Shaftless spiral conveyor for difficult waste handling

Efficiently tackle complex waste handling challenges with a design that excels in conveying bulk materials like de-watered sludge and packaged food, ensuring optimal operation with minimal maintenance and seamless integration into existing waste treatment lines.

Conveys and Processes Complex Waste Materials Efficiently

The SSC Shaftless Spiral Conveyor from WAMGROUP is a highly efficient solution for conveying complex and difficult materials in processing environments. With an extra heavy-duty shaftless screw that slides on a wear-resistant liner, it ensures reliable operation without the need for intermediate bearings. This design is vital for handling variable particle sizes and materials prone to tangling, such as urban solid waste, de-watered sludge, and packaged food products.

Designed for challenging applications, it finds use in industries like wastewater treatment, food and beverage processing, and solid waste management. The SSC offers throughput rates up to 45 m³/h for sludge, using drive power ranging from 0.55 kW to 9.2 kW. Constructed from carbon or stainless steel, it includes options for various liners to suit specific material characteristics, ensuring durability and corrosion resistance.

The system is modular, allowing easy integration and customization with options like bolted trough covers and different power transmissions. It ensures an odour-free, fully enclosed operation while providing substantial access for cleaning and inspection, making maintenance straightforward and efficient. The SSC is designed for continuous operation and is particularly suited to applications involving slurries, solids, and cakes.

Benefits

  • Handles complex materials effortlessly, minimizing material blockage issues.
  • Reduces maintenance needs with a simple design featuring few components.
  • Ensures odour-free operation and environmental compliance.
  • Optimizes energy use with efficient drive power options.
  • Offers versatile integration and adaptation to various industry requirements.

General


Applications
De-watered sludge,Thickened sludge,Food industry,Fruit processing,Beverage industry,Slaughterhouses,Sugarhouse rejects,Conditioned sludge,Creams or pastes,Restaurants,Screenings and floating matter,Meat processing,Canteens,Packaged food,Fish processing,Pulp and paper,Abattoirs,Vegetable processing,Urban solid waste,Waste from meat processing,Chemical industry,Catering
End products
Meat sausages,Recycled paper pulp,Restaurant food waste compost,Sugar by-products,Processed meat cuts,Compost from de-watered sludge,Processed poultry products,Processed fish fillets,Fruit juice concentrates,Chemical additives,Packaged sauces,Alcohol distillation by-products,Organic waste for biogas,Canned soups,Canned fruit,Packaged ready-to-eat meals,Clarified wastewater,Catering waste mulches,Vegetable purees,Recycled urban waste materials
Steps before
Screening,De-watering,Thickening,Conditioning
Steps after
Waste Treatment,Processing,Recycling,Sludge Treatment
Input ingredients
urban solid waste,screenings,floating matter,de-watered sludge,thickened sludge,conditioned sludge,packaged food,creams,pastes,waste from meat processing,waste from fish processing,waste from fruit processing,waste from vegetable processing
Output ingredients
conveyed materials,separated solids,processed waste
Market info
WAMGROUP is known for its expertise in manufacturing bulk material handling and processing equipment, including screw conveyors, dust collectors, and valve systems, with a strong reputation for innovation, quality, and global market presence.

Technical Specifications


Conveying Capacity
Up to 45 m³/h for sludge,up to 12.9 m³/h for screenings
Drive Power
0.55 kW to 9.2 kW
Material of Construction
Carbon steel or 304L/316L stainless steel
Trough Liner
UHMWP (Ultra High Molecular Weight Polyethylene)
Design Type
Shaftless Screw (Spiral) Conveyor
Load Type
Open trough,inlet spout,or side inlet
Liner Options
Various liners with wear signalling,bottom bars,or plates
Power Transmissions
Direct,coupling,chain,belt transmission

Operating Characteristics


Batch vs. continuous operation
Batch / Inline Continuous
Energy efficiency
High
Cleaning method
Manual
Automation level
Manual / PLC
Changeover time
Minimal
Simple design
Few components
Odour-free operation
Yes
Maintenance frequency
Low
Modularity
High

Material Compatibility


Abrasion resistance
Yes
Biological compatibility
Food-grade
Cleanability
Easy to clean
Corrosive resistance (e.g. acids)
Yes
Density/particle size
Varied

Physical Characteristics


Machine footprint
Small
Trough material
Carbon steel / 304L / 316L stainless steel
Spiral material
Heavy-duty
Trough liner
UHMWP
Discharge method
Vertical or flush-type outlet
Loading options
Open trough,inlet spout in cover,side inlet

Custom Options


Material type
Carbon steel / 304L stainless steel / 316L stainless steel
Trough cover type
Bolted trough cover
Inlet options
Standard open trough / Inlet spout / Side inlet
Liner options
Various types per material characteristics
Power transmission type
Direct / Coupling / Chain / Belt
Drive unit
Customizable to application needs
Spiral guiding bar
Available
Odour control
Complete enclosure with gaskets
Inspection access
Hatches for inspection and overflow
Drainage kit
Available
Washing nozzles
Available
