Rotary overflow filler for non-carbonated liquids

Achieve precise fill levels effortlessly with a high-speed rotary overflow solution, ensuring consistent visual presentation across various container shapes and volumes, ideal for handling diverse liquid applications such as beverages and personal care products.

Ensures Consistent Liquid Level Filling

The ROF-40 Rotary Overflow Filler from Accutek Packaging is a high-speed solution for accurately filling non-carbonated liquids in various container types. Utilizing fill-to-level technology, it consistently delivers precise fill levels, even in containers with shape or volume irregularities. Designed for beverage, personal care, and industrial chemical industries, it efficiently handles applications such as bottled water, liquid soaps, and motor oils. With a capacity reaching up to 600 containers per minute, it significantly enhances production line efficiency. The system is PLC-controlled, offering seamless integration into existing lines, and features touch screen controls for ease of operation. Its versatility is further increased with options like explosion-proof configurations and sanitary conveyor systems. Constructed from materials compatible with corrosive or heated products, this machine meets stringent industry standards for reliability and performance. Easy integration with downstream capping and labeling equipment ensures a streamlined bottling process.

Benefits

  • Enhances production speed, filling up to 600 containers per minute, minimizing bottling time.
  • Ensures uniform fill levels, reducing product waste and maintaining product consistency.
  • Supports a wide range of liquids and container materials, offering flexibility across multiple product lines.
  • Reduces labor costs through intuitive touch screen controls and automated operations.
  • Available with explosion-proof options, ensuring safety in volatile environments.

General


Applications
Beverages,Personal care products,Motor oils,Household chemicals,Perfumes,Non-carbonated liquids,Cosmetics,Essential oils,Food products,Industrial chemicals,Pharmaceuticals
End products
Fruit juice drinks,Bottled water,Perfume bottles,Urethane adhesives,Household cleaning solutions,Hand sanitizer,Silicone oil,Motor oil,Ink bottles,Vegetable oil,Milk,Essential oil vials,Liquid soap,Salad dressing,Makeup remover,Tomato juice,Iced tea,Shampoo,Pharmaceutical liquid syrups
Steps before
Bottle Unscrambling,Container Inspection
Steps after
Capping,Labeling,Packing
Input ingredients
Water,Fruit Juices,Extracts,Liquid Tea,Liquid Coffee,Food Coloring,Vegetable Oil,Milk,Tomato Juice,Some Salad Dressings,Perfumes,Essential Oils,Ink,Thin Liquid Soap,Shampoos,Light Makeup Remover,Motor Oil,Urethane,Silicone,Urine,Alcohol
Output ingredients
Bottled Water,Packaged Fruit Juices,Packaged Extracts,Filled Liquid Tea Containers,Filled Liquid Coffee Containers,Colored Food Products,Bottled Vegetable Oil,Packaged Milk,Bottled Tomato Juice,Packaged Salad Dressings,Bottled Perfumes,Packaged Essential Oils,Packaged Inks,Bottled Thin Liquid Soap,Packaged Shampoos,Packaged Makeup Removers,Bottled Motor Oil,Packaged Urethane,Packaged Silicone,Packaged Urine Samples,Bottled Alcohol
Market info
Accutek is known for manufacturing high-quality engineered-to-order (ETO) equipment, specializing in custom automation and packaging solutions. They are reputed for their innovation, reliability, and ability to meet complex industrial needs.

Technical Specifications


Speed
240 CPM
Capacity
1 oz – 1.3 Gal (30mL – 5L)
Viscosity Range
1-2000 cp
Automation
Touch screen control package
Electrical Requirements
220/240 VAC,20 AMP,3 Phase
Air Requirements
100psi @ 5 - 10 CFM
Height
89 inches
Length
54 inches
Width
61 inches
Weight
2200 lbs. (997.90 kg)
Foamy Product Capability
Yes
Corrosive Product Capability
Yes
Heated Product Capability
Yes
Container Type Compatibility
Glass,Plastic,Metal

Operating Characteristics


Working Mechanism
Rotary Overflow
Integrated Steps
Fill-to-level technology
Batch vs. Continuous Operation
Continuous
Automation Level
Touch screen control package
Changeover Time
N/A
Cleaning Method
Manual / CIP
Container Compatibility
Glass,plastic,metal

Material Compatibility


Corrosive resistance (e.g. acids)
Yes
Density/particle size
1-2000 cp viscosity

Physical Characteristics


Compact footprint
Height
Weight
2200 lbs. (997.90 kg)
Fill Size
1 oz – 1.3 Gal (30mL – 5L)
Container Compatibility
Glass,plastic,and metal containers
Discharge method
Overflow Filling
Control Panel Type
Touch screen control package

Custom Options


Control panel type
Touch screen control package
Integration possibilities
Electronic variable speed controls
Specialty Pumps Available
Yes
Explosion Proof option
Available
Teflon seals and hoses
Available
Sanitary Conveyor System
Available
