Industrial pre-cleaners for raw material safeguarding

Effectively eliminate foreign objects from your raw materials with this advanced pre-cleaner, safeguarding your entire production line and minimizing damage to transport and process equipment while ensuring seamless, uninterrupted operations.

Separates and Purifies Bulk Raw Materials

The Ottevanger Pre-cleaner, featuring a durable rotary drum design, addresses essential cleaning needs in bulk material handling. Designed to separate foreign objects like stones and wood from raw inputs, it ensures high operational reliability for industries such as feed processing and grain milling. Its rotating drum, equipped with a 40×40 mm mesh screen, efficiently screens out unwanted materials, directing them to a secondary outlet, while the good material continues to subsequent processes. Operating at continuous throughput, it serves well in processing capacities up to several tons per hour, making it ideal for high-volume operations. It integrates seamlessly into existing lines, with optional dust aspiration and bypass control for cleaner air and operational versatility. Constructed with replaceable manganese steel wearing plates, it promises durability and reduced maintenance downtime. Additionally, its enclosed design minimizes dust emission, supporting a cleaner work environment. Customizable for varying operational needs, it offers engineering support for specialized applications.

Benefits

  • Enhances equipment protection by removing harmful foreign objects from raw materials.
  • Supports continuous operation, maximizing throughput with minimal interruptions.
  • Decreases maintenance costs with durable construction and replaceable wear plates.
  • Improves air quality on-site with optional dust aspiration integration.
  • Customizable for specific production needs, aiding in seamless process integration.

General


Applications
Grains,Pet food,Oilseed processing,Soybean processing,Aqua feed,Concentrates,Premix,Compound feed
End products
Pelletized cattle feed,Refined soybean oil,Processed soybean meal,Floating fish pellets,Mineral-vitamin premix,Protein concentrate blend,Dry dog kibble,Milled wheat flour
Steps before
Product intake,Conveying
Steps after
Dosing,Weighing
Input ingredients
raw materials,wood pieces,stones,clothes,contaminated materials,ropes,strings
Output ingredients
good material,oversized material,screened material,finer screening removal
Market info
Ottevanger Milling Engineers is renowned for designing and manufacturing innovative milling equipment and complete production lines for the grain processing industry, including feed mills, flour mills, and biomass processing, with a reputation for quality, efficiency, and customized solutions.

Technical Specifications


Drum size
600–1800 mm
Capacity
50–2450 kg/h
Mesh screen hole size
40×40 mm
Motor drive
Shaft mounted geared motor
Dust aspiration connection
Included
Material bypass valve
Manually operated
Sight glass
Equipped
Automation
Optional sensors for bypass valve position
Material
Manganese steel wear plates
Weight
100–2450 kg

Operating Characteristics


Working mechanism
Rotating drum with mesh screen
Cleaning method
Manual bypass,dust aspiration
Batch vs. continuous operation
Continuous
Automation level
Control panel with optional sensors
Changeover time
Manual valve operation
Dust control
Connection for dust aspiration
Catching device for ropes and strings
Optional installation

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Physical Characteristics


Basket/Cone/Drum shape
Rotating drum
Basket/Cone/Drum size
Diameter 600-1250 mm
Feed method
Internal drum feeding
Discharge method
Gravity with flight transport
Screen size
40×40 mm mesh

Custom Options


Connection for dust aspiration
Optional
Bypass valve
Manually operated
Replaceable wearing plates
Manganese steel
Extra connection for aspiration
Optional
Drum size
600–3100 mm diameter
