Full body sleeving systems for packaging applications
Achieve seamless, high-speed labeling precision for diverse container types with this advanced sleeving technology, designed to integrate efficiently into your packaging process and boost productivity.
Applies Shrink Sleeves to Containers
The SL1-150 from Accutek Packaging is a compact full body sleeving machine designed to enhance your production line efficiency. It applies shrink sleeves at speeds up to 150 containers per minute, ideal for packaging in food and beverage, personal care, and pharmaceutical industries. The machine accommodates a range of container sizes and uses simple touch screen controls, making it both versatile and user-friendly. Its stainless steel construction ensures durability, while optional upgrades such as heat tunnels and motorized film take-off enhance the machine’s adaptability. Designed to integrate seamlessly into existing production lines, it offers rear load low height feeders for space-constrained facilities. The SL1-150 boasts an energy-efficient design with minimal electronics, contributing to reduced operational costs. For specialized needs, customization options and engineering support are available to tailor the machine to your specific requirements.
Benefits
- Maximizes productivity with up to 150 containers per minute throughput.
- Reduces manual labor with user-friendly touch screen controls.
- Saves space in compact production facilities with a streamlined design.
- Lowers operational costs with an energy-efficient system.
- Enhances flexibility with customizable film management and optional upgrades.
- Applications
- Beverages,Personal care products,Nutraceuticals,Cosmetics,Food and beverage containers,E-cigarettes,Pharmaceuticals
- End products
- Vitamin supplement bottles,E-liquid bottles,Soda bottles,Cough syrup bottles,Ketchup bottles,Lotion bottles,Shampoo bottles
- Steps before
- Bottle Unscrambling,Material Handling
- Steps after
- Shrink Tunneling,Packing,Labeling,Inspection
- Input ingredients
- shrink sleeve film,containers,bottles,film roll,labeling film
- Output ingredients
- labeled bottles,sleeved containers,packaged products,shrink-wrapped items
- Market info
- Accutek is known for manufacturing high-quality engineered-to-order (ETO) equipment, specializing in custom automation and packaging solutions. They are reputed for their innovation, reliability, and ability to meet complex industrial needs.
- Speed
- Up to 150 CPM
- Film Size (Lay Flat)
- 16mm – 150mm
- Cut Length
- 16mm – 200mm
- Electrical Requirements
- 110VAC – 15 AMPS (220VAC Optional)
- Dimensions (Height)
- 77.8 inches
- Dimensions (Length)
- 63 inches
- Dimensions (Width)
- 53.5 inches
- Weight
- 350 lbs. (158.75 kg)
- Roll Core Size (Bottles ≤ 4 inches)
- 5-inch core
- Roll Core Size (Bottles > 4 inches)
- 10-inch core
- Max Roll Diameter
- 18.5 inches
- Container Sizes
- 1
- Speed
- Up to 150 CPM
- Automation level
- Easy-to-Use Touch Screen Display
- Batch vs. continuous operation
- Continuous
- Changeover time
- Simple Setup and Memory Features
- Cleaning method
- Sanitary Stainless Steel Control Parts
- Density/particle size
- 0.5–2.5 g/cm³ / 50–1000 µm
- Machine Footprint
- Length
- Compact Design
- Accommodate limited production line space
- Weight
- 350 lbs (158.75 kg)
- Label Size (Lay Flat Size)
- 16mm – 150mm
- Roll Core Size
- For bottles 4 inches and smaller
- For bottles over 4 inches
- 10-inch core
- Max Roll Diameter
- 18.5 inches
- Stainless Steel Construction
- Yes
- Control Panel Type
- Easy-to-Use Touch Screen Display
- Discharge Method
- Rear Load Low Height Feeder
- Control panel type
- Touch Screen Display
- Integration possibilities
- Motorized film take-off
- Machine speed upgrade
- High speed delivery upgrade
- Feeder type
- Rear Load Low Height Feeder
- Sensors
- Film management sensors
- Printing option
- Thermal printer
