Wet granulation process for pharmaceutical applications

Achieve consistent granule size and uniform mixing with advanced oscillating granulation, optimizing product quality and process efficiency for a wide range of pharmaceutical and food applications.

Processes Powders into Uniform Granules

The Oscilla Granulator from SSPM Systems & Engineers Pvt. Ltd. is designed to optimize granulation processes for pharmaceutical and nutraceutical manufacturers. This equipment features a trolley mount design and a variable frequency drive, allowing for precise control over particle size. The 360° rotation of the impeller, coupled with an adjustable gap between the sieve and impeller, ensures uniform granulation of powders, essential for consistent dosing in tablets, capsules, and protein powders. Capable of processing between 100 to 300 kg per hour, the Oscilla Granulator supports batch operations and integrates seamlessly into existing production lines. Fabricated with SS 316 contact parts for enhanced corrosion resistance and SS 304 non-contact parts, this granulator adheres to industry standards, ensuring reliability in both pharmaceutical and food production environments. Available sieve sizes range from 1 mm to 12 mm, offering versatility in processing different product types. This granulator is ideal for manufacturers needing efficient, consistent granulation to improve the quality of end products such as paracetamol tablets and whey protein powder.

Benefits

  • Ensures consistent product quality with uniform granule size, enhancing dosing accuracy.
  • Increases operational flexibility and efficiency through adjustable processing speeds.
  • Reduces maintenance downtime via robust stainless steel construction.
  • Streamlines production integration with trolley mount design and batch processing capabilities.
  • Enhances compliance with industry standards for pharmaceuticals and nutraceuticals.

General


Applications
Nutraceuticals,Pharmaceutical powder,Supplements,Pharmaceutical tablets
End products
Vitamin d supplements,Paracetamol tablets,Whey protein powder,Fish oil capsules
Steps before
Mixing,Blending,Sifting
Steps after
Drying,Tablet Pressing,Coating,Packing
Input ingredients
Output ingredients
Market info

Technical Specifications


Capacity
100 to 300 Kg/Hr
Sieve Size
1 to 12 mm
Contact Parts Material
SS 316
Non-contact Parts Material
SS 304
Trolley Mount Design
Yes
Variable Frequency Drive
Yes
Impeller Rotation
360°
Gap Adjustment Facility
Between Sieve,Impeller

Operating Characteristics


Working mechanism
Oscillating Granulator
Trolley Mount Design
Yes
Variable Frequency Drive
Yes
360° Rotation of Impeller
Yes
Gap Adjustment
Between Sieve,Impeller
Batch vs. inline flow
Batch

Material Compatibility


Abrasion resistance
SS 316,SS 304
Biological compatibility
SS 316,SS 304
Corrosive resistance (e.g. acids)
SS 316,SS 304

Physical Characteristics


Trolley Mount Design
Yes
Impeller Rotation
360°
Sieve,Impeller Gap Adjustment
Yes
Sieve Size
1/1.5/2/2.5/3/3.5,4/5/6/8/10/12 mm
Construction Material
Contact Parts

Custom Options


Control panel type
Variable Frequency Drive
Discharge method
Trolley Mount Design
Impeller features
360° Rotation of Impeller
Sieve gap adjustment
Gap Adjustment facility between Sieve,Impeller
