In-line mayonnaise emulsifying system

Streamline your sauce and dip production with a system designed for efficient emulsification, mixing, and pasteurization, ensuring consistent quality and flavor in every batch.

Emulsifies and Processes Sauces and Dips

Dutch Process Technology offers a versatile solution with their skid-mounted Inline Emulsifying System, ideal for the efficient production of sauces and dips. This system utilizes a single-pass emulsifying process to ensure consistency across a range of products, from mayonnaise to salsa, catering to diverse consumer demands. Designed for continuous and batch operations, it handles both low and high-viscosity applications, ensuring flexibility for food manufacturers.

The system boasts an automatic flow calibration and recipe storage feature, facilitating seamless integration into existing production lines. Suitable for producing emulsified sauces with up to 80% oil content, it also incorporates optional premix and inline mixing capabilities for added versatility. Constructed from stainless steel, it is equipped with an integrated CIP system for efficient and hygienic cleaning, minimizing downtime.

Whether producing traditional kettle-cooked BBQ sauce or a contemporary low-fat dressing, this equipment supports a variety of end-products through its multi-purpose functionality, making it essential for modern food processing companies seeking to optimize their condiment offerings.

Benefits

  • Enhances product consistency through precise emulsification and mixing.
  • Minimizes operational downtime with integrated CIP cleaning.
  • Expands production capabilities with support for both complex and simple recipes.
  • Reduces setup time with automatic flow calibration and recipe storage.
  • Ensures versatile production with compatibility across a wide range of viscosities and product types.

General


Applications
Sauces,Emulsified sauces,Dips,Condiments,Dressings
End products
Ketchup,Hummus,Cheese sauce,Gravy,Mayonnaise,Cranberry sauce,Salsa,Bbq sauce
Steps before
Recipe formulation,Premixing,Ingredient preparation,Starch paste preparation
Steps after
Cooling,Packing,Labeling
Input ingredients
oil,egg powder,sugar,salt,sorbate,starch paste
Output ingredients
mayonnaise,ketchup,BBQ sauce,cheese sauce,gravy,cranberry sauce,salsa,hummus
Market info
Dutch Process Technology is known for its expertise in designing and manufacturing custom-engineered industrial process equipment, particularly for the chemical and pharmaceutical industries, with a strong reputation for quality and innovation.

Technical Specifications


Automation
Recipe storage,touch screen controls
Batch size
300,500,1000,1500,2000,2500,3000 litre
Batch vs. continuous
Batch or inline
Cleaning method
CIP cleaning
High viscous product capacity
up to 500,000 cps
Heat exchange surface
Large
Control panel type
Touch screen
Material
Stainless steel duplex 1.4462

Operating Characteristics


Working mechanism
In-line emulsifying
Integrated steps
Mixing,dispersing,emulsifying,cooking,cooling,vacuum processing
CIP principles
Integrated CIP cleaning
Batch vs. inline flow
Turnkey skid mounted batch and in-line system
Automation level
Recipe storage,touch screen controls
Energy efficiency
Dual heat exchange cylinders

Material Compatibility


Corrosive resistance (e.g. acids)
Stainless steel duplex 1.4462
Density/particle size
1" particulates

Physical Characteristics


Batch size
300,500,1000,1500,2000,2500,3000 litre
Footprint
Compact design
Heat exchange surface
Large
Maximum Viscosity
Up to 500,000 cps
Emulsifying type
In-line / Single pass
Material
Standard stainless steel duplex 1.4462
Heat exchange cylinders
Dual

Custom Options


Control panel type
Touch screen controls
Recipe storage
Available
Integration possibilities
CIP system integration
Batch size options
300,500,1000,1500,2000,2500,3000 litre
Automation level
Automatic flow calibration
Emulsifying system type
Single pass inline emulsifying
CIP system
Integrated CIP cleaning
Optional features
Premix system,inline mixer
