Gasketed plate heat exchanger for industrial applications

Optimize thermal efficiency and minimize energy consumption in your production line with this versatile gasketed plate heat exchanger, designed for seamless integration across a wide range of industrial processes.

Optimizes Thermal Exchange Across Industrial Applications

The Industrial Gasketed Plate Heat Exchanger from Alfa Laval delivers exceptional thermal management for a range of industries. Designed with advanced features like CurveFlow™ and OmegaPort™, these exchangers enhance fluid distribution and efficiency. Ideal for applications including district cooling, HVAC, and data centers, they handle fluid temperatures with precision and reliability. Utilizing a gasketed plate-and-frame design, they ensure minimal energy consumption and seamless integration with existing systems. Available in various plate and gasket materials, they offer optimal corrosion resistance and durability. AHRI certified, they guarantee reliable performance, while features like ClipGrip™ gaskets ensure straightforward maintenance. Alfa Laval provides engineering support for tailored configurations to meet specific requirements.

Benefits

  • Enhances energy efficiency, reducing operational costs.
  • Ensures reliable thermal performance with AHRI certification.
  • Minimizes maintenance time with easy-to-service design.
  • Customizable to meet specific industry requirements.
  • Supports sustainable operations with reduced environmental impact.

General


Applications
Heat recovery,District cooling,Data centre cooling,Heating,Ice-storage systems,Cooling,Free cooling systems,Evaporation,Condensation
End products
Pharmaceutical process fluids,Ice rink surface cooling,Hvac cooling fluids,Bioethanol concentration,Water purification systems,Data center server cooling,Beer wort cooling,Fruit juice concentrate,Dairy pasteurization,Steam condensate recovery,Geothermal heat pump solutions,Desalination salt recovery
Steps before
Heating,Cooling,Heat Recovery,Condensation,Evaporation
Steps after
Capacity Adjustment,Inspection,Maintenance,Servicing,Efficiency Optimization
Input ingredients
hot fluid,cold fluid,steam
Output ingredients
heated fluid,cooled fluid,condensed steam
Market info
Alfa Laval is renowned for its expertise in heat transfer, separation, and fluid handling technologies, providing innovative, energy-efficient engineered-to-order solutions for various industries including food, marine, and energy.

Technical Specifications


Energy Efficiency
High energy efficiency
Configuration
Flexible – configurable for broad range of applications
Installation
Easy to install
Serviceability
High serviceability
Heat Transfer Area
Series of corrugated plates
Flow Pattern
Counter-currently through the heat exchanger
Plate Design
OmegaPort™,FlexFlow™
Plate Alignment
Five-point alignment,SteerLock™
Gasket Attachment
ClipGrip™
Frame Design
Compact frame
Plate Configuration
Single plate with chevron pattern,Double-wall plate
Port Holes
OmegaPort™ noncircular
Thermal Design
Maximize thermal performance with minimum pressure drop
Gasket Type
Clip or glued
Plate Rigidity
PowerArc™ plate pattern divider
Capacity Change
Easy to adjust for capacity changes

Operating Characteristics


Heat transfer method
Plate and frame
Fluid flow direction
Counter-current
Operation flexibility
Configurable for various applications
Serviceability
Easy to inspect and maintain
Thermal efficiency
High
Capacity adjustment
Easy to adjust
Installation ease
Easy to install
Energy efficiency
Enhanced for reduced consumption

Material Compatibility


Corrosive resistance (e.g. acids)
Yes


AHRI certification
AHRI 400

Physical Characteristics


Compact footprint
Yes
Control panel type
Digital/PLC
Frame type
Compact frame
Discharge method
Counter-current flow

Custom Options


Plate materials
304 SS / 316 SS / Titanium
Gasket materials
EPDM / NBR / FKM
Plate design
Single / Gemini double-wall
Flow configuration
Counter-current / 2-pass
Pressure drop utilization
Optimized for application
Frame type
Compact / Modular
Connection type
Flange / Threaded
Port size
DN 25 - DN 300
