Automatic strand pelletizer for reinforced and filled polymers

Optimize your polymer production with precise pelletizing, designed to handle reinforced and filled compositions efficiently, ensuring high-quality output and streamlined operation in demanding manufacturing environments.

Pelletizes and Dewaters Reinforced Polymer Strands

The WSD Series Strand Pelletizers from Bay Plastics Machinery offer an efficient solution for the pelletizing and dewatering of reinforced and filled polymer strands. This equipment utilizes a dry-cut approach, removing surface water through air blowing and vacuum, ensuring dust-free pellet production with low noise levels. Suitable for applications such as glass fiber reinforced polypropylene and talc-filled polypropylene, it is capable of handling up to 2,000–8,000 pounds per hour. Designed to be compact and space-saving, the machine integrates seamlessly into continuous, high-speed production lines. With a cooling length of 5-16 feet and customizable inverter-driven operation, it provides flexibility and efficiency for diverse manufacturing needs.

Benefits

  • Streamlines production with automated start-up and re-threading, minimizing manual intervention.
  • Enhances product quality with dust-free pellets and low noise operation.
  • Optimizes space utilization with a compact design.
  • Accommodates high production demands, processing up to 8,000 pounds per hour.
  • Supports versatile polymer processing, catering to a wide range of applications.

General


Applications
Reinforced polymers,Polymer compounds,Filled polymers,Plastics
End products
Polycarbonate pellets,Abs (acrylonitrile butadiene styrene) pellets,Talc-filled polypropylene,Nylon pellets,Glass fiber reinforced polypropylene,Polyvinyl chloride (pvc) pellets,Polystyrene pellets,Polyurethane pellets,Polyethylene terephthalate (pet) pellets,High-density polyethylene pellets
Steps before
Extrusion,Material Feeding,Pre-heating,Heat Treatment
Steps after
Pellet Cooling,Pellet Drying,Packaging,Quality Inspection,Storage
Input ingredients
reinforced polymers,filled polymers,strands
Output ingredients
dust-free pellets
Market info
Bay Plastics Machinery is known for manufacturing pelletizing equipment and systems, recognized for their innovation and quality in the plastics industry. They specialize in developing customized solutions for polymer processing, focusing on efficiency and reliability.

Technical Specifications


Number of Strands
1 – 130 Strands
Throughput Capacity
2,000 – 8,000 Lb/Hr
Work Width
8″ (200mm) – 40″ (1000mm)
Drive
Inverter
Horsepower (KW)
15 (11) – 60 (45)
Cooling Length
5-16ft (1.5-5m)
Cooling Water
52gpm or 12m3/h – 255gpm or 63m3/h
Strand Speed
Min – Max Ft/min 90-385
Approximate Throughput at 330 ft/min
5,750 lb/hr – 28,775 lb/hr

Operating Characteristics


Working mechanism
Automatic dry cut
Integrated steps
Air blowing,vacuum,pelletizing
Re-threading
Automated
Pellet quality
Dust-free
Noise level
Low
Design
Compact and space-saving

Material Compatibility


Reinforced Polymers
Yes
Filled Polymers
Yes
Dust-Free Processing
Yes

Product type Characteristics


Material type
Reinforced and filled polymers

Physical Characteristics


Machine footprint
Compact and space saving design
Discharge method
Strands carried down the slide to the belt

Custom Options


Control panel type
Inverter-driven
Number of strands
1 - 130 strands
Strand speed
90-385 ft/min
