Tube feeder for pharmaceutical and personal care industries

Optimize your production line with this high-speed tube feeder, designed to precisely sort and orient tubes for seamless integration into complex manufacturing processes.

Sorts and Feeds Tubes with Precision

The ADMV TF200 from ADMV is a cutting-edge tube feeder designed to enhance your production line efficiency by sorting and feeding tubes with exceptional precision. Ideal for pharmaceutical, personal care, and chemical manufacturers, this equipment excels in handling tubes of various diameters and lengths, thanks to its innovative blade elevator and chain feeding mechanism. The system supports a high throughput of up to 200 tubes per minute, ensuring seamless integration into existing high-speed operations.

The ADMV TF200 is proficient in processing diverse tube types, from plastic and laminate to aluminum, providing versatility across product lines such as toothpaste, shaving foam, and industrial lubricants. Its ergonomic design, featuring an easy changeover system with color coding and multi-format capability, allows for quick adjustments to production needs.

This equipment not only optimizes performance with a substantial 120 dm³ hopper for bulk storage but also maintains operational efficiency with a minimal footprint. Enhanced automation and control are achieved through PLC integration, ensuring smooth operation within your production workflow. Designed with wear-resistant materials, the ADMV TF200 boasts durability and low maintenance requirements, making it an essential asset for maintaining a continuous, high-speed production line.

Benefits

  • Increases productivity with rapid sorting and feeding up to 200 tubes per minute.
  • Enhances operational flexibility with easy changeover and multi-format capability.
  • Minimizes maintenance and downtimes with a robust, ergonomic design.
  • Integrates seamlessly into high-speed production lines, reducing workflow disruption.
  • Ensures precise orientation and feeding, improving product consistency and quality.

General


Applications
Skincare,Oral care,Personal care products,Cosmetics,Otc products,Industrial goods,Liquid soaps,Men's grooming,Chemical goods,Pharmaceuticals
End products
Otc pain relief gel,Anti-dandruff shampoo,Aftershave lotion,Face scrub,Mascara,Toothpaste,Mouthwash,Hand sanitizer,Moisturizer,Shaving foam,Face cream,Lip balm,Capsules,Sunscreen lotion,Industrial lubricants,Antibacterial soap,Ceramic coating solution,Foot cream,Shampoo,Cleaning agents
Steps before
Bulk Loading,Tube Sorting
Steps after
Filling,Sealing,Packing
Input ingredients
bulk tubes,tubes 13 mm to 22 mm diameter,tubes 40 mm to 100 mm length,sensitive tubes
Output ingredients
oriented tubes,fed tubes
Market info
ADMV, part of Coesia Group, is known for designing and manufacturing customized industrial automation solutions, particularly in the assembly and packaging sectors, offering advanced technological innovations tailored to meet specific client needs.

Technical Specifications


Max speed
200 ppm
Machine depth
1625 mm
Machine height
2220 mm
Machine length
2980 mm
Machine weight
1000 kg
Capacity
90 dm³
Hopper storage capacity
120 dm³
Max air pressure
6 bar
Tubes diameter range
13 mm to 22 mm
Tubes length range
40 mm to 100 mm

Operating Characteristics


Working mechanism
Blade elevator and chain feeding device
Maximum speed
200 tubes per minute (tpm)
Product orientation
Tube fed horizontally
Batch vs. continuous operation
Inline Continuous
Changeover time
Easy changeover with color coding
Automation level
Integrated system with linked machines
Loading method
Easy and ergonomic loading
Feeding capacity
Tube diameter 13 mm to 22 mm,Length 40 mm to 100 mm

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Product type Characteristics


Tube Size
Diameter
Tube Material Compatibility
Plastic,Laminate,Aluminum

Physical Characteristics


Machine depth
1625 mm
Machine height
2220 mm
Machine length
2980 mm
Machine weight
1000 kg
Footprint
Compact
Hopper storage capacity
120 dm3
Tube size compatibility
13 mm to 22 mm diameter,40 mm to 100 mm length
Product orientation
Tube fed,horizontally
Discharge method
Blade elevator and chain feeding

Custom Options


Easy Changeover
Color coding
