristics


Twin jacketed hoppers
Stainless steel
Machine body material
Mild steel with powder coat
Control panel type
Allen-Bradley Panel View 600
Drive bar stroke
70 mm
Lever radius
234 mm
Shaft turning angle
17 degrees
Footprint
Compact
Discharge method
Oscillating depositor head
Nozzle layout change
Transfer plates
Material finish
Satin finish stainless steel
Hopper capacity
96 pistons

Custom Options


Control panel type
Allen-Bradley Panel View 600
Drive mechanism
Inline planetary gearbox and servo motor
Nozzle layout customization
Change of transfer plates
Discharge method
Oscillating depositor head
Piston customization
Adjustable piston strokes and speeds
