Uv Dod Cmyk label and packaging film printer

Achieve high-precision, on-demand printing for narrow-web packaging films and labels with minimal waste and improved production agility.

Prints Pre-cut Labels and Packaging Films

The Hapa 861 from Hapa is a compact UV DOD CMYK piezo inkjet printing system specifically crafted for the pharmaceutical and healthcare industries. What sets this equipment apart is its capability to integrate seamlessly with existing packaging lines that use narrow webs, such as label applicators and sachet machines, ensuring efficient space utilization with its small footprint. Operators benefit from robust DOD technology combined with UV-cured inks, offering high print-position accuracy and durable, high-contrast outputs that minimize reject rates.

This system supports applications across diverse segments, including pharmaceuticals, medical devices, and optical products, producing end-products like blister packs, pre-filled syringes, and diagnostic test strips. The Hapa 861 offers a flexible upgrade path: begin with a single-color setup and scale up to 4 spot colors or full CMYK process printing to meet evolving production needs without extensive overhauls.

Capable of reaching speeds of up to 35 m/min and supporting a maximum printing width of 72 mm, this printer ensures reduced material waste and inventory with its on-demand printing feature, aligning with lean manufacturing principles. It requires minimal maintenance and supports easy operation, enhancing production uptime. Additionally, it provides options such as a Corona station and varied color configurations, positioning it as a future-proof investment adaptable to changing production demands.

Benefits

  • Minimizes inventory with on-demand, just-in-time printing, reducing working capital requirements.
  • Lowers reject rates by ensuring high print-position accuracy with UV-cured inks.
  • Enhances production line flexibility with easy upgrade paths to multi-color printing.
  • Optimizes line integration with a compact design for seamless adaptability.
  • Decreases material and process waste, aligning with sustainable production practices.

General


Applications
Packaging films,Medical devices,Labels,Otc products,Optical products,Ophthalmic solutions,Healthcare products,Laboratories,Injectables,Pharmaceuticals
End products
Contact lens packaging,Adhesive labels for medical devices,Eye drop packaging,Diagnostic test strips,Blister packs,Ampoules,Pre-filled syringes,Sachets for medicated creams,Otc medication blister cards,Laboratory reagent bottles
Steps before
Label design,Material selection,Cutting labels
Steps after
Packaging,Label application,Quality inspection
Input ingredients
pre-cut labels,packaging films,blank materials,preprinted materials,narrow-web strip-packing films,self-adhesive labels
Output ingredients
CMYK printed labels,narrow-web packaging films,single color printed materials,multi-color printed materials,full-color CMYK printed materials
Market info
HAPA, part of the Coesia Group, is renowned for its expertise in developing and manufacturing high-quality inline printing solutions, specifically for the pharmaceutical packaging industry, offering flexibility and customization for complex printing needs.

Technical Specifications


Max speed
35 m/min
Max printing width
72 mm
Max printing length
120 mm
Max web width
105 mm
Min web width
35 mm
Resolution
720 dpi
Machine depth
960 mm
Machine height
1065 mm
Machine length
1002 mm
Machine weight
280 kg

Operating Characteristics


Integration capability
Top-mounted
Automation level
CMYK Digital Printing
Printing mechanism
UV DOD (Drop On Demand) Piezo Inkjet
Footprint
Small
Changeover flexibility
Single to multi-color upgrade path
In-house printing
Just-in-time
Substrate compatibility
Pre-cut labels,Narrow-web films
Energy efficiency
Improved due to reduced line downtime
Downtime reduction
Lower maintenance effort

Product type Characteristics


Material Type
Pre-cut labels,Packaging films

Physical Characteristics


Machine depth
960 mm
Machine height
1065 mm
Machine length
1002 mm
Machine weight
280 kg
Max printing width
72 mm
Max printing length
120 mm
Max web width
105 mm
Min web width
35 mm
Resolution
720 dpi

Custom Options


Printing Color Options
1 to 4 spot or CMYK process color options
Printer Configuration
Single color to 4 spot colors or CMYK
Integration Type
Narrow-web,top-mounted integration
Footprint
Small
Operation Type
Easy to operate
Upgrade Path
Simple upgrade paths from single to multi-color
Stand Version
With unwinder
Corona Station
Optional
