Inline chillers for ethanol extraction

Streamline your ethanol extraction process by quickly chilling alcohol to optimal temperatures, enhancing product quality and reducing subsequent processing time, all within a compact system design.

Rapidly Pre-Chills Ethanol for Extraction

The DC-40 Inline Chiller from Delta Separations offers a compact solution to ethanol pre-chilling challenges in extraction processes. It eliminates the need for ultra-low freezers by rapidly cooling ethanol from 20°C to -40°C within 20 minutes. Designed for cannabis and hemp industries, it contributes to the production of high-quality cannabis distillate, CBD oil, and terpene-rich hemp oil. With an ETL-certified condenser and compliance with C1D2 specifications, the DC-40 ensures safety and reliability. The integrated VFD ethanol pump and microprocessor controller enhance operational control, while Modbus or Ethernet compatibility allows seamless integration. This chiller helps reduce HVAC costs and supports continuous, industrial-scale operations efficiently.

Benefits

  • Optimizes extraction efficiency by rapidly pre-chilling ethanol, minimizing processing time.
  • Conserves lab space with a compact design, eliminating bulky ultra-low freezers.
  • Enhances safety and compliance with C1D2-certified components.
  • Reduces operational costs with energy-efficient chilling and lower HVAC demands.
  • Integrates seamlessly with existing systems via Modbus or Ethernet connectivity.

General


Applications
Cannabis oil,Hemp products,Cannabinoid oil,Ethanol extraction
End products
Cannabis distillate,Cbd oil,Thc oil,Full-spectrum hemp oil,Winterized hemp extract,Terpene-rich hemp oil
Steps before
Alcohol Preparation,Mixing,Setup and Calibration,Solution Pre-chill
Steps after
Extraction,Filtration,Evaporation,Distillation,Winterization
Input ingredients
ethanol,alcohol solution,raw hemp,cannabis
Output ingredients
chilled ethanol,cannabinoid oil,crude cannabinoid oil
Market info
Delta Separations is known for its expertise in manufacturing extraction and distillation equipment for the cannabis and hemp industries, providing high-quality engineered equipment that meets industry standards and regulations for efficient processing.

Technical Specifications


Cooling temperature
-40°C
Cooling time
20 minutes
Capacity
30 gallons
Automation
Microprocessor Controller
Compatibility
Modbus or Ethernet
Footprint
Compact
HVAC Costs
Reduced

Operating Characteristics


Automation level
VFD Ethanol Pump / Microprocessor Controller
Batch vs. continuous operation
Inline Continuous
Energy efficiency
Reduced HVAC Costs
Cooling time
Chill 30 gallons of alcohol from 20°C to -40°C in 20 minutes
Cleaning method
CIP (assumption based on typical industry practice)
Space efficiency
Compact footprint

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Physical Characteristics


Compact footprint
Yes
Chill temperature range
20°C to -40°C
Chilling capacity
30 gallons in 20 minutes
Footprint
Compact

Custom Options


Compact footprint
Yes
Control panel type
Microprocessor Controller
Integration Possibilities
Modbus or Ethernet Controller Compatibility
