Linear vibratory weigh filler for fragile food products

Achieve precise and gentle filling of fragile food products with this linear vibratory solution, designed to minimize product damage while maximizing operational efficiency in your packaging line.

Accurately Weighs and Fills Fragile Food Products

The LVF-14A/B-D linear vibratory weigh filler from Pattyn Packaging Lines is tailored for food processing and packaging industries, ensuring precise, gentle handling of products such as nuts, IQF fruits, and granular items. This equipment employs vibratory technology to fill directly into boxes, minimizing product drop height and reducing giveaway. Operating at speeds up to 9 c/min, the LVF-14A/B-D supports continuous, high-speed production lines and integrates seamlessly with case erectors, bag inserters, and palletizers for a full automation package. Its hygienic design simplifies cleaning, reducing downtime, while offering customization in material construction to meet industry standards.

Benefits

  • Ensures gentle product handling, reducing damage to fragile food items.
  • Minimizes product giveaway, enhancing packing efficiency and cost-effectiveness.
  • Streamlines integration into existing production lines with full automation compatibility.
  • Simplifies cleaning and maintenance, reducing downtime and improving hygiene.
  • Supports high-speed operations, maximizing throughput in continuous production settings.

General


Applications
Iqf fruits,Iqf vegetables,Nuts,Dried fruits,Granular products
End products
Almonds,Frozen sliced bell peppers,Dried apricots,Quinoa,Frozen diced peaches
Steps before
Case Erecting,Bag Inserting
Steps after
Bag Sealing,Case Closing,Palletizing
Input ingredients
nuts,diced IQF fruits,sliced IQF fruits,diced vegetables,sliced vegetables,dried non-sticky fruits,dry small granular products
Output ingredients
weighed food products,filled boxes
Market info
Pattyn is known for its expertise in designing and manufacturing industrial packaging solutions, specializing in ETO equipment for bulk packaging automation, with a strong reputation for innovation, quality, and customer-focused service in the industry.

Technical Specifications


Speed
up to 9 c/min
Product size
up to 30 x 30 x 30 mm
Output
up to 5 c/min for LVF-14A-D
Output
up to 9 c/min for LVF-14B-D
Container size - Minimum
L.300 x W.200 // D.100
Container size - Maximum
L.800 x W.500 // D.650
Hygienic design
Quick,easy cleaning
Gentle product treatment
Reduces drop height
Filling method
Vibrating pan direct into boxes

Operating Characteristics


Working mechanism
Linear vibratory
Product feed method
Direct to box without weigh hopper
Gentle product treatment
Low drop height
Automation level
PLC-controlled
Changeover time
Quick,easy cleaning
Batch vs. continuous operation
Continuous
Cleaning method
Manual quick cleaning
Output rate
Up to 9 c/min

Material Compatibility


Cleanability
Hygienic design for easy cleaning
Biological compatibility
Suitable for food-grade materials
Corrosive resistance (e.g. acids)
Non-corrosive materials
Density/particle size
Up to 30 x 30 x 30 mm fragile products

Product type Characteristics


Product type
Fragile foods,nuts,diced,sliced IQF fruits and vegetables,dried non-sticky fruits,granular products

Physical Characteristics


Feed/Discharge method
Gross filling straight into the box
Number of Heads
1 or 2 heads
Vibrating pan
1 vibrating pan without weigh hopper
Maximum product size
30 x 30 x 30 mm

Custom Options


Integration possibilities
Pattyn packaging line components
Automation level
Fully automated with Pattyn system
