Efficient desolventization and toasting solution for oilseeds

Optimize solvent removal and toasting in your oilseed processing with this versatile desolventizer-toaster solution, designed to maintain product integrity and efficiency across a range of applications.

Desolventizes and Toasts Oilseed Products

The Desolventizer-Toaster from Crown Iron Works is an essential component for efficiently processing oilseed products. This equipment utilizes a vertically oriented, multiple-tray system with indirect heat transfer to desolventize and toast solvent-wet products. Capable of handling various applications like vegetable oil, biodiesel, and CBD oil production, it supports both pilot and large-scale operations. The integration of direct and indirect heating reduces equipment size and enhances process efficiency. With automatic level controls and counter-current desolventization, it ensures consistent product quality. Its robust construction, including steam chests and sweep arms, minimizes maintenance concerns. Additionally, it offers significant energy savings through optimized design and material options suitable for diverse industry needs.

Benefits

  • Enhances solvent recovery efficiency, lowering operational costs.
  • Provides flexibility with pilot and large-scale production capabilities.
  • Reduces energy consumption through optimized heat transfer design.
  • Ensures product integrity with consistent desolventization and toasting.
  • Minimizes maintenance with durable construction and automated controls.

General


Applications
Ethanol,Specialty chemicals,Nutraceuticals,Palm processing,Biodiesel pretreatment,Plant-based proteins,Corn processing,Sunflower processing,Oilseed processing,Soybean processing,Canola/rapeseed processing,Food products,Biofuel,Hemp cbd oil extraction,Pharmaceuticals
End products
Palm oil,Protein isolate,Sunflower oil,Protein concentrate,Nutraceutical extracts,Vegetable oil,Cooking oils,Edible oils,Food-grade ethanol,Cbd oil,Rapeseed oil,Ethanol fuel,Biodiesel,Pharmaceutical compounds,Soybean oil,Canola oil,Corn oil,Specialty chemical intermediates
Steps before
Oilseed Preparation,Oilseed Extraction,Drying
Steps after
Toward Ethanol Production,Refining,Degumming,Neutralizing,Continuous Deodorizing,Biodiesel Pretreatment,Renewable Diesel Pretreatment
Input ingredients
ethanol,hexane,solvent-wet products,vegetable oilseeds,wood chips,silicas,DDG,algae,marine products
Output ingredients
desolventized products,toasted products
Market info
Crown Iron Works is renowned for its expertise in designing and manufacturing engineered-to-order equipment for oilseed processing and edible oil extraction, with a strong reputation for innovation, reliability, and delivering customized solutions worldwide.

Technical Specifications


Capacity
Pilot scale to large scale production
Heat Transfer
Indirect and/or direct
Heat Source
Steam,hot water,or oil
Power Requirements
Low horsepower-per-ton
Level Control
Automatic level controls with actuated gates or variable speed rotary valves
Vapor Venting
Hollow stay bolts for venting vapors
Rotary Valve
Variable-speed rotary valve

Operating Characteristics


Heat transfer method
Indirect and direct
Automation level
Manual / PLC
Changeover time
Efficient with automatic controls
Desolventization type
Counter-current
Scale capability
Pilot to large scale
Energy efficiency
Low horsepower-per-ton
Integrated operations
Desolventize and toasting

Material Compatibility


Density/particle size
0.5–2.5 g/cm³ / 50–1000 µm

Product type Characteristics


Suitable for solvent-wet products
Yes

Physical Characteristics


Cylinder shape
Vertically oriented
Tray type
Multiple trays
Heating method
Steam,hot water,or oil
Feed/discharge method
Variable-speed rotary valve
Vent design
Hollow stay bolts
Bottom tray design
Variable-speed rotary valve
Sweep arm design
Heavy-duty steam chests and robust sweep arms
Pre-desolventizing tray design
Basket-type,suspended in the dome

Custom Options


Heat source compatibility
Steam / Hot Water / Oil
Steam introduction
Optional
Sweep arm design
Heavy-duty
