Tamper evident banding system

Ensure product integrity with a high-speed system designed to apply tamper-evident bands efficiently, integrating seamlessly into existing packaging lines for continuous operation.

Applies Tamper-Evident Bands on Containers

The AccuSleever from Biner Ellison is a dynamic machine designed to apply tamper-evident bands efficiently across various packaging lines. Engineered for robust continuous operation, it leverages a servo-controlled band delivery system to ensure precise application on containers at rates of up to 65 per minute. Tailored for industries handling beverages, pharmaceuticals, and personal care products, this machine expertly manages the banding process for products like juice bottles, vitamin supplements, and shampoo containers. It features an adjustable C-frame and a user-friendly touch screen interface for seamless integration into existing lines, supporting quick changeovers with minimal component adjustments. Enhanced with options such as heat tunnel addition and precision positioning controls, the AccuSleever offers optimal adaptability for specific production needs. With a sleek sanitary stainless steel construction, it promises durability and ease of maintenance, while optional thermal printers and film management sensors allow further customization. Ideal for continuous, high-speed operations, it is an essential asset in your packaging department to elevate product security.

Benefits

  • Enhances product security with tamper-evident sealing, fostering consumer trust.
  • Increases production speed with efficient operation up to 65 containers per minute.
  • Seamlessly integrates into existing lines with an adaptable C-frame design.
  • Simplifies operation and reduces downtime with an intuitive touch screen interface.
  • Offers versatile application for diverse product types including liquids and solids.

General


Applications
Beverages,Personal care products,Nutraceuticals,Household products,Cosmetics,Food products,Industrial chemicals,Pharmaceuticals
End products
Face creams,Sauces jars,Chemical containers,Vitamin supplements,Juice bottles,Shampoo bottles,Household cleaning bottle
Steps before
Bottle Unscrambling,Container Conveyor Setup
Steps after
Heat Shrink Tunnel Processing,Labeling,Packing
Input ingredients
containers,heat shrinkable bands,film
Output ingredients
banded containers,tamper evident bands
Market info
Accutek is known for manufacturing high-quality engineered-to-order (ETO) equipment, specializing in custom automation and packaging solutions. They are reputed for their innovation, reliability, and ability to meet complex industrial needs.

Technical Specifications


Speed
65+ containers per minute
Automation
Touch screen controlled
Container Size
3/8
Label Size (Lay Flat Size)
22mm – 95mm
Electrical Requirements
110VAC
Air Requirements
100 PSI
Dimensions (H x L x W)
72 x 17 x 44.5 inches
Weight
120 lbs (54.43 kg)
Speed
105 CPM*

Operating Characteristics


Automation level
Touch screen controlled
Changeover time
Easy changeover with minimum part changes
Batch vs. continuous operation
Continuous inline
Integration capability
C-Frame design for easy integration

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Product type Characteristics


Container size
3/8
Label size (Lay Flat Size)
22mm – 95mm
Tamper evident banding
Heat shrinkable bands

Physical Characteristics


Machine footprint
72" height x 44.5" width x 17" length
Weight
120 lbs. (54.43 kg)
Container Size
3/8
Label Size (Lay Flat Size)
22mm – 95mm
Control panel type
Touch screen display with job memory
Discharge method
Conveyor system
Frame design
C-Frame design

Custom Options


Control panel type
Touch screen display
Integration possibilities
C-Frame design for easy integration
Changeover time
Minimum of part changes
