Tomato paste processing line

Streamline your tomato processing with our comprehensive production line, ensuring high-quality tomato-based products through automated cleaning, pulping, and sterilization steps, tailored to meet large-scale production requirements and varying packaging forms.

Processes Fresh Tomatoes into Various Concentrated Products

The Tomato Paste Production Line from Zhengzhou Taizy Machinery Co., Ltd. is designed for efficient transformation of fresh tomatoes into a range of concentrated tomato-based products. This line utilizes a multi-stage processing system, encompassing cleaning, inspecting, crushing, enzyme inactivation, refining, concentration, sterilization, and filling operations. It seamlessly integrates into existing production lines, catering to food manufacturers and processing plants by addressing the complexities of large-scale sauce, ketchup, and puree production.

Capable of handling from 1 to 1500 tons per day, this automated line offers customizable capacity to suit various production needs. Its continuous operation system, bolstered by PLC control, ensures smooth workflow with reduced manual intervention. Designed with energy efficiency in mind, the line employs vacuum concentration technology to preserve flavors while minimizing energy use.

Constructed from stainless steel, the machines provide excellent corrosion resistance for long-lasting performance in food processing environments. The production line can be tailored with different equipment options such as bagged or canned packaging machines, meeting diverse customer requirements. Compliance with industry standards assures quality and safety in operation, supported by customizable engineering solutions for tailored applications.

Benefits

  • Increases production efficiency with continuous operation and minimal manual intervention.
  • Customizable system capacity caters to small, medium, and large-scale operations for optimal output.
  • Preserves product quality and taste by employing vacuum concentration at low temperatures.
  • Enhances versatility with multiple packaging options, including bags and cans, to meet diverse market demands.
  • Reduces energy consumption through advanced motor control during concentration and processing stages.

General


Applications
Ketchup,Sauces,Tomato puree,Food production,Tomato-based products,Fruit and vegetable processing
End products
Concentrated tomato sauce,Canned ketchup,Tomato powder,Tomato paste,Bagged tomato sauce
Steps before
Hoisting,Cleaning,Picking,Crushing,Preheating enzyme inactivation
Steps after
Concentration,Sterilization,Filling,Packaging
Input ingredients
fresh tomatoes
Output ingredients
tomato paste,tomato sauce,ketchup,tomato puree,concentrated tomato paste,varied concentrations of tomato paste (28%-38%)
Market info
Taizy Food Machinery is known for manufacturing industrial food processing equipment, specializing in engineered-to-order (ETO) machinery. They have a reputation for innovative, high-quality solutions tailored to meet various customer specifications globally.

Technical Specifications


Production capacity
1–1500t/day
Final product concentration
28%–38%
Automation
Automatic
Packaging type
Bagging / Filling
Material used
Fresh tomatoes
Customizability
Yes

Operating Characteristics


Continuous production
Yes
Automation level
PLC / SCADA
Batch vs. continuous operation
Inline Continuous
Cleaning method
CIP
Changeover time
Minimal

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Product type Characteristics


Heat sensitivity
Low-temperature evaporation

Physical Characteristics


Machine footprint
Customizable
Tank shape and size
Customizable based on capacity
Feed/discharge method
Automatic via hoist and conveyor systems
Material of construction
Stainless steel
System layout
Linear or modular

Custom Options


Control panel type
Standard/Customized
Hoist length and angle
Customizable
Picking machine length
Customizable
Buffer tank size
Customizable
Packaging machine type
Bag/Cans/Custom
