Packed and tray columns for distillation, absorption, and extraction

Enhance your production line with columns designed for high-efficiency separation processes, ensuring whether distilling petrochemicals or extracting pharmaceutical compounds, your operations achieve optimal product purity and yield.

Purifies and Separates Industrial Chemical Mixtures

The EQUILLOY Columns from GMM Pfaudler offer a robust solution for industrial-scale purification and separation needs in sectors like petrochemicals, pharmaceuticals, and oil and gas. These columns excel in distillation, absorption, and extraction processes, designed with a range of alloy materials including stainless steel, Hastelloy, and titanium for superior chemical resistance. Featuring both packed and tray configurations, they handle liquid and gas products with precision, targeting end-products such as polyethylene and methanol. With capabilities of up to 160 MT and dimensions reaching 6 meters in diameter and 45 meters in length, they seamlessly integrate into continuous operations with options for PLC automation and remote monitoring. The EQUILLOY Columns also come equipped with internals for customized operation, and they adhere to industry compliance standards ensuring reliability and performance in harsh production environments.

Benefits

  • Enhances operational efficiency by reducing downtime through continuous processing capabilities.
  • Lowers operational costs with energy-efficient motor control and automation options.
  • Ensures compliance in regulated industries through GMP and chemical-resistant material options.
  • Customizable design supports diverse application needs within the chemical process industries.
  • Facilitates environmentally responsible operations with capabilities supporting zero liquid discharge.

General


Applications
Food,Energy,Chemical process industries,Petrochemicals,Oil and gas refineries,Fertilizers,Pharmaceutical
End products
Polyethylene,Methanol,Biofuels,Hydrogen sulfide,Nutritional supplements,Nitric acid,Edible oils,Propylene glycol,Antibiotics,Ethylene,Synthetic rubber,Urea,Pain relievers,Nitrogen fertilizer,Natural gasoline
Steps before
Pilot Testing,Scale-Up,Purification,Filtration,Drying
Steps after
Evaporation,Distillation,Absorption,Scrubber,Extraction
Input ingredients
raw materials,chemical feeds,gas phase materials,liquid phase materials,solvent inputs
Output ingredients
distilled products,extracted liquids,adsorbed products,fractionally distilled outputs,purified chemicals
Market info
GMM Pfaudler is known for manufacturing glass-lined equipment, reactors, and engineered-to-order (ETO) solutions for the chemical, pharmaceutical, and allied industries, recognized for their innovation, quality, and global presence.

Technical Specifications


Column height
Approx. 45 m
Column diameter
Up to 6 m
Column weight
Up to 160 MT
Construction materials
Carbon steel,Stainless steel,Hastelloy,Titanium,SS 904 L Urea Grade
Column types
Packed,Tray,Liquid-liquid extraction,Adsorption,Fractional distillation
Internals
Trays,Packing,Supports,Distributors
Hydraulic and mechanical performance guarantee
Available if required
Application sectors
Petrochemical,Fertilizer,Oil and Gas Refineries,Specialized Chemical Processes

Operating Characteristics


Working mechanism
Packed column / Tray column
Phase separation
Gas-liquid / Liquid-liquid
Flow type
Counter-current
Automation level
Manual / PLC / SCADA
Flexibility in operation
Vacuum distillation capability
Material adaptability
Carbon Steel / Stainless Steel / Hastelloy / Titanium
Modular design
Available
Hydraulic performance guarantee
Available
Mechanical performance guarantee
Available

Material Compatibility


Material types
Carbon steel,Stainless steel,Hastelloy,Titanium,SS 904 L Urea Grade

Product type Characteristics


Vacuum distillation suitability
Packed Columns
Mass transfer requirement
Tray Columns

Physical Characteristics


Column Diameter
Up to 6 m
Column Height
Approximately 45 m
Weight
Up to 160 MT
Material
Carbon and stainless steel,Hastelloy,titanium,SS 904 L Urea Grade
Construction
Solid or cladded materials

Custom Options


Material Type
Carbon Steel/ Stainless Steel/ Hastelloy/ Titanium/ SS 904L Urea Grade
Column Type
Packed/ Tray/ Liquid-Liquid Extraction/ Adsorption/ Fractional Distillation
Column Size
Up to 160 MT weight,6 m diameter,45 m length
Internals Configuration
Trays,Packing,Supports,Distributors
Hydraulic,Mechanical Performance Guarantee
Available
