Automated dry hopping system for large-scale beer production

Achieve seamless dry hopping with reduced oxygen pick-up, optimal aroma extraction, and minimal product loss—transforming your brewing process efficiency and enhancing flavor consistency in large-scale operations.

Enhances Dry Hopping and Fermentation Efficiency

The Iso-Mix External Drive (IMXD) from Alfa Laval revolutionizes beer production by automating dry hopping techniques for volumes ranging from 100 to over 5000 hl. Positioned as a specialist solution, the IMXD smoothly integrates into large-scale brewing operations, enhancing processes such as mixing, dispersion, separation, and fermentation with precision.

At its core, the IMXD employs an external motor to drive an internal shaft, ensuring no fluid-gearing contact, which allows it to handle solid concentrations effectively. Located low in fermenter tanks, it maintains hop suspension for consistent centrifuge feeding, optimizing aroma extraction and minimizing product loss.

Applications of the IMXD encompass the creation of various hop-infused and dry-hopped beers like IPAs and hop-infused lagers. Its robust design accommodates whole hop pellets and slurry forms, offering flexibility in hop introduction. This system is particularly valuable for continuous, automated operations in breweries, from craft to industrial scale.

The IMXD also supports fermentation and cooling by preventing yeast settling, thereby maintaining yeast health and reducing the production of stress-related by-products like SO2 and acetaldehyde. With the capability to potentially reduce fermentation process times and variability, it’s a pivotal component for brewers aiming for efficiency and product consistency.

Benefits

  • Reduces process disruptions and costly shutdowns by preventing blockages in lines and heat exchangers.
  • Minimizes product loss with efficient hop removal through centrifugation.
  • Enhances aroma extraction efficiency, saving on hop usage with optimal dispersion.
  • Maintains yeast health by reducing stress-related by-products, leading to better fermentation results.
  • Integrates seamlessly into existing production lines, supporting diverse hop introduction methods.

General


Applications
Beverage processing,Fermentation,Brewing,Dry hopping techniques,Beer
End products
Craft beer,Double dry-hopped pale ale,Dry-hopped ipa,Dry-hopped stout,Saison with hop infusion,Centrifuge clarified ale,Hazy ipa,Hop-infused lager,New england ipa,Hop-infused wheat beer
Steps before
Fermentation,Dry Hopping Preparation,Hop Introduction
Steps after
Centrifugation,Cooling,Packaging
Input ingredients
hop particles,hop pellets,whole hop pellets,fermentable sugars,yeast,carbon dioxide,circulating fluid
Output ingredients
beer with hop aromas,aroma compounds,yeast in suspension,homogeneous hop suspension,optimal separation
Market info
Alfa Laval is renowned for its expertise in heat transfer, separation, and fluid handling technologies, providing innovative, energy-efficient engineered-to-order solutions for various industries including food, marine, and energy.

Technical Specifications


Capacity
100 to over 5000 hl
Automation
Automated
Cleaning method
Efficient CIP
Residence time
From days to hours
Particle handling
Whole pellets,high tolerance
Mixing configuration
External motor with internal shaft
Process optimization
Fermentation and cooling
Homogenization capability
Yes
Centrifuge compatibility
Constant load maintenance

Operating Characteristics


Working mechanism
External motor-driven mixer
Integrated steps
Mixing,Homogenization,Centrifugation
CIP/SIP
Efficient CIP capability
Batch vs. continuous operation
Batch
Automation level
Automated
Oxygen incorporation control
Minimized

Material Compatibility


Abrasion resistance
High
Cleanability
CIP (Clean-In-Place)
Corrosive resistance (e.g.,acids)
Stainless steel
Biological compatibility
Food-grade
Density/particle size handling
High solids concentration

Physical Characteristics


Compact footprint
Simple and compact design
Tank shape and size
Suitable for medium to large fermenter tanks
Discharge method
Centrifugation
Feed type
Dry Hops
Control panel type
Automated

Custom Options


Control panel type
PLC / SCADA compatible
Integration possibilities
Compatible with existing hop introduction systems
Installation location
Low in the tank,within the cone section
Mixing method
External motor with internal shaft
Hop introduction options
Pre-slurried or gas-blown with CO₂
Process compatibility
Dry hopping,fermentation,maturation,crash-cooling
