Dosing systems are a line of hoppers, feeders, filling machines, and checkweighers that operate in sync to dispense materials accurately. Dosing is an essential feature of the packaging process, whether you’re filling shampoo bottles or tea bags. But dosing equipment is critical for formulations, too, particularly in the pharmaceutical and chemical industries. Imprecise dosing may cause quality degradation in the best-case scenario. In the worst scenario, it creates serious health risks.

Dosing

The fishmeal powder market forecast shows that its global market value will reach USD 10.3 billion by 2025. Expanding since 2019, at an annual growth rate of 6.5%. Fishmeal powder production has strong business potential with the increase of applications in animal feed, pet food, and fortified foods.

Fishmeal powder

A checking weigher recognized for receiving and shipping bulk materials, typically in mills and warehouses etc. It is reliable for constant operations.


<h2>Hassle free and high-capacity bulk weighers</h2>
The W SERIES bulk weighers from PT Chronos for receiving and shipping bulk material stand out for their accuracy, performance and reliability. These electronically controlled weighers designed for bulk materials are normally put to use in grain silos, the feed / food industries, mills, warehouses, etc.

The weigher output is dependent on the size of the weigh hopper, which can be up to 10 tons capacity. These High-capacity bulk weighers are manufactured in welded steel and are dust-tight. In feed and weigh hopper are equipped with pneumatically operated (twin) gates. The weigh hopper has an inspection door and frame to place calibration weights.

High-capacity bulk weighers

Handling powdered and granulated materials in pneumatic conveying systems requires consistent, safe valve operation.


<h2>Dose and discharge materials under demanding conditions</h2>
TBMA supplies three heavy duty rotary valves, each suited for a specific application purpose. The TBMA H-AR type valve functions mainly as an air or explosion barrier and can be employed as a protective system up to 10 bar when handling dust explosion hazardous materials. The TBMA H-GR type blowing seals are employed in the direct dosing of powdered and granulated materials into pneumatic conveying systems. The TBMA H-AX rotary airlock valves are used for easy discharging of even very poor flowing materials.

Heavy duty rotary valve

Short switching times are often required when diverting or combining powder or granular solids in conveying handling systems.


<h2>Switch channels quickly in pneumatic and vacuum conveying lines</h2>
The dual channel diverter valve type TWD from TBMA is designed to provide the shortest possible switch over time for a maximum system pressure of 2 bar. Handling temperatures up to 120°C, the powerful pneumatic actuator is connected to plug by means of lever in this totally self-contained switching valve. With diverting angles of 35°, these valves are available in five sizes ranging from DIN50 up to DIN125.

Dual channel plug diverter valve

The varying properties of dry powder products mean that specialized feeders are required for dispensing them into the feed screw. Bad-flowing and compacting type powders can be damaged by internal agitation which causes bridging and ratholing of the product.


<h2>Accurately dose any dry substance without damage</h2>
The walls of all Hethon feeders are massaged with paddles from the outside to keep the powder moving without being damaged by stirring arms or internal agitators. This ensures efficient filling of the feed screw for optimum volumetric performance.

The capacity is controlled by frequency inverters for volumetric machines and for continuous or batch-based gravimetric dosing, an advanced weight control system is used.

The Hethon range of feeder models 40, 50, 60, 70, and 80 are available with a standard, FDA, antistatic, or chlorine resistant flexible hopper and can handle capacities anywhere from 150 to 32,000 liters per hour.

Hethon feeders have applications in the ceramic, chemical, environmental, food, paint, pharmaceutical, plastic, and rubber industries.

&nbsp;

Feeder with flexible wall hopper

Find production technology for Fishmeal powder dosing, and connect directly with leading machine manufacturers worldwide

Fishmeal powder dosing

Which fishmeal powder dosing equipment do you need?

High-capacity bulk weighers

Heavy duty rotary valve

Dual channel plug diverter valve

Feeder with flexible wall hopper

There is currently no equipment listed with your specified properties, but we are sure we can help you. Try us!Contact us
