Magnetic coupling agitator for sealed mixing

Achieve leak-free, hermetically sealed mixing for critical and aggressive mediums with this customized magnetic coupling agitator designed to ensure safe, contactless operation and energy-efficient processes across diverse viscosity ranges.

Mixes and Blends Viscous Media Securely

The VISCO JET VJ610 from VISCO JET Rührsysteme GmbH is a magnetic coupling tank agitator designed to address the challenges of securely mixing critical or aggressive media in industries like chemicals, pharmaceuticals, and food processing. This agitator features a contact-free magnetic drive, ensuring a hermetically sealed system that prevents leaks and contamination. Suitable for continuous and manual operations, it effectively mixes low to high viscosity substances, including liquid detergents, antibiotic suspensions, and flavored dairy beverages.

The VJ610 integrates seamlessly into production lines where secure and efficient mixing is crucial. The agitator’s design includes a welded magnetic coupling, allowing it to be installed through the tank floor or cover, making it ideal for stationary storage or production tanks. It supports various VISCO JET stirring elements, offering flexibility for different media viscosities.

Made from durable stainless steel grades 1.4301, 1.4404, or 1.4571, the VJ610 is built for high corrosion resistance. It complies with important EU directives for machinery safety and electromagnetic compatibility and is available in ATEX configurations for explosive environments. The agitator’s low drive power requirements result in energy-efficient operations, while available options for polished surfaces facilitate easy cleaning, complemented by compatibility with CIP systems. Custom engineering support is offered for specific application needs, ensuring the agitator meets unique process requirements.

Benefits

  • Ensures operational safety and product integrity with hermetically sealed, leak-free mixing.
  • Enhances process efficiency with flexible stirring for low to high viscosity media.
  • Reduces energy costs through low power consumption design.
  • Compliant with ATEX standards, suitable for explosive environments.
  • Facilitates quick cleaning and maintenance, compatible with CIP systems.

General


Applications
Chemicals,Paints and coatings,Milk products,Candy,Food and beverage,Petrochemicals,Mining,Cosmetics and soaps,Paper manufacturing,Pharmaceuticals
End products
Mineral slurries,Flavored dairy beverages,Liquid detergents,Emulsion paints,Essential oil emulsions,Ethylene by-products,Milk protein concentrates,Pulp fiber suspensions,Caramel sauces,Antibiotic suspensions
Steps before
Material Preparation,Mixing,Ingredient Loading,Heating
Steps after
Cleaning,Sterilization,Product Storage,Packaging
Input ingredients
niedrigviskose Medien,mittelviskose Medien,hochviskose Medien,aggressive Medien,kritische Medien
Output ingredients
gerührte Medien,homogenisierte Produkte
Market info
Visco Jet Ruhrsysteme is known for manufacturing advanced mixing and stirring equipment, particularly industrial agitators, which are engineered-to-order for various industries. Their expertise lies in efficient and tailored mixing solutions with a strong reputation for innovation and quality.

Technical Specifications


Drive Power
From 0.12 kW
Material
Stainless Steel 1.4301/1.4404/1.4571
Mounting Solution
Welded in tank bottom or lid
Hermetically Sealed
Yes,magnetic coupling
Mixing Capability
Low,medium,high viscosity liquids
ATEX Compliance
Zone 0 available
Operation Type
Contactless,magnetically controlled
Energy Efficiency
Low drive power requirements
Cleanability
Compatible with CIP

Operating Characteristics


Working Mechanism
Magnetic coupling
Batch vs. Continuous Operation
Batch
Cleaning Method
CIP Compatible
Energy Efficiency
Low energy consumption
Automation Level
Manual / PLC
Hermetically Sealed Process
Yes
Adaptability for Viscosity
Low,Medium,High Viscosity
Installation Type
Tank-bottom or -deck mounted

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Physical Characteristics


Tank shape
Fixed-standing vertical
Tank size
Customizable
Discharge method
Bottom or top mounted
Magnetic coupling
Enclosed in the tank
Rührorgan material
Stainless Steel 1.4301/1.4404/1.4571

Custom Options


Control panel type
Individually configured
Installation method
Tank-top or tank-bottom
ATEX execution
Available for Zone 0
Rührorgan compatibility
Combines with all VISCO JET® Rührorgane
Material type
Stainless steel (1.4301/1.4404/1.4571)
Surface finish
Electro-polished or ground
