If storing and transporting products easily is a problem for your industrial production, then you need palletizing solutions. A pallet is a flat structure, on which containers of the packaged products are stacked to consolidate the product and to make it easier for a forklift to lift the goods for warehousing and transportation. A palletizer is a machine that automates or simplifies the process of stacking product containers onto a pallet. The choice of an industrial palletizer depends on the type of product packaging such as bags, drums, or boxes, the level of automation required, and the in-feed to the palletizer. Palletizers find applications in all major industries including food, chemical, and pharmaceutical.

Palletizing

Phosphorous is literally at the root of the food industry. An essential ingredient in agriculture, it contributes to plant seed formation and root development. But farmers do not simply give their soil a dose of the chemical element. Instead, phosphorous fertilizer processing equipment blends it with other materials to manufacture effective formulas.

Phosphorus fertilizer

Palletize up to 1,800 large industrial bags per hour at a multi-pick-up configuration.


<h2>The most efficient robotic cells for any palletizing need</h2>
The RPL SERIES robot palletizers from Premier Tech Chronos have combined the innovative engineering and control capabilities with leading-edge bag preparation. These robots can palletize up to 1,800 bags per hour at a multi-pick-up configuration.

The heavy duty robotic cell can simultaneously gather bags, bales or containers from many different incoming product lines. This robot palletizer is compatible with all common standard industrial pallets. All our equipment is PLC controlled with user-friendly human-machine interfaces. The RPL SERIES can handle boxes, bundles, cases, cans, drums, trays, bags, bales etc.

Robot palletizer

If you are a relatively large-scale producer, packing and transporting large quantities of products in the shortest time possible would be your top priority. In this case, a customer-specific palletizing solution which reliable industrial robot manufacturers design is required.


<h2>Save time with a high-performance robotic palletizing system</h2>
STATEC BINDER'S PRINCIPAL-R is a high-performance robot palletizer. This palletizing system is highly reliable owing to the prowess of the robot manufacturers. The robot palletizing system uses articulated arm robots with four axes and a rotation of up to 360° in the R-axis. It is particularly suitable for palletizing and depalletizing applications due to its fast and repeatable movement, ensuring a high output in the shortest cycle time. The operation and selection of the pallet patterns are carried out simply via a touch screen. The set-up variants range from a single to a double to a multiple line arrangement.

It can carry out about 1400 cycles per hour. It uses different robot models depending on the desired performance, thus making it highly flexible. The gripper can be tailored according to your application. These include finger, container, or vacuum grabs, as well as customer-specific grabs, depending on the type of bag. It is also optimized for sling bags.

Robot palletizing system

The effective placement and positioning of bags and boxes can be a challenge during the palletizing process. This is important so that the barcodes can be read from the outside. If you need to pack or transport large quantities of product, you need an efficient palletizing solution that can tackle these challenges.


<h2>High level and high-performance palletizer</h2>
STATEC BINDER’S PRINCIPAL-H is a fast, high-level palletizer capable of stacking up to 2400 bags or cartons per hour. It is configured with an empty pallet magazine and an outfeed system. It has a bag flattener at the beginning which ensures that the bags are in shape for stacking and a full pallet removal station. The system has a pallet magazine with high capacity in order to ensure continuous and uninterrupted operation. The pallets stacked in the magazine are automatically separated and prepared for palletizing. The bags to be stacked are passed through the bag pressing belt to make sure they achieve a uniform shape. These bags can be layered according to the input layer pattern. The palletizer is equipped with an overhead rotating device that helps place the bags in the required position for different layer patterns.

The automatic palletizer machine for bags ensures a clean layer pattern by the synchronous belt drive of the layer pusher, which enables the exact positioning of the bags or boxes, as well the motorised side shifters to achieve a stable desired layer. The layer forming plate places the completed layers on the pallet. The pallet is then pressed against the layer forming plate to improve its stability.

Automatic palletizer machine for bags and boxes

Find production technology for Phosphorus fertilizer palletizing, and connect directly with leading machine manufacturers worldwide

Phosphorus fertilizer palletizing

Which phosphorus fertilizer palletizing equipment do you need?

Robot palletizer

Robot palletizing system

Automatic palletizer machine for bags and boxes

There is currently no equipment listed with your specified properties, but we are sure we can help you. Try us!Contact us
