Spiral oven for cooking and browning products with steam and hot air

Optimize your cooking line with a compact spiral oven that ensures even browning and consistent quality using advanced steam and air circulation, perfect for high-volume production.

Continuously Cooks and Browns Food Products

The alco Spiral Oven ASH PRO from JBT is a state-of-the-art spiral oven designed to streamline cooking and browning in food production. Utilizing a spiral conveyor system, it provides even heat distribution and optimal space utilization in your processing line. This equipment is ideal for producing items such as plant-based burger patties, chicken breasts, and lasagna trays. With adjustable belt levels and varying production speeds, it caters to high-speed, continuous operations. The oven integrates seamlessly into automated production lines, featuring a PLC control system for precise recipe management and process monitoring. Energy efficiency is enhanced through high-performance heating elements available in electrical, thermal oil, or steam-powered options. The oven’s highly insulated housing minimizes energy loss, while its CIP-capable belt wash system ensures easy maintenance and hygiene. For customization, the ASH PRO offers multiple belt widths and levels, allowing tailored configurations to meet specific processing needs.

Benefits

  • Maximizes production capacity with a minimal footprint through its space-efficient spiral design.
  • Enhances product quality with uniform cooking and browning via optimized air circulation and steam injection.
  • Reduces energy costs with efficient heating elements and an insulated housing that minimizes heat loss.
  • Supports high-speed, automated operations with customizable belt levels and PLC-controlled systems.
  • Simplifies cleaning and maintenance with an integrated continuous belt wash and CIP setup.

General


Applications
Seafood,Ready meals,Potatoes,Pet food,Meat,Plant-based protein,Vegetables,Poultry
End products
Chicken breasts,Dog kibble,Bacon strips,Vegetable medleys,Lasagna trays,Potato wedges,Plant-based burger patties,Meatless nuggets,Tofu steaks,Cat treats,Fish fillets,Beef meatloaf
Steps before
Portioning,Seasoning,Marination,Injection
Steps after
Cooling,Freezing,Slicing,Packaging
Input ingredients
raw meatloaf,whole chicken,raw burgers,nuggets,raw bacon,raw lasagna,raw pretzels,poultry,meat,plant-based proteins,vegetables
Output ingredients
cooked meatloaf,browned whole chicken,cooked burgers,cooked nuggets,browned bacon,cooked lasagna,cooked pretzels,cooked poultry,browned meat,cooked plant-based proteins,cooked vegetables
Market info
JBT is known for manufacturing innovative industrial machinery and solutions, particularly in the food processing and air transportation sectors, renowned for their advanced technology, reliability, and customer-focused engineered-to-order solutions tailored to specific industry needs.

Technical Specifications


Heating temperature
Up to 230°C
Belt width
400,600,700,1000 mm
Belt levels
5 to 10 levels
Heating method
Electrical,thermal oil,steam-powered
Production speed
Continuously adjustable
Humidity control
Steam injection bars
Process control
PLC-controlled,touch panel
Energy efficiency
Highly insulated housing
Cleaning system
Automatic,continuous belt wash with CIP nozzles
Steam nozzles
Optional for direct steam injection
Dew point control
Optional
Automation level
User-friendly PLC with recipe management

Operating Characteristics


Automation level
Manual / PLC
Batch vs. continuous operation
Continuous
Cleaning method
CIP
Process temperature control
Continuously adjustable up to max. 230 °C

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Physical Characteristics


Footprint
Compact,spiral design
Product height
Variable,depending on the number of levels
Heating element type
Electrical,thermal oil,or steam-powered
Housing design
Highly insulated

Custom Options


Control panel type
PLC control system with touch panel
Stage belt system
5 to 10 levels
Belt width options
400,600,700,and 1,000 mm
Heating element type
Electrical,thermal oil,or steam-powered
Steam injection
Optional dew point control
Cleaning system
CIP nozzles and belt wash system
