Rotary bottle rinser for high-speed production lines

Ensure thorough cleaning and preparation of containers with a high-speed rotary rinser, optimizing rinsing and draining processes to enhance production efficiency.

Rinses and Drains Containers Efficiently

The R-Rinser W52-24 from Accutek Packaging is an efficient rotary bottle rinser, ideal for high-speed production lines in the beverage, pharmaceutical, and cosmetics industries. Utilizing a self-contained recirculating liquid system, it provides thorough rinsing, cleaning, and draining of containers. Customizable rinse cycles, including ionized air treatment, add versatility. With a capacity of 240 CPM, it seamlessly integrates into bottling operations, driven by touch screen controls and management lockout features. Constructed with a boxed tube sanitary stainless steel frame, it ensures durability and safety. Compliance with industry standards is maintained, and options for multi-cycle rinsing and electronic integration enhance its functionality, making it a robust choice for manufacturers seeking efficiency and reliability.

Benefits

  • Enhances product quality by preventing cross-contamination with its "no bottle-no rinse" feature.
  • Increases production efficiency with high-speed operation up to 240 CPM.
  • Minimizes labor requirements through tool-less change parts and fast changeover.
  • Adapts to different production needs with customizable rinse cycles and ionized air options.
  • Ensures operational safety with interlocked safety guarding and management lockout controls.

General


Applications
Beverages,Sauces,Personal care products,Bottled water,Household chemicals,Nutraceuticals,Liquid detergents,Pharmaceuticals
End products
Ketchup,Bottled mineral water,Facial cleansers,Dish soap,Cough syrup,Laundry detergent,Bottled supplements,Juice,Soft drinks
Steps before
Bottle Unscrambling,Container Sorting
Steps after
Filling,Capping,Labeling,Inspection,Packaging
Input ingredients
bottles,containers,water,cleaning solutions,ionized air
Output ingredients
clean bottles,drained containers
Market info
Accutek is known for manufacturing high-quality engineered-to-order (ETO) equipment, specializing in custom automation and packaging solutions. They are reputed for their innovation, reliability, and ability to meet complex industrial needs.

Technical Specifications


Max Fill Size
128 oz
Electrical Requirements
220/240 VAC,20 AMP,3 Phase
Air Requirements
220/240 VAC,20 AMP,3 Phase
Dimensions (Height)
72
Dimensions (Length)
86
Dimensions (Width)
92
Weight
apx. 2000 lbs. (907 kg)
Speed
240 CPM
Automation
Touch screen control,job memory,tooling memory
Cleaning Method
Self contained recirculating liquid system

Operating Characteristics


Working mechanism
Rotary
Integrated steps
Rinse-fill-cap
CIP/SIP
Self contained recirculating liquid system
Batch vs. continuous operation
Inline Continuous
Automation level
PLC with touch screen controls
Cleaning method
Variable water or cleaning solutions
Changeover time
Fast changeover with minimal tooling
Automation level
PLC / Touch screen managed

Material Compatibility


Corrosive resistance (e.g. acids)
Yes
Cleanability
High
Biological compatibility
Yes
Abrasion resistance
Yes

Physical Characteristics


Machine footprint
Length 86",Width 92",Height 72"
Weight
Approx. 2000 lbs (907 kg)
Frame Material
Sanitary stainless steel
Control panel type
Color touch screen
Conveyor Length
10’ conveyor shell
Rinse cycle
Multiple cycle capable
Liquid system
Self contained recirculating liquid system
Lockout feature
Management lockout
Toolless change parts
Fast change over with minimal tooling

Custom Options


Control panel type
Touch screen controls
Electronic Integration to filler
Available
Multi cycle rinse
Upgrade option
Tool less change parts
Available
Upgrade to high temperature
Available
