Gyro sifter for feed cleaning

Eliminate contamination and optimize product quality with high-speed screening and cleaning technology designed for seamless integration into demanding production lines.

Screens and Cleans Production Materials

The Gyro Sifters/Feed Cleaners from CPM are engineered to streamline the cleaning and screening processes in various industries, including animal feed, oilseed processing, ethanol, and biomass production. This equipment is distinguished by its modernized rotor configuration, which can be equipped with adjustable wipers and brushes to enhance the efficiency of material conveyance and screen cleanliness. With full-access doors, maintenance is simplified, ensuring minimal downtime.

Designed for continuous, high-speed operation, these sifters handle up to 300 tons per hour, depending on model, supporting a range of granules, powders, and solids. The stainless steel option offers durability and resistance to corrosion, making it suitable for challenging industrial environments. Optional internal bypass facilitates versatile workflow integration, while compliance with industry standards ensures reliable performance. CPM’s gyro sifters offer significant operational efficiencies, underpinned by robust support and customization options for specific processing needs.

Benefits

  • Maximizes screening efficiency with adjustable rotor and brush system.
  • Simplifies maintenance with full-access doors, reducing downtime.
  • Enhances material purity, boosting product quality across multiple industries.
  • Supports high-capacity operations, processing up to 300 tons per hour.
  • Versatile integration with optional internal bypass and material options.

General


Applications
Aquaculture,Animal feed,Ethanol,Pet food,Hemp,Food industry,Other industries,Oilseed processing,Hops,Rendering,Biomass
End products
Dog kibble,Hemp protein products,Wood pellets,Flaxseed meal,Tallow,Fish feed,Poultry feed,Cattle feed,Animal feed pellets,Ethanol by-products,Dried hops,Soybean meal
Steps before
Grinding,Particle Size Reduction,Briquetting
Steps after
Pelleting,Steam Flaking,Cooling,Packing
Input ingredients
mixed feed ingredients
Output ingredients
screened feed,clean feed
Market info
CPM is known for manufacturing high-quality process equipment and technology solutions for the industrial and agricultural sectors, specializing in particle size reduction, conditioning, and pelleting solutions with a strong reputation for reliability and innovation.

Technical Specifications


Capacity
50–300 TPH (Metric
Screen Area
2,232–12,900 in² (Metric
Motor Power
7.5–250 HP (Metric
Material Handling
Wipers and brushes for material conveyance
Screen Change Accessibility
Full-access doors
Adjustability
Adjustable wiper and brush angle
Option for Material
Stainless steel housing
Internal Bypass
Yes

Operating Characteristics


Screen access
Full-access doors
Maintenance ease
Easy maintenance
Material conveyance
Wipers and brushes
Wiper and brush angle
Adjustable
Screen changes
Easy access
Rotor configuration
Variety of brushes and wipers
Operation efficiency
High

Material Compatibility


Abrasion resistance
Compatible with abrasive materials
Biological compatibility
Suitable for animal feed
Cleanability
Easy to clean with full-access doors
Corrosive resistance (e.g. acids)
Stainless steel housing option available
Density/particle size
Suitable for mixed feed ingredients

Product type Characteristics


Component Configuration
Variety of brushes and wipers

Physical Characteristics


Machine footprint
Varies by model
Screen area
2,232 in² to 12,900 in²
Screen configuration
Variety of brushes and wipers
Access method
Full-access doors for screen changes
Housing material
Optional stainless steel

Custom Options


Screen changes access
Full-access doors
Wipers and brushes configuration
Adjustable angle
Material of housing
Stainless steel
Internal bypass option
Yes
